Bits7-0: P6.[7:0]: Port6 Output Latch Bits.
Write - Output appears on I/O pins.
0: Logic Low Output.
1: Logic High Output (Open-Drain if corresponding P6MDOUT bit = 0). See SFR Definition
17.21.
Read - Returns states of I/O pins.
0: P6.n pin is logic low.
1: P6.n pin is logic high.
Note: P6.[7:0] can be driven by the External Data Memory Interface (as Address[15:8] in Multi-
plexed mode, or as Address[7:0] in Non-multiplexed mode). See Section “16. External
Data Memory Interface and On-Chip XRAM” on page 187 for more information about the
External Memory Interface.
R/W R/W R/W R/W R/W R/W R/W R/W Reset Value
P6.7 P6.6 P6.5 P6.4 P6.3 P6.2 P6.1 P6.0 11111111
Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
Bit
Addressable
SFR Address:
SFR Page:
0xE8
F
Bits7-0: P6MDOUT.[7:0]: Port6 Output Mode Bits.
0: Port Pin output mode is configured as Open-Drain.
1: Port Pin output mode is configured as Push-Pull.
R/W R/W R/W R/W R/W R/W R/W R/W Reset Value
00000000
Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
SFR Address:
SFR Page:
0x9E
F
