C8051F040/1/2/3/4/5/6/7
Rev. 1.5 241
19.2. SMBus Protocol
Two types of data transfers are possible: data transfers from a master transmitter to an addressed slave
receiver (WRITE), and data transfers from an addressed slave transmitter to a master receiver (READ).
The master device initiates both types of data transfers and provides the serial clock pulses on SCL. Note:
multiple master devices on the same bus are supported. If two or more masters attempt to initiate a data
transfer simultaneously, an arbitration scheme is employed with a single master always winning the arbitra-
tion. Note that it is not necessary to specify one device as the master in a system; any device who trans-
mits a START and a slave address becomes the master for that transfer.
A typical SMBus transaction consists of a START condition followed by an address byte (Bits7-1: 7-bit
slave address; Bit0: R/W direction bit), one or more bytes of data, and a STOP condition. Each byte that is
received (by a master or slave) must be acknowledged (ACK) with a low SDA during a high SCL (see
Figure 19.3). If the receiving device does not ACK, the transmitting device will read a “not acknowledge”
(NACK), which is a high SDA during a high SCL.
The direction bit (R/W) occupies the least-significant bit position of the address. The direction bit is set to
logic 1 to indicate a "READ" operation and cleared to logic 0 to indicate a "WRITE" operation.
All transactions are initiated by a master, with one or more addressed slave devices as the target. The
master generates the START condition and then transmits the slave address and direction bit. If the trans-
action is a WRITE operation from the master to the slave, the master transmits the data one byte at a time
and expects an ACK from the slave at the end of each byte. For READ operations, the slave transmits the
data and expects an ACK from the master at the end of each byte. At the end of the data transfer, the mas-
ter generates a STOP condition to terminate the transaction and free the bus. Figure 19.3 illustrates a typ-
ical SMBus transaction.
Figure 19.3. SMBus Transaction
19.2.1. Arbitration
A master may start a transfer only if the bus is free. The bus is free after a STOP condition or after the SCL
and SDA lines remain high for a specified time (see Section 19.2.4). In the event that two or more devices
attempt to begin a transfer at the same time, an arbitration scheme is employed to force one master to give
up the bus. The master devices continue transmitting until one attempts a HIGH while the other transmits a
LOW. Since the bus is open-drain, the bus will be pulled LOW. The master attempting the HIGH will detect
a LOW SDA and give up the bus. The winning master continues its transmission without interruption; the
losing master becomes a slave and receives the rest of the transfer. This arbitration scheme is non-
destructive: one device always wins, and no data is lost.
SLA6
SDA
SLA5-0 R/W D7 D6-0
SCL
Slave Address + R/W Data ByteSTART ACK NACK STOP
C8051F040/1/2/3/4/5/6/7
242 Rev. 1.5
19.2.2. Clock Low Extension
SMBus provides a clock synchronization mechanism, similar to I
2
C, which allows devices with different
speed capabilities to coexist on the bus. A clock-low extension is used during a transfer in order to allow
slower slave devices to communicate with faster masters. The slave may temporarily hold the SCL line
LOW to extend the clock low period, effectively decreasing the serial clock frequency.
19.2.3. SCL Low Timeout
If the SCL line is held low by a slave device on the bus, no further communication is possible. Furthermore,
the master cannot force the SCL line high to correct the error condition. To solve this problem, the SMBus
protocol specifies that devices participating in a transfer must detect any clock cycle held low longer than
25 ms as a “timeout” condition. Devices that have detected the timeout condition must reset the communi-
cation no later than 10 ms after detecting the timeout condition.
19.2.4. SCL High (SMBus Free) Timeout
The SMBus specification stipulates that if the SCL and SDA lines remain high for more that 50 µs, the bus
is designated as free. If an SMBus device is waiting to generate a Master START, the START will be gen-
erated following the bus free timeout.
19.3. SMBus Transfer Modes
The SMBus0 interface may be configured to operate as a master and/or a slave. At any particular time, the
interface will be operating in one of the following modes: Master Transmitter, Master Receiver, Slave
Transmitter, or Slave Receiver. See Table 19.1 for transfer mode status decoding using the SMB0STA sta-
tus register. The following mode descriptions illustrate an interrupt-driven SMBus0 application; SMBus0
may alternatively be operated in polled mode.
19.3.1. Master Transmitter Mode
Serial data is transmitted on SDA while the serial clock is output on SCL. SMBus0 generates a START
condition and then transmits the first byte containing the address of the target slave device and the data
direction bit. In this case the data direction bit (R/W) will be logic 0 to indicate a "WRITE" operation. The
SMBus0 interface transmits one or more bytes of serial data, waiting for an acknowledge (ACK) from the
slave after each byte. To indicate the end of the serial transfer, SMBus0 generates a STOP condition.
Figure 19.4. Typical Master Transmitter Sequence
A AAS W PData Byte Data ByteSLA
S = START
P = STOP
A = ACK
W = WRITE
SLA = Slave Address
Received by SMBus
Interface
Transmitted by
SMBus Interface
Interrupt Interrupt InterruptInterrupt
C8051F040/1/2/3/4/5/6/7
Rev. 1.5 243
19.3.2. Master Receiver Mode
Serial data is received on SDA while the serial clock is output on SCL. The SMBus0 interface generates a
START followed by the first data byte containing the address of the target slave and the data direction bit.
In this case the data direction bit (R/W) will be logic 1 to indicate a "READ" operation. The SMBus0 inter-
face receives serial data from the slave and generates the clock on SCL. After each byte is received,
SMBus0 generates an ACK or NACK depending on the state of the AA bit in register SMB0CN. SMBus0
generates a STOP condition to indicate the end of the serial transfer.
Figure 19.5. Typical Master Receiver Sequence
19.3.3. Slave Transmitter Mode
Serial data is transmitted on SDA while the serial clock is received on SCL. The SMBus0 interface receives
a START followed by data byte containing the slave address and direction bit. If the received slave address
matches the address held in register SMB0ADR, the SMBus0 interface generates an ACK. SMBus0 will
also ACK if the general call address (0x00) is received and the General Call Address Enable bit
(SMB0ADR.0) is set to logic 1. In this case the data direction bit (R/W) will be logic 1 to indicate a "READ"
operation. The SMBus0 interface receives the clock on SCL and transmits one or more bytes of serial
data, waiting for an ACK from the master after each byte. SMBus0 exits slave mode after receiving a
STOP condition from the master.
Figure 19.6. Typical Slave Transmitter Sequence
Data ByteData Byte A NAS R PSLA
S = START
P = STOP
A = ACK
N = NACK
R = READ
SLA = Slave Address
Received by SMBus
Interface
Transmitted by
SMBus Interface
Interrupt Interrupt InterruptInterrupt
PRSLAS Data ByteData Byte A NA
S = START
P = STOP
N = NACK
W = WRITE
SLA = Slave Address
Received by SMBus
Interface
Transmitted by
SMBus Interface
Interrupt Interrupt Interrupt
Interrupt
