LMV7239M7X

Part # LMV7239M7X
Description Comparator Single R-R I/P 5.5V 5-Pin SC-70 T/R
Category IC
Availability In Stock
Qty 5867
Qty Price
1 - 171 $1.45979
172 - 430 $1.16120
431 - 913 $1.09484
914 - 1,965 $1.01743
1,966 + $0.90684
Manufacturer Available Qty
National Semiconductor Corp
Date Code: 0652
  • Shipping Freelance Stock: 5867
    Ships Immediately



Technical Document


DISCLAIMER: The information provided herein is solely for informational purposes. Customers must be aware of the suitability of this product for their application, and consider that variable factors such as Manufacturer, Product Category, Date Codes, Pictures and Descriptions may differ from available inventory.

LMV7235, LMV7239
www.ti.com
SNOS532M SEPTEMBER 2000REVISED FEBRUARY 2013
LMV7235/LMV7239/LMV7239Q 75 nsec, Ultra Low Power, Low Voltage, Rail-to-Rail Input
Comparator with Open-Drain/Push-Pull Output
Check for Samples: LMV7235, LMV7239
1
FEATURES
DESCRIPTION
The LMV7235/LMV7239/LMV7239Q are ultra low
2
(V
S
= 5V, T
A
= 25°C
power, low voltage, 75 nsec comparators. They are
Typical values unless otherwise specified)
guaranteed to operate over the full supply voltage
Propagation delay 75 nsec
range of 2.7V to 5.5V. These devices achieve a 75
nsec propagation delay while consuming only 65µA
Low supply current 65µA
of supply current at 5V.
Rail-to-Rail input
The LMV7235/LMV7239/LMV7239Q have a greater
Open drain and push-pull output
than rail-to-rail common mode voltage range. The
Ideal for 2.7V and 5V single supply
input common mode voltage range extends 200mV
applications
below ground and 200mV above supply, allowing
Available in space saving packages
both ground and supply sensing.
5-pin SOT-23
The LMV7235 features an open drain output. By
connecting an external resistor, the output of the
5-pin SC70
comparator can be used as a level shifter.
LMV7239Q is an automotive grade product
that is AECQ grade 1 qualified and is
The LMV7239/LMV7239Q features a push-pull output
manufactured on an automotive grade flow.
stage. This feature allows operation without the need
of an external pull-up resistor.
APPLICATIONS
The LMV7235/LMV7239/LMV7239Q are available in
the 5-Pin SC70 and 5-Pin SOT-23 packages, which
Portable and battery powered systems
are ideal for systems where small size and low power
Scanners
is critical.
Set top boxes
High speed differential line receiver
Window comparators
Zero-crossing detectors
High speed sampling circuits
Automotive
1
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of
Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
2All trademarks are the property of their respective owners.
PRODUCTION DATA information is current as of publication date.
Copyright © 2000–2013, Texas Instruments Incorporated
Products conform to specifications per the terms of the Texas
Instruments standard warranty. Production processing does not
necessarily include testing of all parameters.
Inverting
Input
1
2
3 4
5
V
+
V
-
V
OUT
Non-Inverting
Input
SC70
SOT-23
Crystal
100K
V
OUT
0.1uF
V
CC
100K
100K
LMV7235, LMV7239
SNOS532M SEPTEMBER 2000REVISED FEBRUARY 2013
www.ti.com
Typical Application
Figure 1. Crystal Oscillator
Connection Diagram
Figure 2. 5-Pin SC70/SOT-23 (Top View)
Simplified Schematic
2 Submit Documentation Feedback Copyright © 2000–2013, Texas Instruments Incorporated
Product Folder Links: LMV7235 LMV7239
LMV7235, LMV7239
www.ti.com
SNOS532M SEPTEMBER 2000REVISED FEBRUARY 2013
These devices have limited built-in ESD protection. The leads should be shorted together or the device placed in conductive foam
during storage or handling to prevent electrostatic damage to the MOS gates.
Absolute Maximum Ratings
(1)(2)
ESD Tolerance
(3)
Human Model Body 1000V
Machine Body 100V
Differential Input Voltage ± Supply Voltage
Output Short Circuit Duration
(4)
Supply Voltage (V
+
- V
) 6V
Soldering Information
Infrared or Convection (20 sec) 235°C
Wave Soldering (10 sec) 260°C (lead temp)
Voltage at Input/Output Pins (V
+
) +0.3V, (V
) 0.3V
Current at Input Pin
(5)
±10mA
(1) Absolute Maximum Ratings indicate limits beyond which damage to the device may occur. Operating Ratings indicate conditions for
which the device is intended to be functional, but specific performance is not guaranteed. For guaranteed specifications and the test
conditions, see the Electrical Characteristics.
(2) If Military/Aerospace specified devices are required, please contact the Texas Instruments Sales Office / Distributors for
availability and specifications.
(3) Human Body Model, applicable std. MIL-STD-883, Method 3015.7. Machine Model, applicable std. JESD22-A115-A (ESD MM std. of
JEDEC)Field-Induced Charge-Device Model, applicable std. JESD22-C101-C (ESD FICDM std. of JEDEC).
(4) Applies to both single-supply and split-supply operation. Continuous short circuit operation at elevated ambient temperature can result in
exceeding the maximum allowed junction temperature of 150°C. Output currents in excess of ±30mA over long term may adversely
affect reliability.
(5) Limiting input pin current is only necessary for input voltages that exceed absolute maximum input voltage ratings.
Operating Ratings
Supply Voltages (V
+
- V
) 2.7V to 5.5V
Temperature Range
(1)
LMV7235/LMV7239 40°C to +85°C
LMV7239Q 40°C to +125°C
Storage Temperature Range 65°C to +150°C
Package Thermal Resistance
5-Pin SC70 478°C/W
5-Pin SOT-23 265°C/W
(1) The maximum power dissipation is a function of T
J(MAX)
, θ
JA
. The maximum allowable power dissipation at any ambient temperature is
P
D
= (T
J(MAX)
– T
A
) / θ
JA
. All numbers apply for packages soldered directly onto a PC Board.
2.7V Electrical Characteristics
Unless otherwise specified, all limits guaranteed for T
A
= 25°C, V
CM
= V
+
/2, V
+
= 2.7V, V
= 0V
. Boldface limits apply at the
temperature extremes.
Symbol Parameter Conditions Min
(1)
Typ
(2)
Max
(1)
Units
0.8 6
V
OS
Input Offset Voltage mV
8
30 400
I
B
Input Bias Current nA
600
5 200
I
OS
Input Offset Current nA
400
(1) All limits are guaranteed by testing or statistical analysis.
(2) Typical values represent the most likely parametric norm as determined at the time of characterization. Actual typical values may vary
over time and will also depend on the application and configuration. The typical values are not tested and are not guaranteed on
shipped production material.
Copyright © 2000–2013, Texas Instruments Incorporated Submit Documentation Feedback 3
Product Folder Links: LMV7235 LMV7239
