AS215-92, AS215-92LF: Single Positive Control PHEMT
GaAs IC SPDT Switch 0.5–3 GHz
DATA SHEET
Features
●
Single bias control
●
Operates with 1.8 V control voltage
●
Low DC power consumption
●
Available lead (Pb)-free and RoHS-compliant MSL-1 @ 260 °C
per JEDEC J-STD-020
Description
The AS215-92 is a medium-power IC FET SPDT switch in a low-
cost, miniature SC-70 6-lead plastic package. The AS215-92
features low insertion loss and positive voltage operation with
very low DC power consumption. This general-purpose switch
can be used in a variety of telecommunications applications.
Parameter Frequency Min. Typ. Max. Unit
Insertion loss
(1)
0.5–1 GHz 0.75 1.0 dB
1.0–2 GHz 0.60 0.8 dB
2.0–3 GHz 0.50 0.7 dB
Isolation 0.5–1 GHz 25 28 dB
1.0–2 GHz 21 24 dB
2.0–3 GHz 17 20 dB
VSWR
(2)
0.5–1 GHz 1.1:1
1.0–2 GHz 1.4:1
2.0–3 GHz 1.2:1
Electrical Specifications
V
S
= 3 V, V
CTL
= 0/3 V, Z
0
= 50 Ω, unless otherwise noted
Applications
●
T/R switch for Bluetooth
TM
and general-purpose
telecommunication applications
1 2 3
6 5 4
J
1
GND
C
BL
C
BL
C
BL
J
2
J
3
V
CTL
V
SS
D
C blocking capacitors (C
BL
)
must be supplied externally for positive voltage operation.
C
BL
= 100 pF for operation >500 MHz.
Pin Out
1. Insertion loss changes by 0.003 dB/°C.
2. Insertion loss state.
Skyworks offers lead (Pb)-free, RoHS (Restriction of
Hazardous Substances)-compliant packaging.
