SLUS553D − MAY 2003 − REVISED JULY 2005
3
www.ti.com
Table 1. Available Options
SELECTOR OPERATION
−20°C ≤ T
J
≤ 125°C
bq24702PW bq24703RHD
Battery as Power Source
Battery removal Automatically selects ac + alarm Automatically selects ac + alarm
Battery reinserted Selection based on selector inputs
Adapter latched until adapter is removed or ac select
toggles.
AC as Power Source
AC removal Automatically selects battery Automatically selects battery
AC reinserted Selection based on selector inputs Selection based on selector inputs
Depleted Battery Condition
Battery as power source Sends ALARM signal
Automatically selects ac
Sends ALARM signal
AC as power source Sends ALARM signal Sends ALARM signal
ALARM Signal Active
Depleted battery condition Depleted battery condition
When selector input is not equal to selector
output (single pulse alarm)
ABSOLUTE MAXIMUM RATINGS OVER OPERATING FREE-AIR TEMPERATURE
(unless otherwise noted)
Ĕ}
Supply voltage range: VCC −0.3 V to 30 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Battery voltage range: SRP, SRN −0.3 V to 30 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Input voltage: ACN, ACP −0.3 V to 30 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Virtual junction temperature range, T
J
−40°C to 125°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maximum source/sink current VHSP 50 mA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maximum ramp rate for V
CC
10 V/ µs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maximum sink current ACPRES, COMP, ALARM 2.5 mA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maximum ramp rate for V
(BAT)
10 V/ µs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maximum source/sink current BATDRV
10 mA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maximum source/sink current ACDRV
10 mA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maximum source/sink current PWM
50 mA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maximum source/sink current pulsed ACDRV
, (10-µs rise time, 10-µs fall time, 1-ms pulse width, single pulse) 50 mA
Maximum source current VREF 30 mA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maximum source current SRP 100 mA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maximum difference voltage SRP − SRN 30 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage temperature range T
stg
−65°C to 150°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lead temperature (soldering, 10 seconds) 300°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
†
Stresses beyond those listed under “absolute maximum ratings” may cause permanent damage to the device. These are stress ratings only, and
functional operation of the device at these or any other conditions beyond those indicated under “recommended operating conditions” is not
implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
‡
All voltages are with respect to ground. Currents are positive into and negative out of the specified terminals. Consult the Packaging section of
the data book for thermal limitations and considerations of the package.
