2-WIRE SERIAL REGISTER MAP
The AD9880 is initialized and controlled by a set of registers that determines the operating modes. An external controller is employed to
write and read the control registers through the 2-wire serial interface port.
Table 11. Control Register Map
Hex
Address
Read/Write
or Read Only
Bits
Default
Value
Register Name Description
0x00 Read [7:0] 00000000 Chip Revision Chip revision ID. Revision is read [7:4]. [3:0].
0x01 Read/Write [7:0] 01101001 PLL Divider MSB PLL feedback divider value MSB.
0x02 Read/Write [7:4] 1101**** PLL Divider PLL feedback divider value.
0x03 Read/Write [7:6] 01****** VCO Range VCO range.
[5:3] **001*** Charge Pump Charge pump current control for PLL.
[2] *****0** External Clock Enable
Selects the external clock input rather that the internal PLL
clock.
0x04 Read/Write [7:3] 10000*** Phase Adjust Selects the clock phase to use for the ADC clock.
0x05 Read/Write [7:0] 10000000 Red Gain
Controls the gain of the red channel PGA. 0 = low gain,
255 = high gain.
0x06 Read/Write [7:0] 10000000 Green Gain
Controls the gain of the green channel PGA. 0 = low gain,
255 = high gain.
0x07 Read/Write [7:0] 10000000 Blue Gain
Controls the gain of the blue channel PGA. 0 = low gain,
255 = high gain.
0x08 Read/Write [7:0] 00000000 Red Offset Adjust User adjustment of auto offset. Allows user control of brightness.
0x09 Read/Write [7:0] 10000000 Red Offset Red offset/target code. 0 = small offset, 255 = large offset.
0x0A Read/Write [7:0] 00000000 Green Offset Adjust User adjustment of auto offset. Allows user control of brightness.
0x0B Read/Write [7:0] 10000000 Green Offset Green offset/target code. 0 = small offset, 255 = large offset.
0x0C Read/Write [7:0] 00000000 Blue Offset Adjust User adjustment of auto offset. Allows user control of brightness.
0x0D Read/Write [7:0] 10000000 Blue Offset Blue offset/target code. 0 = small offset, 255 = large offset.
0x0E Read/Write [7:0] 00100000
Sync Separator
Threshold
Selects the maximum Hsync pulse width for composite sync
separation.
0x0F Read/Write [7:2] 010000**
SOG Comparator
Threshold Enter
The enter level for the SOG slicer. Must be less than or equal to
the exit level.
0x10 Read/Write [7:2] 010000**
SOG Comparator
Threshold Exit
The exit level for the SOG slicer. Must be greater than or equal to
the enter level.
0x11 Read/Write [7] 0******* Hsync Source 0 = Hsync.
1 = SOG.
[6] *0******
Hsync Source
Override
0 = auto Hsync source.
1 = manual Hsync source.
[5] **0***** Vsync Source 0 = Vsync.
1 = Vsync from SOG.
[4] ***0****
Vsync Source
Override
0 = auto Hsync source.
1 = manual Hsync source.
[3] ****0*** Channel Select 0 = Channel 0.
1 = Channel 1.
[2] *****0**
Channel Select
Override
0 = autochannel select.
1 = manual channel select.
[1] ******0* Interface Select 0 = analog interface.
1 = digital interface.
[0] *******0 Interface Override 0 = auto-interface select.
1 = manual interface select.
