C8051F041-GQ

Part # C8051F041-GQ
Description MCU 8BIT CISC 64KB FLASH 3V 64TQFP - Trays
Category IC
Availability In Stock
Qty 2
Qty Price
1 + $20.05559
Manufacturer Available Qty
SILICON LABORATORIES
Date Code: 0903
  • Shipping Freelance Stock: 2
    Ships Immediately



Technical Document


DISCLAIMER: The information provided herein is solely for informational purposes. Customers must be aware of the suitability of this product for their application, and consider that variable factors such as Manufacturer, Product Category, Date Codes, Pictures and Descriptions may differ from available inventory.

C8051F040/1/2/3/4/5/6/7
40 Rev. 1.5
P3.0/AD0/D0 54 47 A In
D I/O
Bit 0 External Memory Address/Data bus (Multiplexed
mode)
Bit 0 External Memory Data bus (Non-multiplexed mode)
Port 3.0
See Port Input/Output section for complete description.
ADC0 Input. (See ADC0 Specification for
complete
description.)
P3.1/AD1/D1 53 46 A In
D I/O
Port 3.1. See Port Input/Output section for complete
de
scription.
ADC0 Input. (See ADC0 Specification for
complete
description.)
P3.2/AD2/D2 52 45 A In
D I/O
Port 3.2. See Port Input/Output section for complete
de
scription.
ADC0 Input. (See ADC0 Specification for
complete
description.)
P3.3/AD3/D3 51 44 A In
D I/O
Port 3.3. See Port Input/Output section for complete
de
scription.
ADC0 Input. (See ADC0 Specification for
complete
description.)
P3.4/AD4/D4 50 43 A In
D I/O
Port 3.4. See Port Input/Output section for complete
de
scription.
ADC0 Input. (See ADC0 Specification for
complete
description.)
P3.5/AD5/D5 49 42 A In
D I/O
Port 3.5. See Port Input/Output section for complete
de
scription.
ADC0 Input. (See ADC0 Specification for
complete
description.)
P3.6/AD6/D6 48 39 A In
D I/O
Port 3.6. See Port Input/Output section for complete
de
scription.
ADC0 Input. (See ADC0 Specification for
complete
description.)
P3.7/AD7/D7 47 38 A In
D I/O
Port 3.7. See Port Input/Output section for complete
de
scription.
ADC0 Input. (See ADC0 Specification for
complete
description.)
P4.0 98 D I/O Port 4.0. See Port Input/Output section for complete
de
scription.
P4.1 97 D I/O Port 4.1. See Port Input/Output section for complete
de
scription.
P4.2 96 D I/O Port 4.2. See Port Input/Output section for complete
de
scription.
P4.3 95 D I/O Port 4.3. See Port Input/Output section for complete
de
scription.
Table 4.1. Pin Definitions (Continued)
Name
Pin Numbers
Type Description
F040/2/4/6 F041/3/5/7
C8051F040/1/2/3/4/5/6/7
Rev. 1.5 41
P4.4 94 D I/O Port 4.4. See Port Input/Output section for complete
description.
P4.5/ALE 93 D I/O ALE Strobe for External Memory Address bus (multi-
plexed mode)
Port 4.5
See Port Input/Output section for complete description.
P4.6/RD 92 D I/O /RD Strobe for External Memory Address bus
Port 4.6
See Port Input/Output section for complete description.
P4.7/WR 91 D I/O /WR Strobe for External Memory Address bus
Port 4.7
See Port Input/Output section for complete description.
P5.0/A8 88 D I/O Bit 8 External Memory Address bus (Non-multiplexed
mo
de)
Port 5.0
See Port Input/Output section for complete description.
P5.1/A9 87 D I/O Port 5.1. See Port Input/Output section for complete
de
scription.
P5.2/A10 86 D I/O Port 5.2. See Port Input/Output section for complete
de
scription.
P5.3/A11 85 D I/O Port 5.3. See Port Input/Output section for complete
de
scription.
P5.4/A12 84 D I/O Port 5.4. See Port Input/Output section for complete
de
scription.
P5.5/A13 83 D I/O Port 5.5. See Port Input/Output section for complete
de
scription.
P5.6/A14 82 D I/O Port 5.6. See Port Input/Output section for complete
de
scription.
P5.7/A15 81 D I/O Port 5.7. See Port Input/Output section for complete
de
scription.
P6.0/A8m/A0 80 D I/O Bit 8 External Memory Address bus (Multiplexed mode)
Bit 0 External Memory Address bus (Non-multiplexed
mo
de)
Port 6.0
See Port Input/Output section for complete description.
P6.1/A9m/A1 79 D I/O Port 6.1. See Port Input/Output section for complete
de
scription.
P6.2/A10m/A2 78 D I/O Port 6.2. See Port Input/Output section for complete
de
scription.
P6.3/A11m/A3 77 D I/O Port 6.3. See Port Input/Output section for complete
de
scription.
Table 4.1. Pin Definitions (Continued)
Name
Pin Numbers
Type Description
F040/2/4/6 F041/3/5/7
C8051F040/1/2/3/4/5/6/7
42 Rev. 1.5
P6.4/A12m/A4 76 D I/O Port 6.4. See Port Input/Output section for complete
description.
P6.5/A13m/A5 75 D I/O Port 6.5. See Port Input/Output section for complete
de
scription.
P6.6/A14m/A6 74 D I/O Port 6.6. See Port Input/Output section for complete
de
scription.
P6.7/A15m/A7 73 D I/O Port 6.7. See Port Input/Output section for complete
de
scription.
P7.0/AD0/D0 72 D I/O Bit 0 External Memory Address/Data bus (Multiplexed
mo
de)
Bit 0 External Memory Data bus (Non-multiplexed mode)
Port 7.0
See Port Input/Output section for complete description.
P7.1/AD1/D1 71 D I/O Port 7.1. See Port Input/Output section for complete
de
scription.
P7.2/AD2/D2 70 D I/O Port 7.2. See Port Input/Output section for complete
de
scription.
P7.3/AD3/D3 69 D I/O Port 7.3. See Port Input/Output section for complete
de
scription.
P7.4/AD4/D4 68 D I/O Port 7.4. See Port Input/Output section for complete
de
scription.
P7.5/AD5/D5 67 D I/O Port 7.5. See Port Input/Output section for complete
de
scription.
P7.6/AD6/D6 66 D I/O Port 7.6. See Port Input/Output section for complete
de
scription.
P7.7/AD7/D7 65 D I/O Port 7.7. See Port Input/Output section for complete
de
scription.
Table 4.1. Pin Definitions (Continued)
Name
Pin Numbers
Type Description
F040/2/4/6 F041/3/5/7
