AD9880KSTZ-150

Part # AD9880KSTZ-150
Description PB-FREE 150 MHZ HDMI & ANALOGINTERFACE
Category IC
Availability Out of Stock
Qty 0
Qty Price
1 + $10.18110



Technical Document


DISCLAIMER: The information provided herein is solely for informational purposes. Customers must be aware of the suitability of this product for their application, and consider that variable factors such as Manufacturer, Product Category, Date Codes, Pictures and Descriptions may differ from available inventory.

AD9880
Rev. 0 | Page 4 of 64
AD9880KSTZ-100 AD9880KSTZ-150
Parameter Temp Test Level Min Typ Max Min Typ Max Unit
V
DD
Supply Voltage Full IV 1.7 3.3 3.47 1.7 3.3 3.47 V
PV
DD
Supply Voltage Full IV 1.7 1.8 1.9 1.7 1.8 1.9 V
I
D
Supply Current (V
D
) 25°C VI 260 300 330 mA
I
DVDD
Supply Current (DV
DD
) 25°C VI 45 60 85
I
DD
Supply Current (V
DD
)
2
25°C VI 37 100
3
130
3
mA
IP
VDD
Supply Current (P
VDD
) 25°C VI 10 15 20 mA
Total Power Full VI 1.1 1.4 1.15 1.4 W
Power-Down Dissipation Full VI 130 130 mW
DYNAMIC PERFORMANCE
Analog Bandwidth, Full
Power
25°C V 330 330 MHz
Signal–to–Noise Ratio (SNR) 25°C I 46 46 dB
Without Harmonics Full V 45 45 dB
f
IN
= 40.7 MHz
Crosstalk Full V 60 60 dBc
THERMAL CHARACTERISTICS
θ
JA
-Junction-to-Ambient V 35 35 °C/W
1
Drive strength = high.
2
DATACK load = 15 pF, data load = 5 pF.
3
Specified current and power values with a worst case pattern (on/off).
DIGITAL INTERFACE ELECTRICAL CHARACTERISTICS
V
DD
= V
D
=3.3 V, DV
DD
= PV
DD
= 1.8 V, ADC clock = maximum.
Table 2.
AD9880KSTZ-100
AD9880KSTZ-150
Parameter
Tes t
Level
Conditions Min Typ Max Min Typ Max Unit
RESOLUTION 8 8 Bit
DC DIGITAL I/O Specifications
High-Level Input Voltage, (V
IH
) VI 2.5 2.5 V
Low-Level Input Voltage, (V
IL
) VI 0.8 0.8 V
High-Level Output Voltage, (V
OH
) VI V
DD
− 0.1 V
Low-Level Output Voltage, (V
OL
) VI V
DD
− 0.1 0.1 0.1 V
DC SPECIFICATIONS
Output High Level IV Output drive = high 36 36 mA
(I
OHD
) (V
OUT
= V
OH
) IV Output drive = low 24 24 mA
Output Low Level IV Output drive = high 12 12 mA
I
OLD
, (V
OUT
= V
OL
) IV Output drive = low 8 8 mA
DATACK High Level IV Output drive = high 40 40 mA
V
OHC
, (V
OUT
= V
OH
) IV Output drive = low 20 20 mA
DATACK Low Level IV Output drive = high 30 30 mA
V
OLC
, (V
OUT
= V
OL
) IV Output drive = low 15 15 mA
Differential Input Voltage, Single Ended
Amplitude
IV 75 700 75 700 mV
AD9880
Rev. 0 | Page 5 of 64
AD9880KSTZ-100
AD9880KSTZ-150
Parameter
Tes t
Level
Conditions Min Typ Max Min Typ Max Unit
POWER SUPPLY
V
D
Supply Voltage IV 3.15 3.3 3.47 3.15 3.3 3.47 V
V
DD
Supply Voltage IV 1.7 3.3 347 1.7 3.3 347 V
DV
DD
Supply Voltage IV 1.7 1.8 1.9 1.7 1.8 1.9 V
PV
DD
Supply Voltage IV 1.7 1.8 1.9 1.7 1.8 1.9 V
I
VD
Supply Current (Typical Pattern)
1
V 80 100 80 110 mA
I
VDD
Supply Current (Typical Pattern)
2
V 40 100
3
55 175*
I
DVDD
Supply Current (Typical Pattern)
1, 4
V 88 110 110 145 mA
I
PVDD
Supply Current (Typical Pattern)
1
V 26 35 30 40 mA
Power-Down Supply Current (I
PD
) VI 130 130 mA
AC SPECIFICATIONS
Intrapair (+ to −) Differential Input Skew
(T
DPS
)
IV 360 pS
Channel to Channel Differential Input
Skew (T
CCS
)
IV 6
Clock
Period
Low-to-High Transition Time for Data and
Controls (D
LHT
)
IV
Output drive = high;
C
L
= 10 pF
900 ps
IV
Output drive = low;
C
L
= 5 pF
1300 ps
Low-to-High Transition Time for
DATACK (D
LHT
)
IV
Output drive = high;
C
L
= 10 pF
650 ps
IV
Output drive = low;
C
L
= 5 pF
1200 ps
High-to-Low Transition Time for Data and
Controls (D
HLT
)
IV
Output drive = high;
C
L
= 10 pF
850 ps
IV
Output drive = low;
C
L
= 5 pF
1250 ps
High-to-Low Transition Time for
DATACK (D
HLT
)
IV
Output drive = high;
C
L
= 10 pF
800 ps
IV
Output drive = low;
C
L
= 5 pF
1200 ps
Clock to Data Skew
5
(T
SKEW
) IV –0.5 2.0 –0.5 2.0 ns
Duty Cycle, DATACK
5
IV 45 50 55 %
DATACK Frequency (F
CIP
) VI 20 150 MHz
1
The typical pattern contains a gray scale area, output drive = high. Worst case pattern is alternating black and white pixels.
2
The typical pattern contains a gray scale area, output drive = high.
3
Specified current and power values with a worst case pattern (on/off).
4
DATACK load = 10 pF, data load = 5 pF.
5
Drive strength = high.
AD9880
Rev. 0 | Page 6 of 64
ABSOLUTE MAXIMUM RATINGS
Table 3.
Stresses above those listed under Absolute Maximum Ratings
may cause permanent damage to the device. This is a stress
rating only; functional operation of the device at these or any
other conditions above those indicated in the operational
section of this specification is not implied. Exposure to absolute
maximum rating conditions for extended periods may affect
device reliability.
EXPLANATION OF TEST LEVELS
Test L evel
I. 100% production tested.
II. 100% production tested at 25°C and sample tested at
specified temperatures.
III. Sample tested only.
IV. Parameter is guaranteed by design and
characterization testing.
V. Parameter is a typical value only.
VI. 100% production tested at 25°C; guaranteed by design
and characterization testing.
ESD CAUTION
ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily accumulate on
the human body and test equipment and can discharge without detection. Although this product features
proprietary ESD protection circuitry, permanent damage may occur on devices subjected to high energy
electrostatic discharges. Therefore, proper ESD precautions are recommended to avoid performance
degradation or loss of functionality.
Parameter Rating
VD 3.6 V
VDD 3.6 V
DVDD 1.98 V
PVDD 1.98 V
Analog Inputs V
D
to 0.0 V
Digital Inputs 5 V to 0.0 V
Digital Output Current 20 mA
Operating Temperature −25°C to + 85°C
Storage Temperature −65°C to + 150°C
Maximum Junction Temperature 150°C
Maximum Case Temperature 150°C
