6−8
6.6 Socket Power-Management Register
This register provides power management control over the socket through a mechanism for slowing or stopping the
clock on the card interface when the card is idle. See Table 6−7 for a complete description of the register contents.
Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Register: Socket power-management
Type: Read-only, Read/Write
Offset: CardBus socket address + 20h
Default: 0000 0000h
Table 6−7. Socket Power-Management Register Description
BIT SIGNAL TYPE FUNCTION
31−26 RSVD R Reserved. Bits 31−26 return 00 0000b when read.
25 SKTACCES R
Socket access status. This bit provides information on when a socket access has occurred. This bit is
cleared by a read access.
0 = A PC card access has not occurred (default)
1 = A PC card access has occurred
24 SKTMODE R
Socket mode status. This bit provides clock mode information.
0 = Clock is operating normally
1 = Clock frequency has changed
23−17 RSVD R Reserved. Bits 23−17 return 000 0000b when read.
16 CLKCTRLEN RW
CardBus clock control enable. When bit 16 is set, bit 0 (CLKCTRL) is enabled.
0 = Clock control is disabled (default)
1 = Clock control is enabled
15−1 RSVD R Reserved. Bits 15−1 return 0s when read.
0 CLKCTRL RW
CardBus clock control. This bit determines whether the CB CLKRUN protocol stops or slows the CB clock
during idle states. Bit 16 (CLKCTRLEN) enables this bit.
0 = Allows CB CLKRUN protocol to stop the CB clock (default)
1 = Allows CB CLKRUN
protocol to slow the CB clock by a factor of 16
7−1
7 Electrical Characteristics
7.1 Absolute Maximum Ratings Over Operating Temperature Ranges
Supply voltage range, V
CC
−0.5 V to 4.6 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clamping voltage range, V
CCP,
V
CCCB
−0.5 V to 6 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Input voltage range, V
I
: PCI, miscellaneous −0.5 V to V
CCP
+ 0.5 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PC Card −0.5 to V
CCCB
+ 0.5 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fail safe −0.5 V to V
CC
+ 0.5 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Output voltage range, V
O
: PCI, miscellaneous −0.5 V to V
CCP
+ 0.5 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PC Card −0.5 to V
CCCB
+ 0.5 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fail safe −0.5 V to V
CC
+ 0.5 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Input clamp current, I
IK
(V
I
< 0 or V
I
> V
CC
) (see Note 1) ±20 mA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Output clamp current, I
OK
(V
O
< 0 or V
O
> V
CC
) (see Note 2) ±20 mA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage temperature range, T
stg
−65°C to 150°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Virtual junction temperature, T
J
150°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Stresses beyond those listed under absolute maximum ratings may cause permanent damage to the device. These are stress ratings only and
functional operation of the device at these or any other conditions beyond those indicated under recommended operating conditions is not implied.
Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
NOTES: 1. Applies for external input and bidirectional buffers. V
I
> V
CC
does not apply to fail-safe terminals. PCI terminals and miscellaneous
terminals are measured with respect to V
CCP
instead of V
CC
. PC Card terminals are measured with respect to V
CCCB
. The limit
specified applies for a dc condition.
2. Applies for external output and bidirectional buffers. V
O
> V
CC
does not apply to fail-safe terminals. PCI terminals and miscellaneous
terminals are measured with respect to V
CCP
instead of V
CC
. PC Card terminals are measured with respect to V
CCCB
. The limit
specified applies for a dc condition.
7−2
7.2 Recommended Operating Conditions (see Note 3)
OPERATION MIN NOM MAX UNIT
V
CC
Core voltage
Commercial 3.3 V 3 3.3 3.6 V
V
CCP
PCI and miscellaneous I/O clamp
Commercial
3.3 V 3 3.3 3.6
V
V
CCP
PCI and miscellaneous I/O clamp
voltage
Commercial
5 V 4.75 5 5.25
V
V
CCCB
PC Card I/O clamp voltage
Commercial
3.3 V 3 3.3 3.6
V
V
CCCB
PC Card I/O clamp voltage
Commercial
5 V 4.75 5 5.25
V
PCI
3.3 V 0.5 V
CCP
V
CCP
PCI
5 V 2 V
CCP
V
IH
High-level input voltage
PC Card
3.3 V 0.475 V
CCCB
V
CCCB
V
V
IH
High-level input voltage
PC Card
5 V 2.4 V
CCCB
V
Miscellaneous
2 V
CC
PCI
3.3 V 0 0.3 V
CCP
PCI
5 V 0 0.8
V
IL
Low-level input voltage
PC Card
3.3 V 0 0.325 V
CCCB
V
V
IL
Low-level input voltage
PC Card
5 V 0 0.8
V
Miscellaneous
0 0.8
PCI 0 V
CCP
V
I
Input voltage
PC Card
0 V
CCCB
V
V
I
Input voltage
Miscellaneous
0 V
CC
V
PCI 0 V
CC
V
O
§
Output voltage
PC Card
0 V
CC
V
V
O
§
Output voltage
Miscellaneous
0 V
CC
V
t
t
Input transition time (t
r
and t
f
)
PCI and PC Card 1 4
ns
t
t
Input transition time (t
r
and t
f
)
Miscellaneous
0 6
ns
T
A
Operating ambient temperature range 0 25 70 °C
T
J
Virtual junction temperature 0 25 115 °C
Applies to external inputs and bidirectional buffers without hysteresis
Miscellaneous terminals are 65, 66, 75, 117, 130, and 138 for the PGE-packaged device; A09, B02, B05, L11, L13, and N10 for the
GGU-packaged device; and B10, C09, F12, G03, H02, and L17 for the GVF-packaged device (SUSPEND
, GRST, CDx, and VSx terminals).
§
Applies to external output buffers
These junction temperatures reflect simulation conditions. The customer is responsible for verifying junction temperature.
NOTE 3: Unused terminals (input or I/O) must be held high or low to prevent them from floating.
