AD9880
Rev. 0 | Page 61 of 64
Table 102. RGB (0 to 255) to HDTV YCrCb (0 to 255)
Register Red/Cr Coeff 1 Red/Cr Coeff 2 Red/Cr Coeff Red/Cr Offset
Address
0x35 0x36 0x37 0x38 0x39 0x3A 0x3B 0x3C
Value 0x08 0x2D 0x18 0x93 0x1F 0x3F 0x08 0x00
Register Green/Y Coeff 1 Green/Y Coeff 2 Green/Y Coeff 3 Green/Y Offset
Address
0x3D 0x3E 0x3F 0x40 0x41 0x42 0x43 0x44
Value 0x03 0x68 0x0B 0x71 0x01 0x27 0x00 0x00
Register Blue/Cb Coeff 1 Blue/Cb Coeff 2 Blue/Cb Coeff 3 Blue/Cb Offset
Address
0x45 0x46 0x47 0x48 0x49 0x4A 0x4B 0x4C
Value 0x1E 0x21 0x19 0xB2 0x08 0x2D 0x08 0x00
Table 103. RGB (0 to 255) to HDTV YCrCb (16 to 235)
Register
Red/Cr Coeff 1 Red/Cr Coeff 2 Red/Cr Coeff 3 Red/Cr Offset
Address
0x35 0x36 0x37 0x38 0x39 0x3A 0x3B 0x3C
Value
0x07 0x06 0x19 0xA0 0x1F 0x5B 0x08 0x00
Register
Green/Y Coeff 1 Green/Y Coeff 2 Green/Y Coeff 3 Green/Y Offset
Address
0x3D 0x3E 0x3F 0x40 0x41 0x42 0x43 0x44
Value
0x02 0xED 0x09 0xD3 0x00 0xFD 0x01 0x00
Register
Blue/Cb Coeff 1 Blue/Cb Coeff 2 Blue/Cb Coeff 3 Blue/Cb Offset
Address
0x45 0x46 0x47 0x48 0x49 0x4A 0x4B 0x4C
Value
0x1E 0x64 0x1A 0x96 0x07 0x06 0x08 0x00
Table 104. RGB (0 to 255) to SDTV YCrCb (0 to 255)
Register Red/Cr Coeff 1 Red/Cr Coeff 2 Red/Cr Coeff 3 Red/Cr Offset
Address
0x35 0x36 0x37 0x38 0x39 0x3A 0x3B 0x3C
Value
0x08 0x2D 0x19 0x27 0x1E 0xAC 0x08 0x00
Register Green/Y Coeff 1 Green/Y Coeff 2 Green/Y Coeff 3 Green/Y Offset
Address
0x3D 0x3E 0x3F 0x40 0x41 0x42 0x43 0x44
Value
0x04 0xC9 0x09 0x64 0x01 0xD3 0x00 0x00
Register Blue/Cb Coeff 1 Blue/Cb Coeff 2 Blue/Cb Coeff 3 Blue/Cb Offset
Address
0x45 0x46 0x47 0x48 0x49 0x4A 0x4B 0x4C
Value
0x1D 0x3F 0x1A 0x93 0x08 0x2D 0x08 0x00
Table 105. RGB (0 to 255) to SDTV YCrCb (16 to 235)
Register Red/Cr Coeff 1 Red/Cr Coeff 2 Red/Cr Coeff 3 Red/Cr Offset
Address
0x35 0x36 0x37 0x38 0x39 0x3A 0x3B 0x3C
Value
0x07 0x06 0x1A 0x1E 0x1E 0xDC 0x08 0x00
Register Green/Y Coeff 1 Green/Y Coeff 2 Green/Y Coeff 3 Green/Y Offset
Address
0x3D 0x3E 0x3F 0x40 0x41 0x42 0x43 0x44
Value
0x04 0x1C 0x08 0x11 0x01 0x91 0x01 0x00
Register Blue/Cb Coeff 1 Blue/Cb Coeff 2 Blue/Cb Coeff 3 Blue/Cb Offset
Address
0x45 0x46 0x47 0x48 0x49 0x4A 0x4B 0x4C
Value
0x1D 0xA3 0x1B 0x57 0x07 0x06 0x08 0x00
