C8051F040/1/2/3/4/5/6/7

262 Rev. 1.5

SFR Definition 20.2. SPI0CN: SPI0 Control

Bit 7: SPIF: SPI0 Interrupt Flag.

This bit is set to logic 1 by hardware at the end of a data transfer. If interrupts are enabled,

setting this bit causes the CPU to vector to the SPI0 interrupt service routine. This bit is not

automatically cleared by hardware. It must be cleared by software.

Bit 6: WCOL: Write Collision Flag.

This bit is set to logic 1 by hardware (and generates a SPI0 interrupt) to indicate a write to

the SPI0 data register was attempted while a data transfer was in progress. It must be

cleared by software.

Bit 5: MODF: Mode Fault Flag.

This bit is set to logic 1 by hardware (and generates a SPI0 interrupt) when a master mode

collision is detected (NSS is low, MSTEN = 1, and NSSMD[1:0] = 01). This bit is not auto-

matically cleared by hardware. It must be cleared by software.

Bit 4: RXOVRN: Receive Overrun Flag (Slave Mode only).

This bit is set to logic 1 by hardware (and generates a SPI0 interrupt) when the receive

buffer still holds unread data from a previous transfer and the last bit of the current transfer

is shifted into the SPI0 shift register. This bit is not automatically cleared by hardware. It

must be cleared by software.

Bits 3-2: NSSMD1-NSSMD0: Slave Select Mode.

Selects between the following NSS operation modes:

(See Section “20.2. SPI0 Master Mode Operation” on page 257 and Section “20.3. SPI0

Slave Mode Operation” on page 259).

00: 3-Wire Slave or 3-wire Master Mode. NSS signal is not routed to a port pin.

01: 4-Wire Slave or Multi-Master Mode (Default). NSS is always an input to the device.

1x: 4-Wire Single-Master Mode. NSS signal is mapped as an output from the device and will

assume the value of NSSMD0.

Bit 1: TXBMT: Transmit Buffer Empty.

This bit will be set to logic 0 when new data has been written to the transmit buffer. When

data in the transmit buffer is transferred to the SPI shift register, this bit will be set to logic 1,

indicating that it is safe to write a new byte to the transmit buffer.

Bit 0: SPIEN: SPI0 Enable.

This bit enables/disables the SPI.

0: SPI disabled.

1: SPI enabled.

R/W R/W R/W R/W R/W R/W R R/W Reset Value

SPIF WCOL MODF RXOVRN NSSMD1 NSSMD0 TXBMT SPIEN 00000110

Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0

Bit

Addressable

SFR Address:

SFR Page:

0xF8

C8051F040/1/2/3/4/5/6/7

Rev. 1.5 263

SFR Definition 20.3. SPI0CKR: SPI0 Clock Rate

Bits 7-0: SCR7-SCR0: SPI0 Clock Rate

These bits determine the frequency of the SCK output when the SPI0 module is configured

for master mode operation. The SCK clock frequency is a divided version of the system

clock, and is given in the following equation, where SYSCLK is the system clock frequency

and SPI0CKR is the 8-bit value held in the SPI0CKR register.

for 0 <= SPI0CKR <= 255

Example: If SYSCLK = 2 MHz and SPI0CKR = 0x04,

R/W R/W R/W R/W R/W R/W R/W R/W Reset Value

SCR7 SCR6 SCR5 SCR4 SCR3 SCR2 SCR1 SCR0 00000000

Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0

SFR Address:

SFR Page:

0x9D

SCK

2000000

241+

--------------------------

SCK

200kHz=

SCK

SYSCLK

2 SPI0CKR 1+

-------------------------------------------------

C8051F040/1/2/3/4/5/6/7

264 Rev. 1.5

SFR Definition 20.4. SPI0DAT: SPI0 Data

Bits 7-0: SPI0DAT: SPI0 Transmit and Receive Data.

The SPI0DAT register is used to transmit and receive SPI0 data. Writing data to SPI0DAT

places the data into the transmit buffer and initiates a transfer when in Master Mode. A read

of SPI0DAT returns the contents of the receive buffer.

R/W R/W R/W R/W R/W R/W R/W R/W Reset Value

00000000

Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0

SFR Address:

SFR Page:

0x9B
