PNP HIGH POWER SILICON TRANSISTOR
Qualified per MIL-PRF-19500/379
Devices Qualified Level
2N3791 2N3792
JAN
JANTX
JANTXV
MAXIMUM RATINGS
Ratings
Symbol
2N3791
2N3792
Unit
Collector-Emitter Voltage
V
CEO
60 80 Vdc
Collector-Base Voltage
V
CBO
60 80 Vdc
Emitter-Base Voltage
V
EBO
7.0 Vdc
Base Current I
B
4.0 Adc
Collector Current
I
C
10 Adc
Total Power Dissipation @ T
A
= +25
0
C
(1)
@ T
C
= +100
0
C
(2)
P
T
5.0
85.7
W
W
Operating & Storage Junction Temperature Range
T
J
,
T
stg
-65 to +200
0
C
THERMAL CHARACTERISTICS
Characteristics Symbol Max. Unit
Thermal Resistance, Junction-to-Case
R
θJC
1.17
0
C/W
1) Derate linearly @ 28.57 mW/
0
C for T
A
> +25
0
C
2) Derate linearly @ 0.857 mW/
0
C for T
C
> +100
0
C
TO-3*
(TO-204AA)
*See Appendix A for
Package Outline
ELECTRICAL CHARACTERISTICS (T
C
= 25
0
C unless otherwise noted)
Characteristics Symbol Min. Max. Unit
OFF CHARACTERISTICS
Collector-Emitter Breakdown Voltage
I
C
= 10 mAdc 2N3791
2N3792
V
(BR)
CEO
60
80
Vdc
Collector-Emitter Cutoff Current
V
CE
= 50 Vdc 2N3791
V
CE
= 70 Vdc 2N3792
I
CES
5.0
5.0
mAdc
Collector-Emitter Cutoff Current
V
CE
= 60 Vdc, V
BE
= 1.5 Vdc 2N3791
V
CE
= 80 Vdc, V
BE
= 1.5 Vdc 2N3792
I
CEX
5.0
5.0
mAdc
6 Lake Street, Lawrence, MA 01841
1-800-446-1158 / (978) 794-1666 / Fax: (978) 689-0803
120101
Page 1 of 2
2N3791, 2N3792 JAN SERIES
ELECTRICAL CHARACTERISTICS (con’t)
Characteristics Symbol Min. Max. Unit
Collector-Base Cutoff Current
V
CB
= 60 Vdc 2N3791
V
CB
= 80 Vdc 2N3792
I
CBO
5.0
5.0
mAdc
Emitter-Base Cutoff Current
V
EB
= 7.0 Vdc
I
EBO
5.0
mAdc
ON CHARACTERISTICS
(3)
Forward-Current Transfer Ratio
I
C
= 1.0 Adc, V
CE
= 2.0 Vdc
I
C
= 3.0 Adc, V
CE
= 2.0 Vdc
I
C
= 5.0 Adc, V
CE
= 2.0 Vdc
I
C
= 10 Adc, V
CE
= 4.0 Vdc
h
FE
50
30
10
5.0
150
120
Collector-Emitter Saturation Voltage
I
C
= 5.0 Adc, I
B
= 0.5 Adc
I
C
= 10 Adc, I
B
= 2.0 Adc
V
CE(sat)
1.0
2.5
Vdc
Base-Emitter Saturation Voltage
I
C
= 5.0 Adc, I
B
= 0.5 Adc
I
C
= 10 Adc, I
B
= 2.0 Adc
V
BE(sat)
1.5
3.0
Vdc
DYNAMIC CHARACTERISTICS
Magnitude of Common Emitter Small-Signal Short-Circuit
Forward Current Transfer Ratio
I
C
= 0.5 Adc, V
CE
= 10 Vdc, f = 1.0 MHz
h
fe
4.0
20
Small-Signal Short-Circuit Forward Current Transfer Ratio
I
C
= 0.5 Adc, V
CE
= 10 Vdc, f = 1.0 kHz
h
fe
30
300
Output Capacitance
V
CB
= 10 Vdc, I
E
= 0, f = 1.0 MHz
C
obo
500
pF
SAFE OPERATING AREA
DC Tests
T
C
= +25
0
C, 1 Cycle, t 1.0 s
Test 1
V
CE
= 15 Vdc, I
C
= 10 Adc
Test 2
V
CE
= 40 Vdc, I
C
= 3.75 Adc
Test 3
V
CE
= 55 Vdc, I
C
= 0.9 Adc 2N3791
V
CE
= 65 Vdc, I
C
= 0.9 Adc 2N3792
(3) Pulse Test: Pulse Width = 300µs, Duty Cycle 2.0%.
