4−10
4.21 I/O Base Registers 0, 1
The I/O base registers indicate the lower address of a PCI I/O address range. These registers are used by the
controller to determine when to forward an I/O transaction to the CardBus bus and when to forward a CardBus cycle
to the PCI bus. The lower 16 bits of this register locate the bottom of the I/O window within a 64-Kbyte page, and the
upper 16 bits (31−16) are a page register which locates this 64-Kbyte page in 32-bit PCI I/O address space. Bits 31−2
are read/write. Bits 1 and 0 are read-only and always return 00b, forcing I/O windows to be aligned on a natural
doubleword boundary.
NOTE: Either the I/O base register or the I/O limit register must be nonzero to enable any I/O
transactions.
Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Register: I/O base registers 0, 1
Offset: 2Ch, 34h
Type: Read-only, Read/Write
Default: 0000 0000h
4.22 I/O Limit Registers 0, 1
The I/O limit registers indicate the upper address of a PCI I/O address range. These registers are used by the
controller to determine when to forward an I/O transaction to the CardBus bus and when to forward a CardBus cycle
to PCI. The lower 16 bits of this register locate the top of the I/O window within a 64-Kbyte page, and the upper 16
bits are a page register that locates this 64-Kbyte page in 32-bit PCI I/O address space. Bits 15−2 are read/write and
allow the I/O limit address to be located anywhere in the 64-Kbyte page (indicated by bits 31−16 of the appropriate
I/O base) on doubleword boundaries.
Bits 31−16 are read-only and always return 0000h when read. The page is set in the I/O base register. Bits 1 and 0
are read-only and always return 00b, forcing I/O windows to be aligned on a natural doubleword boundary. Write
transactions to read-only bits have no effect. The controller assumes that the lower 2 bits of the limit address are 11b.
NOTE: The I/O base or the I/O limit register must be nonzero to enable an I/O transaction.
Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Register: I/O limit registers 0, 1
Offset: 30h, 38h
Type: Read-only, Read/Write
Default: 0000 0000h
4−11
4.23 Interrupt Line Register
The interrupt line register communicates interrupt line routing information.
Bit 7 6 5 4 3 2 1 0
Default 1 1 1 1 1 1 1 1
Register: Interrupt line
Offset: 3Ch
Type: Read/Write
Default: FFh
4.24 Interrupt Pin Register
The value read from the interrupt pin register is function dependent and depends on the interrupt signaling mode,
selected through bits 2−1 (INTMODE field) of the device control register (PCI offset 92h, see Section 4.33).
Bit 7 6 5 4 3 2 1 0
Default 0 0 0 0 0 0 0 1
Register: Interrupt pin
Offset: 3Dh
Type: Read-only
Default: 01h
4−12
4.25 Bridge Control Register
The bridge control register provides control over various bridging functions. See Table 4−6 for a complete description
of the register contents.
Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Default 0 0 0 0 0 0 1 1 0 1 0 0 0 0 0 0
Register: Bridge control
Offset: 3Eh
Type: Read-only, Read/Write
Default: 0340h
Table 4−6. Bridge Control Register Description
BIT SIGNAL TYPE FUNCTION
15−11 RSVD R Reserved. Bits 15−11 return 00 0000b when read.
10 POSTEN RW
Write posting enable. Enables write posting to and from the CardBus socket. Write posting enables posting
of write data on burst cycles. Operating with write posting disabled inhibits performance on burst cycles.
Note that burst write data can be posted, but various write transactions may not.
9 PREFETCH1 RW
Memory window 1 type. Bit 9 specifies whether or not memory window 1 is prefetchable. Bit 9 is encoded
as:
0 = Memory window 1 is nonprefetchable
1 = Memory window 1 is prefetchable (default)
8 PREFETCH0 RW
Memory window 0 type. Bit 8 specifies whether or not memory window 0 is prefetchable. This bit is
encoded as:
0 = Memory window 0 is nonprefetchable
1 = Memory window 0 is prefetchable (default)
7 INTR RW
PCI interrupt − IREQ routing enable. Bit 7 selects whether PC Card functional interrupts are routed to PCI
interrupts or the IRQ specified in the ExCA registers.
0 = Functional interrupts routed to PCI interrupts (default)
1 = Functional interrupts routed by ExCAs
6 CRST RW
CardBus reset. When bit 6 is set, CRST is asserted on the CardBus interface. CRST can also be asserted
by passing a PRST
assertion to CardBus.
0 = CRST
deasserted
1 = CRST
asserted (default)
5 MABTMODE RW
Master abort mode. Bit 5 controls how the controller responds to a master abort when the controller is an
initiator on the CardBus interface. This bit is common between each socket.
0 = Master aborts not reported (default)
1 = Signal target abort on PCI and SERR
(if enabled)
4 RSVD R Reserved. Bit 4 returns 0b when read.
3 VGAEN RW
VGA enable. Bit 3 affects how the controller responds to VGA addresses. When this bit is set, accesses
to VGA addresses are forwarded.
2 ISAEN RW
ISA mode enable. Bit 2 affects how the controller passes I/O cycles within the 64-Kbyte ISA range. When
this bit is set, the controller does not forward the last 768 bytes of each 1K I/O range to CardBus.
1 CSERREN RW
CSERR enable. Bit 1 controls the response of the controller to CSERR signals on the CardBus bus.
0 = CSERR
is not forwarded to PCI SERR
1 = CSERR is forwarded to PCI SERR
0 CPERREN RW
CardBus parity error response enable. Bit 0 controls the response of the controller to CardBus parity
errors.
0 = CardBus parity errors are ignored
1 = CardBus parity errors are reported using CPERR
