AD9880
Rev. 0 | Page 52 of 64
0x8D 7-0 Active Pixel End LSB
Combined with the MSB in Register 0x8E these bits
indicate the last active video pixel in the display. All
pixels past this comprise a right vertical bar. If the
2-byte value is greater than the number of pixels in the
display, there is no vertical bar.
0x8E 7-0 Active Pixel End MSB
See Register 0x8D.
0x8F 6-0 NDF
See Register 0x87.
0x90 7-0 Audio Infoframe Version
0x91 7-4 Audio Coding Type
These bits identify the audio coding so that the
receiver may process audio properly.
Table 88.
CT [3:0] Audio Coding
0x0 Refer to stream header
0x1 IEC60958 PCM
0x2 AC-3
0x3 MPEG1 (Layers 1 and 2)
0x4 MP3 (MPEG1 Layer 3)
0x5 MPEG2 (multichannel)
0x6 AAC
0x7 DTS
0x8 ATRAC
0x91 2-0 Audio Channel Count
These bits specify how many audio channels are being
sent—2 channels to 8 channels.
Table 89.
CC [2:0] Channel Count
000 Refer to stream header
001 2
010 3
011 4
100 5
101 6
110 7
111 8
0x92 4-2 Sampling Frequency
0x92 1-0 Ample Size
0x93 7-0 Max Bit Rate
For compressed audio only when this value is
multiplied by 8 kHz represents the maximum bit rate.
A value of 0x08 in this field would yield a maximum
bit rate of (8 kHz × 8 kHz = 64 kHz).
0x94 7-0 Speaker Mapping
These bits define the mapping (suggested placement)
of speakers.
Table 90.
Abbreviation Speaker Placement
FL Front left
FC Front center
FR Front right
FCL Front center left
FCR Front center right
RL Rear left
RC Rear center
RR Rear right
RCL Rear center left
RCR Rear center right
LFE Low frequency effect
AD9880
Rev. 0 | Page 53 of 64
Table 91.
CA Channel Number
Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Bit 8 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1
0 0 0 0 0
– – FR FL
0 0 0 0 1
– LFE FR FL
0 0 0 1 0
FC – FR FL
0 0 0 1 1
FC LFE FR FL
0 0 1 0 0
RC – FR FL
0 0 1 0 1
RC – LFE FR FL
0 0 1 1 0
RC FC FR FL
0 0 1 1 1
RC FC LFE FR FL
0 1 0 0 0
RR RL FR FL
0 1 0 0 1
RR RL LFE FR FL
0 1 0 1 0
RR RL FC FR FL
0 1 0 1 1 – RR RL FC LFE FR FL
0 1 1 0 0 – RC RR RL FR FL
0 1 1 0 1 – RC RR RL LFE FR FL
0 1 1 1 0 – RC RR RL FC FR FL
0 1 1 1 1 – RC RR RL FC LFE FR FL
1 0 0 0 0 RRC RLC RR RL FR FL
1 0 0 0 1 RRC RLC RR RL LFE FR FL
1 0 0 1 0 RRC RLC RR RL FC FR FL
1 0 0 1 1 RRC RLC RR RL FC LFE FR FL
1 0 1 0 0 FRC FLC v FR FL
1 0 1 0 1 FRC FLC v LFE FR FL
1 0 1 1 0 FRC FLC FC FR FL
1 0 1 1 1 FRC FLC FC LFE FR FL
1 1 0 0 0 FRC FLC RC FR FL
1 1 0 0 1 FRC FLC RC LFE FR FL
1 1 0 1 0 FRC FLC RC FC FR FL
1 1 0 1 1 FRC FLC RC FC LFE FR FL
1 1 1 0 0 FRC FLC RR RL v FR FL
1 1 1 0 1 FRC FLC RR RL LFE FR FL
1 1 1 1 0 FRC FLC RR RL FC FR FL
1 1 1 1 1 FRC FLC RR RL FC LFE FR FL
0x95 7 Down-Mix Inhibit
0x95 6-3 Level Shift Values
These bits define the amount of attenuation. The value
directly corresponds to the amount of attenuation: for
example, 0000 = 0 dB, 0001 = 1 dB to 1111 = 15 dB
attenuation.
