Bits7-0: P2.[7:0]: Port2 Output Latch Bits.
(Write - Output appears on I/O pins per XBR0, XBR1, XBR2, and XBR3 Registers)
0: Logic Low Output.
1: Logic High Output (open if corresponding P2MDOUT.n bit = 0).
(Read - Regardless of XBR0, XBR1, XBR2, and XBR3 Register settings).
0: P2.n pin is logic low.
1: P2.n pin is logic high.
Note: P2.[7:0] can be driven by the External Data Memory Interface (as Address[15:8] in Multi-
plexed mode, or as Address[7:0] in Non-multiplexed mode). See Section “16. External
Data Memory Interface and On-Chip XRAM” on page 187 for more information about the
External Memory Interface.
R/W R/W R/W R/W R/W R/W R/W R/W Reset Value
P2.7 P2.6 P2.5 P2.4 P2.3 P2.2 P2.1 P2.0 11111111
Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
Bit
Addessable
SFR Address:
SFR Page:
0xA0
All Pages
Bits7-0: P1MDIN.[7:0]: Port 2 Input Mode Bits.
0: Port Pin is configured in Analog Input mode. The digital input path is disabled (a read from
the Port bit will always return ‘0’). The weak pullup on the pin is disabled.
1: Port Pin is configured in Digital Input mode. A read from the Port bit will return the logic
level at the Pin. The state of the weak pullup is determined by the WEAKPUD bit (XBR2.7,
see SFR Definition 17.3).
R/W R/W R/W R/W R/W R/W R/W R/W Reset Value
11111111
Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
SFR Address:
SFR Page:
0xAE
F
