SN74F112
DUAL NEGATIVE-EDGE-TRIGGERED J-K FLIP-FLOP
WITH CLEAR AND PRESET
SDFS048A – D2932, MARCH 1987 – REVISED OCTOBER 1993
Copyright 1993, Texas Instruments Incorporated
2–1
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
• Package Options Include Plastic
Small-Outline Packages and Standard
Plastic 300-mil DIPs
description
The SN74F112 contains two independent J-K
negative-edge-triggered flip-flops. A low level at
the preset (PRE
) or clear (CLR) inputs sets or
resets the outputs regardless of the levels of the
other inputs. When PRE
and CLR are inactive
(high), data at the J and K inputs meeting the setup
time requirements is transferred to the outputs on
the negative-going edge of the clock pulse. Clock
triggering occurs at a voltage level and is not
directly related to the rise time of the clock pulse.
Following the hold-time interval, data at the J and
K inputs may be changed without affecting the
levels at the outputs. The SN74F112 can perform
as a toggle flip-flop by tying J and K high.
The SN74F112 is characterized for operation from
0°C to 70°C.
FUNCTION TABLE
INPUTS
OUTPUTS
PRE CLR CLK J K Q Q
L H X X X H L
H LXXXLH
LLXXXH
†
H
†
HH↓LLQ
0
Q
0
HH↓HLHL
HH↓LHLH
HH↓H H Toggle
H H H X X Q
0
Q
0
†
The output levels in this configuration are not guaranteed to
meet the minimum levels for V
OH
. Furthermore, this
configuration is nonstable; that is, it will not persist when
either PRE
or CLR returns to its inactive (high) level.
D OR N PACKAGE
(TOP VIEW)
1
2
3
4
5
6
7
8
16
15
14
13
12
11
10
9
1CLK
1K
1J
1PRE
1Q
1Q
2Q
GND
V
CC
1CLR
2CLR
2CLK
2K
2J
2PRE
2Q
