C8051F040/1/2/3/4/5/6/7
Rev. 1.5 37
4. Pinout and Package Definitions
Table 4.1. Pin Definitions
Name
Pin Numbers
Type Description
F040/2/4/6 F041/3/5/7
V
DD
37, 64, 90 24, 41, 57 Digital Supply Voltage. Must be tied to +2.7 to +3.6 V.
DGND 38, 63, 89 25, 40, 56 Digital Ground. Must be tied
to Ground.
AV+ 8, 11, 14 3, 6 Analog Supply Voltage. Must be tied to +2.7 to +3.6 V.
AGND 9, 10, 13 4, 5 Analog Ground. Must be tied to Ground.
TMS 1 58 D In JTAG Test Mode Select with internal pullup.
TCK 2 59 D In JTAG Test Clock with internal pullup.
TDI 3 60 D In JTAG Test Data Input with internal pullup. TDI
is latched
on the rising edge of TCK.
TDO 4 61 D Out JTAG Test Data Output with internal pullup. Data is
shif
ted out on TDO on the falling edge of TCK. TDO out-
put is a tri-state driver.
/RST 5 62 D I/O Device Reset. Open-drain outpu
t of internal V
DD
monitor.
Is driven low when V
DD
is < 2.7 V and MONEN is high. An
external source can initiate a system reset by driving this
pin low.
XTAL1 26 17 A In Crystal Input. This pin is the return for the internal
oscilla-
tor circuit for a crystal or ceramic resonator. For a preci-
sion internal clock, connect a
crystal or ceramic resonator
from XTAL1 to XTAL2. If overdriven by an external CMOS
clock, this becomes the system clock.
XTAL2 27 18 A Out Crystal Output. This pin is the excitation driver for a crystal
or ceramic
resonator.
MONEN 28 19 D In V
DD
Monitor Enable. When tied high, this pin enables the
internal V
DD
monitor, which forces a system reset when
V
DD
is < 2.7 V. When tied low, the internal V
DD
monitor is
disabled.
In most applications, MONEN should be connected
di
rectly to V
DD
.
VREF 12 7 A I/O Bandgap Voltage Reference Output (all devices).
DAC Voltage Reference Input (C8051F041/3 only).
VREFA 8 A In ADC0 (C8051F041/3/5/7) and ADC2 (C8051F041/3 only)
Voltage Reference Input.
VREF0 16 A In ADC0 Voltage Reference Input.
VREF2 17 A In ADC2 Voltage Reference Input (C8051F040/2 only).
VREF 15 A In DAC Voltage Reference Input (C8051F040/2 only).
AIN0.0 18 9 A In ADC0 Input Channel 0 (See ADC0 Specification for com-
plete description).
C8051F040/1/2/3/4/5/6/7
38 Rev. 1.5
AIN0.1 19 10 A In ADC0 Input Channel 1 (See ADC0 Specification for com-
plete description).
AIN0.2 20 11 A In ADC0 Input Channel 2 (See ADC0 Specification for com-
plete description).
AIN0.3 21 12 A In ADC0 Input Channel 3 (See ADC0 Specification for com-
plete description).
HVCAP 22 13 A I/O High Voltage Difference Amplifier Capacitor.
HVREF 23 14 A In High Voltage Difference Amplifier Bias Reference.
HVAIN+ 24 15 A In High Voltage Difference Amplifier Positive Signal
Input.
HVAIN- 25 16 A In High Voltage Difference Amplifie
r Negative Signal Input.
CANTX 7 2 D Out Controller Area Network Transmit Output.
CANRX 6 1 D In Controller Area Network Receive Input.
DAC0 100 64 A Out Digital to Analog Converter 0 Voltage Output. (See DAC
S
pecification for complete description). (C8051F040/1/2/3
only)
DAC1 99 63 A Out Digital to Analog Converter 1 Voltage Output. (See DAC
S
pecification for complete description). (C8051F040/1/2/3
only)
P0.0 62 55 D I/O Port 0.0. See Port Input/Output section for complete
de
scription.
P0.1 61 54 D I/O Port 0.1. See Port Input/Output section for complete
de
scription.
P0.2 60 53 D I/O Port 0.2. See Port Input/Output section for complete
de
scription.
P0.3 59 52 D I/O Port 0.3. See Port Input/Output section for complete
de
scription.
P0.4 58 51 D I/O Port 0.4. See Port Input/Output section for complete
de
scription.
P0.5/ALE 57 50 D I/O ALE Strobe for External Memory Address bus (multi-
plexed mode) Port 0.5
See Port Input/Output section for complete description.
P0.6/RD 56 49 D I/O /RD Strobe for External Memory Address bus
Port 0.6
See Port Input/Output section for complete description.
P0.7/WR 55 48 D I/O /WR Strobe for External Memory Address bus
Port 0.7
See Port Input/Output section for complete description.
Table 4.1. Pin Definitions (Continued)
Name
Pin Numbers
Type Description
F040/2/4/6 F041/3/5/7
C8051F040/1/2/3/4/5/6/7
Rev. 1.5 39
P1.0/AIN2.0/A8 36 29 A In
D I/O
ADC1 Input Channel 0 (See ADC1 Specification for com-
plete description).
Bit 8 External Memory Address bus (Non-multiplexed
mo
de)
Port 1.0
See Port Input/Output section for complete description.
P1.1/AIN2.1/A9 35 28 A In
D I/O
Port 1.1. See Port Input/Output section for complete
de
scription.
P1.2/AIN2.2/
A10
34 27 A In
D I/O
Port 1.2. See Port Input/Output section for complete
de
scription.
P1.3/AIN2.3/
A1
1
33 26 A In
D I/O
Port 1.3. See Port Input/Output section for complete
description.
P1.4/AIN2.4/
A12
32 23 A In
D I/O
Port 1.4. See Port Input/Output section for complete
de
scription.
P1.5/AIN2.5/
A13
31 22 A In
D I/O
Port 1.5. See Port Input/Output section for complete
de
scription.
P1.6/AIN2.6/
A14
30 21 A In
D I/O
Port 1.6. See Port Input/Output section for complete
de
scription.
P1.7/AIN2.7/
A15
29 20 A In
D I/O
Port 1.7. See Port Input/Output section for complete
de
scription.
P2.0/A8m/A0 46 37 D I/O Bit 8 External Memory Address bus (Multiplexed mode)
Bit 0 External Memory Address bus (Non-multiplexed
mo
de) Port 2.0
See Port Input/Output section for complete description.
P2.1/A9m/A1 45 36 D I/O Port 2.1. See Port Input/Output section for complete
de
scription.
P2.2/A10m/A2 44 35 D I/O Port 2.2. See Port Input/Output section for complete
de
scription.
P2.3/A11m/A3 43 34 D I/O Port 2.3. See Port Input/Output section for complete
de
scription.
P2.4/A12m/A4 42 33 D I/O Port 2.4. See Port Input/Output section for complete
de
scription.
P2.5/A13m/A5 41 32 D I/O Port 2.5. See Port Input/Output section for complete
de
scription.
P2.6/A14m/A6 40 31 D I/O Port 2.6. See Port Input/Output section for complete
de
scription.
P2.7/A15m/A7 39 30 D I/O Port 2.7. See Port Input/Output section for complete
de
scription.
Table 4.1. Pin Definitions (Continued)
Name
Pin Numbers
Type Description
F040/2/4/6 F041/3/5/7
