AD9880
Rev. 0 | Page 35 of 64
Hex
Address
Read/Write
or Read Only
Bits
Default
Value
Register Name Description
0xBD Read [1:0] MPEG Frame MF [1:0] This identifies whether frame is an I, B, or P picture.
00 = unknown.
01 = I picture.
10 = B picture.
11 = P picture.
0xBE Read [7:0] Reserved.
0xBF Read [6:0] New Data Flags New data flags (see 0x87).
0xC0 Read [7:0] Audio content protection packet (ACP) type.
0x00 = Generic audio.
0x01 = IEC 60958-identified audio.
0x02 = DVD-audio.
0x03 = Reserved for super audio CD (SACD).
Audio Content
Protection Packet
(ACP) Type
0x04 – 0xFF reserved.
0xC1 Read [7:0] ACP Packet Byte 0 ACP Packet Byte 0 (ACP_PB0).
0xC2 Read [7:0] ACP_PB1 ACP_PB1.
0xC3 Read [7:0] ACP_PB2 ACP_PB2.
0xC4 Read [7:0] ACP_PB3 ACP_PB3.
0xC5 Rea [7:0] ACP_PB4 ACP_PB4.
0xC6 Read [7:0] ACP_PB5 ACP_PB5.
0xC7 Read [6:0] NDF New data flags (see 0x87).
0xC8 7 ISRC1 Continued
International standard recording code (ISRC1) continued—This
indicates an ISRC2 packet is being transmitted.
Read 6 ISRC1 Valid 0 = ISRC1 status BITS and PBs not valid.
1 = ISRC1 status BITS and PBs valid.
001 = starting position.
[2:0] ISRC1 Status 010 = intermediate position.
100 = final position.
0xC9 Read [7:0] ISRC1 Packet Byte 0 ISRC1 Packet Byte 0 (ISRC1_PB0).
0xCA Read [7:0] ISRC1_PB1 ISRC1_PB1.
0xCB Read [7:0] ISRC1_PB2 ISRC1_PB2.
0xCC Read [7:0] ISRC1_PB3 ISRC1_PB3.
0xCD Read [7:0] ISRC1_PB4 ISRC1_PB4.
0xCE Read [7:0] ISRC1_PB5 ISRC1_PB5.
0xCF Read [6:0] NDF New data flags (see 0x87).
0xD0 Read [7:0] ISRC1_PB6 ISRC1_PB6.
0xD1 Read [7:0] ISRC1_PB7 ISRC1_PB7.
0xD2 Read [7:0] ISRC1_PB8 ISRC1_PB8.
0xD3 Read [7:0] ISRC1_PB9 ISRC1_PB9.
0xD4 Read [7:0] ISRC1_PB10 ISRC1_PB10.
0xD5 Read [7:0] ISRC1_PB11 ISRC1_PB11.
0xD6 Read [7:0] ISRC1_PB12 ISRC1_PB12.
0xD7 Read [6:0] NDF New data flags (see 0x87).
0xD8 Read [7:0] ISRC1_PB13 ISRC1_PB13.
0xD9 Read [7:0] ISRC1_PB14 ISRC1_PB14.
0xDA Read [7:0] ISRC1_PB15 ISRC1_PB15.
0xDB Read [7:0] ISRC1_PB16 ISRC1_PB16.
0xDC Read [7:0] ISRC2 Packet Byte 0
ISRC2 Packet Byte 0 (ISRC2_PB0)—This is transmitted only when
the ISRC_ continue bit (Register 0xC8, Bit 7) is set to 1.
0xDD Read [7:0] ISRC2_PB1 ISRC2_PB1.
0xDE Read [7:0] ISRC2_PB2 ISRC2_PB2.
0xDF Read [6:0] New Data Flags New data flags (see 0x87).
