2
SY10EL07
SY100EL07
Micrel
TA = –40°CTA = 0°CTA = +25°CTA = +85°C
Symbol Parameter Min. Typ. Max. Min. Typ. Max. Min. Typ. Max. Min. Typ. Max. Unit
t
PLH Propagation Delay to 90 250 435 140 250 385 150 260 395 170 280 415 ps
tPHL Output D
tr Output Rise/Fall Times Q 100 225 350 100 225 350 100 225 350 100 225 350 ps
tf (20% to 80%)
DC ELECTRICAL CHARACTERISTICS
TA = –40°CTA = 0°CTA = +25°CTA = +85°C
Symbol Parameter Min. Typ. Max. Min. Typ. Max. Min. Typ. Max. Min. Typ. Max. Unit
I
EE Power Supply Current mA
10EL — 14 17 11 14 17 11 14 17 11 14 17
100EL — 14 17 11 14 17 11 14 17 13 16 20
V
EE Power Supply Voltage V
10EL –4.75 –5.2 –5.5 –4.75 –5.2 –5.5 –4.75 –5.2 –5.5 –4.75 –5.2 –5.5
100EL –4.20 –4.5 –5.5 –4.20 –4.5 –5.5 –4.20 –4.5 –5.5 –4.20 –4.5 –5.5
I
IH Input HIGH Current µA
D0 — — 250 — — 250 — — 250 — — 250
D1 — — 150 — — 150 — — 150 — — 150
VEE = VEE (Min.) to VEE (Max.); VCC = GND
AC ELECTRICAL CHARACTERISTICS
VEE = VEE (Min.) to VEE (Max.); VCC = GND
PRODUCT ORDERING CODE
Ordering Package Operating
Code Type Range
SY10EL07ZC Z8-1 Commercial
SY10EL07ZCTR Z8-1 Commercial
SY100EL07ZC Z8-1 Commercial
SY100EL07ZCTR Z8-1 Commercial
