C8051F040/1/2/3/4/5/6/7
184 Rev. 1.5
SFR Definition 15.1. FLACL: Flash Access Limit
SFR Definition 15.2. FLSCL: Flash Memory Control
Bits 7-0: FLACL: Flash Access Limit.
This register holds the high byte of the 16-bit program memory read/write/erase limit
address. The entire 16-bit access limit address value is calculated as 0xNN00 where NN is
replaced by contents of FLACL. A write to this register sets the Flash Access Limit. This reg-
ister can only be written once after any reset. Any subsequent writes are ignored until the
next reset.
R/W R/W R/W R/W R/W R/W R/W R/W Reset Value
00000000
Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0 SFR Address:
SFR Address:
SFR Page:
0xB7
F
Bit7: FOSE: Flash One-Shot Timer Enable
This is the timer that turns off the sense amps after a Flash read.
0: Flash One-Shot Timer disabled.
1: Flash One-Shot Timer enabled (recommended setting).
Bit6: FRAE: Flash Read Always Enable
0: Flash reads occur as necessary (recommended setting).
1: Flash reads occur every system clock cycle.
Bits5-1: RESERVED. Read = 00000b. Must Write 00000b.
Bit0: FLWE: Flash Write/Erase Enable
This bit must be set to allow Flash writes/erases from user software.
0: Flash writes/erases disabled.
1: Flash writes/erases enabled.
R/W R/W R/W R/W R/W R/W R/W R/W Reset Value
FOSE FRAE Reserved Reserved Reserved Reserved Reserved FLWE 10000000
Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0 SFR Address:
SFR Address:
SFR Page:
0xB7
0
C8051F040/1/2/3/4/5/6/7
Rev. 1.5 185
SFR Definition 15.3. PSCTL: Program Store Read/Write Control
Bits7-3: UNUSED. Read = 00000b, Write = don't care.
Bit2: SFLE: Scratchpad Flash Memory Access Enable
When this bit is set, Flash reads and writes from user software are directed to the 128-byte
Scratchpad Flash sector. When SFLE is set to logic 1, Flash accesses out of the address
range 0x00-0x7F should not be attempted. Reads/Writes out of this range will yield unde-
fined results.
0: Flash access from user software directed to the Program/Data Flash sector.
1: Flash access from user software directed to the 128 byte Scratchpad sector.
Bit1: PSEE: Program Store Erase Enable.
Setting this bit allows an entire page of the Flash program memory to be erased provided
the PSWE bit is also set. After setting this bit, a write to Flash memory using the MOVX
instruction will erase the entire page that contains the location addressed by the MOVX
instruction. The value of the data byte written does not matter. Note: The Flash page con-
taining the Read Lock Byte and Write/Erase Lock Bytes cannot be erased by soft-
ware.
0: Flash program memory erasure disabled.
1: Flash program memory erasure enabled.
Bit0: PSWE: Program Store Write Enable.
Setting this bit allows writing a byte of data to the Flash program memory using the MOVX
write instruction. The location must be erased prior to writing data.
0: Write to Flash program memory disabled. MOVX write operations target External RAM.
1: Write to Flash program memory enabled. MOVX write operations target Flash memory.
R/W R/W R/W R/W R/W R/W R/W R/W Reset Value
- - - - - SFLE PSEE PSWE 00000000
Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0 SFR Address:
SFR Address:
SFR Page:
0x8F
0
C8051F040/1/2/3/4/5/6/7
186 Rev. 1.5