0x96 7-0 Reserved
0x97 6-0 New Data Flags
See Register 0x87 for a description.
0x98 7-0 Source Product Description (SPD)
Infoframe Version
0x99 7-0 Vender Name Character 1 (VN1)
This is the first character in eight that is the name of
the company that appears on the product. The data
characters are 7-bit ASCII code.
0x9A 7-0 VN2
0x9B 7-0 VN3
0x9C 7-0 VN4
0x9D 7-0 VN5
0x9E 7-0 VN6
0x9F 6-0 New Data Flags
See Register 0x87 for a description.
AD9880
Rev. 0 | Page 54 of 64
0xA0 7-0 VN7
0xA1 7-0 VN8
0xA2 7-0 Product Description Character 1 (PD1)
This is the first character of 16 which contains the
model number and a short description of the product.
The data characters are 7-bit ASCII code.
0xA3 7-0 PD2
0xA4 7-0 PD3
0xA5 7-0 PD4
0xA6 7-0 PD5
0xA7 6-0 New Data Flags
See Register 0x87 for a description.
0xA8 7-0 PD6
0xA9 7-0 PD7
0xAA 7-0 PD8
0xAB 7-0 PD9
0xAC 7-0 PD10
0xAD 7-0 PD11
0xAE 7-0 PD12
0xAF 6-0 New Data Flags
See Register 0x87 for a description.
0xB0 7-0 PD13
0xB1 7-0 PD14
0xB2 7-0 PD15
0xB3 7-0 PD16
0xB4 7-0 Source Device Information Code
These bytes classify the source device.
Table 92.
SDI Code Source
0x00 Unknown
0x01 Digital STB
0x02 DVD
0x03 D-VHS
0x04 HDD video
0x05 DVC
0x06 DSC
0x07 Video CD
0x08 Game
0x09 PC general
0xB7 6-0 New Data Flags
See Register 0x87 for a description.
0xB8 7-0 MPEG Source Infoframe Version
0xB9 7-0 MPEG Bit Rate Byte 0 (MB0)
This is the lower 8 bits of 32 bits that specify the
MPEG bit rate in Hz.
0xBA 7-0 MB1
0xBB 7-0 MB2
0xBC 7-0 MB3—Upper Byte
0xBD 4 Field Repeat
This defines whether the field is new or repeated.
Table 93.
FR Field Type
0 New field or picture
1 Repeated field
0xBD 1-0 MPEG Frame
This identifies the frame as I, B, or P.
Table 94.
MF [1-0] Frame Type
00 Unknown
01 I—picture
10 B—picture
11 P—picture
0xBE 7-0 Reserved
0xBF 6-0 New Data Flags
See Register 0x87 for a description.
0xC0 7-0 Audio Content Protection Packet (ACP
Type)
These bits define which audio content protection is used.
Table 95.
Code ACP Type
0x00 Generic audio
0x01 IEC 60958-identified audio
0x02 DVD-audio
0x03 Reserved for super audio CD (SACD)
0x04—0xFF Reserved
0xC1 ACP Packet Byte 0 (ACP_PB0)
0xC2 7-0 ACP_PB1
0xC3 7-0 ACP_PB2
0xC4 7-0 ACP_PB3
0xC5 7-0 ACP_PB4
0xC7 6-0 New Data Flags
See Register 0x87 for a description.
0xC8 7 International Standard Recording Code
(ISRC1) Continued
This bit indicates that a continuation of the 16 ISRC1
packet bytes (an ISRC2 packet) is being transmitted.
0xC8 6 ISRC1 Valid
This bit is an indication of the whether ISRC1 packet
bytes are valid.
