C8051F040/1/2/3/4/5/6/7
Rev. 1.5 169
SFR Definition 13.1. WDTCN: Watchdog Timer Control
Bits7-0: WDT Control
Writing 0xA5 both enables and reloads the WDT.
Writing 0xDE followed within 4 system clocks by 0xAD disables the WDT.
Writing 0xFF locks out the disable feature.
Bit4: Watchdog Status Bit (when Read)
Reading the WDTCN.[4] bit indicates the Watchdog Timer Status.
0: WDT is inactive
1: WDT is active
Bits2-0: Watchdog Timeout Interval Bits
The WDTCN.[2:0] bits set the Watchdog Timeout Interval. When writing these bits,
WDTCN.7 must be set to 0.
R/WR/WR/WR/WR/WR/WR/W R/WReset Value
xxxxx111
Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
SFR Address:
SFR Page:
0xFF
All Pages
C8051F040/1/2/3/4/5/6/7
170 Rev. 1.5
SFR Definition 13.2. RSTSRC: Reset Source
Bit7: Reserved.
Bit6: CNVRSEF: Convert Start Reset Source Enable and Flag
Write: 0: CNVSTR0 is not a reset source.
1: CNVSTR0 is a reset source (active low).
Read: 0: Source of prior reset was not CNVSTR0.
1: Source of prior reset was CNVSTR0.
Bit5: C0RSEF: Comparator0 Reset Enable and Flag.
Write: 0: Comparator0 is not a reset source.
1: Comparator0 is a reset source (active low).
Read: 0: Source of last reset was not Comparator0.
1: Source of last reset was Comparator0.
Bit4: SWRSF: Software Reset Force and Flag.
Write: 0: No effect.
1: Forces an internal reset. /RST pin is not effected.
Read: 0: Source of last reset was not a write to the SWRSF bit.
1: Source of last reset was a write to the SWRSF bit.
Bit3: WDTRSF: Watchdog Timer Reset Flag.
0: Source of last reset was not WDT timeout.
1: Source of last reset was WDT timeout.
Bit2: MCDRSF: Missing Clock Detector Flag.
Write: 0: Missing Clock Detector disabled.
1: Missing Clock Detector enabled; triggers a reset if a missing clock condition is
detected.
Read: 0: Source of last reset was not a Missing Clock Detector timeout.
1: Source of last reset was a Missing Clock Detector timeout.
Bit1: PORSF: Power-On Reset Flag.
Write: If the
V
DD
monitor circuitry is enabled (by tying the MONEN pin to a logic high state), this
bit can be written to select or de-select the
V
DD
monitor as a reset source.
0: De-select the
V
DD
monitor as a reset source.
1: Select the
V
DD
monitor as a reset source.
Important: At power-on, the V
DD
monitor is enabled/disabled using the external V
DD
moni-
tor enable pin (MONEN). The PORSF bit does not disable or enable the V
DD
monitor cir-
cuit. It simply selects the V
DD
monitor as a reset source.
Read: This bit is set whenever a power-on reset occurs. This may be due to a true power-on
reset or a V
DD
monitor reset. In either case, data memory should be considered indeterminate
following the reset.
0: Source of last reset was not a power-on or V
DD
monitor reset.
1: Source of last reset was a power-on or V
DD
monitor reset.
Note: When this flag is read as '1', all other reset flags are indeterminate.
Bit0: PINRSF: HW Pin Reset Flag.
Write: 0: No effect.
1: Forces a Power-On Reset. /RST is driven low.
Read: 0: Source of prior reset was not /RST pin.
1: Source of prior reset was /RST pin.
R R/W R/W R/W R R/W R R/W Reset Value
- CNVRSEF C0RSEF SWRSEF WDTRSF MCDRSF PORSF PINRSF 00000000
Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
SFR Address:
SFR Page:
0xEF
0
C8051F040/1/2/3/4/5/6/7
Rev. 1.5 171
Table 13.1. Reset Electrical Characteristics
–40 to +85 °C unless otherwise specified.
Parameter Conditions Min Typ Max Units
RST Output Low Voltage I
OL
= 8.5 mA, V
DD
= 2.7 V to 3.6 V
——0.6 V
RST Input High Voltage
0.7 x
V
DD
—— V
RST Input Low Voltage
——
0.3
x
V
DD
RST Input Leakage Current RST = 0.0 V
—50— µA
V
DD
for /RST Output Valid
1.0 V
AV+ for /RST Output Valid
1.0 V
V
DD
POR Threshold (V
RST
)
2.40 2.55 2.70 V
Minimum /RST Low Time to
Generat
e a System Reset
10 ns
Reset Time Delay
RST rising edge after V
DD
crosses
V
RST
threshold
80 100 120 ms
Missing Clock Detector
Timeout
Time from last system clock to
reset initiation
100 220 500 µs
