C8051F040/1/2/3/4/5/6/7

130 Rev. 1.5

DEC Rn Decrement register 1 1

DEC direct Decrement direct byte 2 2

DEC @Ri Decrement indirect RAM 1 2

INC DPTR Increment Data Pointer 1 1

MUL AB Multiply A and B 1 4

DIV AB Divide A by B 1 8

DA A Decimal adjust A 1 1

Logical Operations

ANL A, Rn AND Register to A 1 1

ANL A, direct AND direct byte to A 2 2

ANL A, @Ri AND indirect RAM to A 1 2

ANL A, #data AND immediate to A 2 2

ANL direct, A AND A to direct byte 2 2

ANL direct, #data AND immediate to direct byte 3 3

ORL A, Rn OR Register to A 1 1

ORL A, direct OR direct byte to A 2 2

ORL A, @Ri OR indirect RAM to A 1 2

ORL A, #data OR immediate to A 2 2

ORL direct, A OR A to direct byte 2 2

ORL direct, #data OR immediate to direct byte 3 3

XRL A, Rn Exclusive-OR Register to A 1 1

XRL A, direct Exclusive-OR direct byte to A 2 2

XRL A, @Ri Exclusive-OR indirect RAM to A 1 2

XRL A, #data Exclusive-OR immediate to A 2 2

XRL direct, A Exclusive-OR A to direct byte 2 2

XRL direct, #data Exclusive-OR immediate to direct byte 3 3

CLR A Clear A 1 1

CPL A Complement A 1 1

RL A Rotate A left 1 1

RLC A Rotate A left through Carry 1 1

RR A Rotate A right 1 1

RRC A Rotate A right through Carry 1 1

SWAP A Swap nibbles of A 1 1

Data Transfer

MOV A, Rn Move Register to A 1 1

MOV A, direct

Move direct byte to A 2 2

MOV A, @Ri Move indirect RAM to A 1 2

MOV A, #data Move immediate to A 2 2

MOV Rn, A Move A to Register 1 1

MOV Rn, direct Move direct byte to Register 2 2

MOV Rn, #data Move immediate to Register 2 2

MOV direct, A Move A to direct byte 2 2

MOV direct, Rn Move Register to direct byte 2 2

MOV direct, direct Move direct byte to direct byte 3 3

MOV direct, @Ri Move indirect RAM to direct byte 2 2

Table 12.1. CIP-51 Instruction Set Summary (Continued)

Mnemonic Description Bytes

Clock

Cycles

C8051F040/1/2/3/4/5/6/7

Rev. 1.5 131

MOV direct, #data Move immediate to direct byte 3 3

MOV @Ri, A Move A to indirect RAM 1 2

MOV @Ri, direct Move direct byte to indirect RAM 2 2

MOV @Ri, #data Move immediate to indirect RAM 2 2

MOV DPTR, #data16 Load DPTR with 16-bit constant 3 3

MOVC A, @A+DPTR Move code byte relative DPTR to A 1 3

MOVC A, @A+PC Move code byte relative PC to A 1 3

MOVX A, @Ri Move external data (8-bit address) to A 1 3

MOVX @Ri, A Move A to external data (8-bit address) 1 3

MOVX A, @DPTR Move external data (16-bit address) to A 1 3

MOVX @DPTR, A Move A to external data (16-bit address) 1 3

PUSH direct Push direct byte onto stack 2 2

POP direct Pop direct byte from stack 2 2

XCH A, Rn Exchange Register with A 1 1

XCH A, direct Exchange direct byte with A 2 2

XCH A, @Ri Exchange indirect RAM with A 1 2

XCHD A, @Ri Exchange low nibble of indirect RAM with A 1 2

Boolean Manipulation

CLR C Clear Carry 1 1

CLR bit Clear direct bit 2 2

SETB C Set Carry 1 1

SETB bit Set direct bit 2 2

CPL C Complement Carry 1 1

CPL bit Complement direct bit 2 2

ANL C, bit AND direct bit to Carry 2 2

ANL C, /bit AND complement of direct bit to Carry 2 2

ORL C, bit OR direct bit to carry 2 2

ORL C, /bit OR complement of direct bit to Carry 2 2

MOV C, bit Move direct bit to Carry 2 2

MOV bit, C Move Carry to direct bit 2 2

JC rel Jump if Carry is set 2 2/3

JNC rel Jump if Carry is not set 2 2/3

JB bit, rel Jump if direct bit is set 3 3/4

JNB bit, rel Jump if direct bit is not set 3 3/4

JBC bit, rel Jump if direct bit is set and clear bit

3 3/4

Program Branching

ACALL addr11 Absolute subroutine call 2 3

LCALL addr16 Long subroutine call 3 4

RET Return from subroutine 1 5

RETI Return from interrupt 1 5

AJMP addr11 Absolute jump 2 3

LJMP addr16 Long jump 3 4

SJMP rel Short jump (relative address) 2 3

JMP @A+DPTR Jump indirect relative to DPTR 1 3

JZ rel Jump if A equals zero 2 2/3

Table 12.1. CIP-51 Instruction Set Summary (Continued)

Mnemonic Description Bytes

Clock

Cycles

C8051F040/1/2/3/4/5/6/7

132 Rev. 1.5

JNZ rel Jump if A does not equal zero 2 2/3

CJNE A, direct, rel Compare direct byte to A and jump if not equal 3 3/4

CJNE A, #data, rel Compare immediate to A and jump if not equal 3 3/4

CJNE Rn, #data, rel

Compare immediate to Register and jump if not

ual

3 3/4

CJNE @Ri, #data, rel

Compare immediate to indirect and jump if not

ual

3 4/5

DJNZ Rn, rel Decrement Register and jump if not zero 2 2/3

DJNZ direct, rel Decrement direct byte and jump if not zero 3 3/4

NOP No operation 1 1

Table 12.1. CIP-51 Instruction Set Summary (Continued)

Mnemonic Description Bytes

Clock

Cycles

Notes on Registers, Operands and Addressing Modes:

Rn - Register R0-R7 of the currently selected register bank.

@Ri - Data RAM location addressed indirectly through R0 or R1.

rel - 8-bit, signed (two’s complement) offset relative to the first byte of the following instruction. Used by

SJMP and all conditional jumps.

direct - 8-bit internal data location’s address. This could be a direct-access Data RAM location (0x00-

0x7F) or an SFR (0x80-0xFF).

#data - 8-bit constant

#data16 - 16-bit constant

bit - Direct-accessed bit in Data RAM or SFR

addr11 - 11-bit destination address used by ACALL and AJMP. The destination must be within the

same 2K-byte page of program memory as the first byte of the following instruction.

addr16 - 16-bit destination address used by LCALL and LJMP. The destination may be anywhere within

the 64 kB program memory space.

There is one unused opcode (0xA5) that performs the same function as NOP.
