The UDORDn bit in UCSRnC sets the frame format used by the USART in MSPIM mode. The

Receiver and Transmitter use the same setting. Note that changing the setting of any of these

bits will corrupt all ongoing communication for both the Receiver and Transmitter.

16-bit data transfer can be achieved by writing two data bytes to UDRn. A UART transmit com-

plete interrupt will then signal that the 16-bit value has been shifted out.

20.5.1 USART MSPIM Initialization

The USART in MSPIM mode has to be initialized before any communication can take place. The

initialization process normally consists of setting the baud rate, setting master mode of operation

(by setting DDR_XCKn to one), setting frame format and enabling the Transmitter and the

Receiver. Only the transmitter can operate independently. For interrupt driven USART opera-

tion, the Global Interrupt Flag should be cleared (and thus interrupts globally disabled) when

doing the initialization.

Note: To ensure immediate initialization of the XCKn output the baud-rate register (UBRRn) must be

zero at the time the transmitter is enabled. Contrary to the normal mode USART operation the

UBRRn must then be written to the desired value after the transmitter is enabled, but before the

first transmission is started. Setting UBRRn to zero before enabling the transmitter is not neces-

sary if the initialization is done immediately after a reset since UBRRn is reset to zero.

Before doing a re-initialization with changed baud rate, data mode, or frame format, be sure that

there is no ongoing transmissions during the period the registers are changed. The TXCn Flag

can be used to check that the Transmitter has completed all transfers, and the RXCn Flag can

be used to check that there are no unread data in the receive buffer. Note that the TXCn Flag

must be cleared before each transmission (before UDRn is written) if it is used for this purpose.

The following simple USART initialization code examples show one assembly and one C func-

tion that are equal in functionality. The examples assume polling (no interrupts enabled). The

203

2545M–AVR–09/07

ATmega48/88/168

baud rate is given as a function parameter. For the assembly code, the baud rate parameter is

assumed to be stored in the r17:r16 registers.

Note: 1. See ”About Code Examples” on page 9.

Assembly Code Example

(1)

USART_Init:

clr r18

out UBRRnH,r18

out UBRRnL,r18

; Setting the XCKn port pin as output, enables master mode.

sbi XCKn_DDR, XCKn

; Set MSPI mode of operation and SPI data mode 0.

ldi r18, (1<<UMSELn1)|(1<<UMSELn0)|(0<<UCPHAn)|(0<<UCPOLn)

out UCSRnC,r18

; Enable receiver and transmitter.

ldi r18, (1<<RXENn)|(1<<TXENn)

out UCSRnB,r18

; Set baud rate.

; IMPORTANT: The Baud Rate must be set after the transmitter is enabled!

out UBRRnH, r17

out UBRRnL, r18

ret

C Code Example

(1)

void USART_Init( unsigned int baud )

{

UBRRn = 0;

/* Setting the XCKn port pin as output, enables master mode. */

XCKn_DDR |= (1<<XCKn);

/* Set MSPI mode of operation and SPI data mode 0. */

UCSRnC = (1<<UMSELn1)|(1<<UMSELn0)|(0<<UCPHAn)|(0<<UCPOLn);

/* Enable receiver and transmitter. */

UCSRnB = (1<<RXENn)|(1<<TXENn);

/* Set baud rate. */

/* IMPORTANT: The Baud Rate must be set after the transmitter is enabled

UBRRn = baud;

}

204

2545M–AVR–09/07

ATmega48/88/168

20.6 Data Transfer

Using the USART in MSPI mode requires the Transmitter to be enabled, i.e. the TXENn bit in

the UCSRnB register is set to one. When the Transmitter is enabled, the normal port operation

of the TxDn pin is overridden and given the function as the Transmitter's serial output. Enabling

the receiver is optional and is done by setting the RXENn bit in the UCSRnB register to one.

When the receiver is enabled, the normal pin operation of the RxDn pin is overridden and given

the function as the Receiver's serial input. The XCKn will in both cases be used as the transfer

clock.

After initialization the USART is ready for doing data transfers. A data transfer is initiated by writ-

ing to the UDRn I/O location. This is the case for both sending and receiving data since the

transmitter controls the transfer clock. The data written to UDRn is moved from the transmit

buffer to the shift register when the shift register is ready to send a new frame.

Note: To keep the input buffer in sync with the number of data bytes transmitted, the UDRn register must

be read once for each byte transmitted. The input buffer operation is identical to normal USART

mode, i.e. if an overflow occurs the character last received will be lost, not the first data in the

buffer. This means that if four bytes are transferred, byte 1 first, then byte 2, 3, and 4, and the

UDRn is not read before all transfers are completed, then byte 3 to be received will be lost, and not

byte 1.

The following code examples show a simple USART in MSPIM mode transfer function based on

polling of the Data Register Empty (UDREn) Flag and the Receive Complete (RXCn) Flag. The

USART has to be initialized before the function can be used. For the assembly code, the data to

be sent is assumed to be stored in Register R16 and the data received will be available in the

same register (R16) after the function returns.

The function simply waits for the transmit buffer to be empty by checking the UDREn Flag,

before loading it with new data to be transmitted. The function then waits for data to be present

in the receive buffer by checking the RXCn Flag, before reading the buffer and returning the

value.
