C8051F040/1/2/3/4/5/6/7
Rev. 1.5 49
SFR Definition 5.1. AMX0CF: AMUX0 Configuration
SFR Definition 5.2. AMX0SL: AMUX0 Channel Select
Bits7-4: UNUSED. Read = 0000b; Write = don’t care
Bit3: PORT3IC: Port 3 even/odd Pin Input Pair Configuration Bit
0: Port 3 even and odd input channels are independent single-ended inputs
1: Port 3 even and odd input channels are (respectively) +, - difference input pair
Bit2: HVDA2C: HVDA 2’s Compliment Bit
0: HVDA output measured as an independent single-ended input
1: HVDA result for 2’s compliment value
Bit1: AIN23IC: AIN0.2, AIN0.3 Input Pair Configuration Bit
0: AIN0.2 and AIN0.3 are independent single-ended inputs
1: AIN0.2, AIN0.3 are (respectively) +, - difference input pair
Bit0: AIN01IC: AIN0.0, AIN0.1 Input Pair Configuration Bit
0: AIN0.0 and AIN0.1 are independent single-ended inputs
1: AIN0.0, AIN0.1 are (respectively) +, - difference input pair
NOTE: The ADC0 Data Word is in 2’s complement format for channels configured as difference.
R R R R R/W R/W R/W R/W Reset Value
- - - - PORT3IC HVDA2C AIN23IC AIN01IC 00000000
Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
SFR
Address:
SFR Address:
SFR Page:
0xBA
0
Bits7-4: UNUSED. Read = 0000b; Write = don’t care
Bits3-0: AMX0AD3-0: AMX0 Address Bits
0000-1111b: ADC Inputs selected per Table 5.1.
R R R R R/W R/W R/W R/W Reset Value
- - - - AMX0AD3 AMX0AD2 AMX0AD1 AMX0AD0 00000000
Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
SFR Address:
SFR Page:
0xBB
0
C8051F040/1/2/3/4/5/6/7
50 Rev. 1.5
Note: “P3EVEN” denotes even numbered and “P3ODD” odd numbered Port 3 pins selected in the AMX0PRT
register.
Table 5.1. AMUX Selection Chart (AMX0AD3–0 and AMX0CF3–0 bits)
AMX0AD3-0
0000 0001 0010 0011 0100 0101 0110 0111 1xxx
AMX0CF Bits 3-0
0000
AIN0.0 AIN0.1 AIN0.2 AIN0.3 HVDA AGND P3EVEN P3ODD
TEMP
SENSO
R
0001
+(AIN0.0)
-(AIN0.1)
AIN0.2 AIN0.3 HVDA AGND P3EVEN P3ODD
TEMP
SENSO
R
0010
AIN0.0 AIN0.1
+(AIN0.2)
-(AIN0.3)
HVDA AGND P3EVEN P3ODD
TEMP
SENSO
R
0011
+(AIN0.0)
-(AIN0.1)
+(AIN0.2)
-(AIN0.3)
HVDA AGND P3EVEN P3ODD
TEMP
SENSOR
0100
AIN0.0 AIN0.1 AIN0.2 AIN0.3
+(HVDA)
-(HVREF)
P3EVEN P3ODD
TEMP
SENSO
R
0101
+(AIN0.0)
-(AIN0.1)
AIN0.2 AIN0.3
+(HVDA)
-(HVREF)
P3EVEN P3ODD
TEMP
SENSOR
0110
AIN0.0 AIN0.1
+(AIN0.2)
-(AIN0.3)
+(HVDA)
-(HVREF)
P3EVEN P3ODD
TEMP
SENSO
R
0111
+(AIN0.0)
-(AIN0.1)
+(AIN0.2)
-(AIN0.3)
+(HVDA)
-(HVREF)
P3EVEN P3ODD
TEMP
SENSO
R
1000
AIN0.0 AIN0.1 AIN0.2 AIN0.3 HVDA AGND
+P3EVEN
-P3ODD
TEMP
SENSO
R
1001
+(AIN0.0)
-(AIN0.1)
AIN0.2 AIN0.3 HVDA AGND
+P3EVEN
-P3ODD
TEMP
SENSO
R
1010
AIN0.0 AIN0.1
+(AIN0.2)
-(AIN0.3)
HVDA AGND
+P3EVEN
-P3ODD
TEMP
SENSO
R
1011
+(AIN0.0)
-(AIN0.1)
+(AIN0.2)
-(AIN0.3)
HVDA AGND
+P3EVEN
-P3ODD
TEMP
SENSO
R
1100
AIN0.0 AIN0.1 AIN0.2 AIN0.3
+(HVDA)
-(HVREF)
+P3EVEN
-P3ODD)
TEMP
SENSO
R
1101
+(AIN0.0)
-(AIN0.1)
AIN0.2 AIN0.3
+(HVDA)
-(HVREF)
+P3EVEN
-P3ODD
TEMP
SENSOR
1110
AIN0.0 AIN0.1
+(AIN0.2)
-(AIN0.3)
+(HVDA)
-(HVREF)
+P3EVEN
-P3ODD
TEMP
SENSO
R
1111
+(AIN0.0)
-(AIN0.1)
+(AIN0.2)
-(AIN0.3)
+(HVDA)
-(HVREF)
+P3EVEN
-P3ODD
TEMP
SENSOR
C8051F040/1/2/3/4/5/6/7
Rev. 1.5 51
SFR Definition 5.3. AMX0PRT: Port 3 Pin Selection
Bit7: PAIN7EN: Pin 7 Analog Input Enable Bit
0: P3.7 is not selected as an analog input to the AMUX.
1: P3.7 is selected as an analog input to the AMUX.
Bit6: PAIN6EN: Pin 6 Analog Input Enable Bit
0: P3.6 is not selected as an analog input to the AMUX.
1: P3.6 is selected as an analog input to the AMUX.
Bit5: PAIN5EN: Pin 5 Analog Input Enable Bit
0: P3.5 is not selected as an analog input to the AMUX.
1: P3.5 is selected as an analog input to the AMUX.
Bit4: PAIN4EN: Pin 4 Analog Input Enable Bit
0: P3.4 is not selected as an analog input to the AMUX.
1: P3.4 is selected as an analog input to the AMUX.
Bit3: PAIN3EN: Pin 3 Analog Input Enable Bit
0: P3.3 is not selected as an analog input to the AMUX.
1: P3.3 is enabled as an analog input to the AMUX.
Bit2: PAIN2EN: Pin 2 Analog Input Enable Bit
0: P3.2 is not selected as an analog input to the AMUX.
1: P3.2 is enabled as an analog input to the AMUX.
Bit1: PAIN1EN: Pin 1 Analog Input Enable Bit
0: P3.1 is not selected as an analog input to the AMUX.
1: P3.1 is enabled as an analog input to the AMUX.
Bit0: PAIN0EN: Pin 0 Analog Input Enable Bit
0: P3.0 is not selected as an analog input to the AMUX.
1: P3.0 is enabled as an analog input to the AMUX.
Note:Any number of Port 3 pins may be selected simultaneously inputs to the AMUX. Odd numbered and even
numbered pins that are selected simultaneously are shorted together as “wired-OR”.
R/W R/W R/W R/W R/W R/W R/W R/W Reset Value
PAIN7EN PAIN6EN PAIN5EN PAIN4EN PAIN3EN PAIN2EN PAIN1EN PAIN0EN 00000000
Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
SFR Address:
SFR Page:
0xBD
0
