www.lumberg-automationusa.com 1-717-217-2299 25

1/2”-20-Round-Plug Connector

1/2”-20-Cordsets

1/2” UNF-Male Straight

Actuator-/Sensor-Cordsets, Single Ended,

1/2” UNF-Male Straight Connector, 3-Poles, C-Coding

with Threaded Joint and Molded Cable. IP 67 Rated.

Cable Types:

226 = PUR, halogen-free, black

Part No.

RST 3U-226/5 M

RST 3U

1/2”-20-Male Straight

Actuator-/Sensor-Cordsets, Single Ended,

1/2”-20 Male Straight Connector, 3-, 4- and 5-Poles,

Dual Keyway, Yellow PVC Cable. IP 67 Rated.

Color Code: Automotive

Cable Types: 18 AWG

688 | 689 = PVC, yellow

755 = TPE, yellow

Cable Types: 22 AWG

618 | 674 | 673 = PVC, yellow

664 = PUR, yellow

Color Code: U.S.

Cable Types: 18 AWG

619 = CPE, yellow

Part No.

RST 3 U-618/6 F RST 4 U-689/6 F

RST 3 U-618/12 F RST 4 U-689/12 F

RST 3 U-618/15 F RST 4 U-689/15 F

RST 3 U-618/20 F RST 4 U-689/20 F

RST 3 U-619/6 F RST 4 U-674/6 F

RST 3 U-619/12 F RST 4 U-674/12 F

RST 3 U-619/15 F RST 4 U-674/15 F

RST 3 U-619/20 F RST 4 U-674/20 F

RST 3 U-688/6 F RST 5 U-673/6 F

RST 3 U-688/12 F RST 5 U-673/12 F

RST 3 U-688/15 F RST 5 U-673/15 F

RST 3 U-688/20 F RST 5 U-673/20 F

RST 3 U-664/6 F RST 5 U-755/6 F

RST 3 U-664/12 F RST 5 U-755/12 F

RST 3 U-664/15 F RST 5 U-755/15 F

RST 3 U-664/20 F RST 5 U-755/20 F

RST 3 U | RST 4 U | RST 5 U

1/2” UNF-Female Straight

Actuator-/Sensor-Cordsets, Single Ended,

1/2” UNF-Female Straight Connector, 3-Poles,

C-Coding with Threaded Joint and Molded Cable.

IP 67 Rated.

Cable Types:

226 = PUR, halogen-free, black

Part No.

RKT 3U-226/5 M

RKT 3U

Cordsets

Single-Ended

Cordsets, Single-Ended

1-717-217-2299 www.lumberg-automationusa.com26

1/2”-20-Female Straight

Actuator-/Sensor-Cordsets, Single Ended,

1/2”-20 Female Straight Connector, 3-, 4- and

5-Poles, Dual Keyway, 18 AWG Yellow PVC Cable,

IP 67 Rated.

Color Code: Automotive

Cable Types: 18 AWG

688 | 689 = PVC, yellow

755 = TPE, yellow

Cable Types: 22 AWG

618 | 674 | 673 = PVC, yellow

664 = PUR, yellow

Color Code: U.S.

Cable Types: 18 AWG

619 = CPE, yellow

1/2”-20-Female 90˚

Actuator-/Sensor-Cordsets, Single Ended,

1/2”-20 Female 90˚ Connector, 3-, 4- and 5-Poles,

Dual Keyway, 18 AWG Yellow PVC Cable, IP 67 Rated.

Color Code: Automotive

Cable Types: 18 AWG

688 | 689 = PVC, yellow

755 = TPE, yellow

Cable Types: 22 AWG

618 | 674 | 673 = PVC, yellow

664 = PUR, yellow

Color Code: U.S.

Cable Types: 18 AWG

619 = CPE, yellow

Part No. Part No.

RKT 3 U-618/6 F RKT 4 U-689/6 F

RKT 3 U-618/12 F RKT 4 U-689/12 F

RKT 3 U-618/15 F RKT 4 U-689/15 F

RKT 3 U-618/20 F RKT 4 U-689/20 F

RKT 3 U-619/6 F RKT 4 U-674/6 F

RKT 3 U-619/12 F RKT 4 U-674/12 F

RKT 3 U-619/15 F RKT 4 U-674/15 F

RKT 3 U-619/20 F RKT 4 U-674/20 F

RKT 3 U-688/6 F RKT 5 U-673/6 F

RKT 3 U-688/12 F RKT 5 U-673/12 F

RKT 3 U-688/15 F RKT 5 U-673/15 F

RKT 3 U-688/20 F RKT 5 U-673/20 F

RKT 3 U-664/6 F RKT 5 U-755/6 F

RKT 3 U-664/12 F RKT 5 U-755/12 F

RKT 3 U-664/15 F RKT 5 U-755/15 F

RKT 3 U-664/20 F RKT 5 U-755/20 F

Part No. Part No.

RKWT 3 U-618/6 F RKWT 4 U-689/6 F

RKWT 3 U-618/12 F RKWT 4 U-689/12 F

RKWT 3 U-618/15 F RKWT 4 U-689/15 F

RKWT 3 U-618/20 F RKWT 4 U-689/20 F

RKWT 3 U-619/6 F RKWT 4 U-674/6 F

RKWT 3 U-619/12 F RKWT 4 U-674/12 F

RKWT 3 U-619/15 F RKWT 4 U-674/15 F

RKWT 3 U-619/20 F RKWT 4 U-674/20 F

RKWT 3 U-688/6 F RKWT 5 U-673/6 F

RKWT 3 U-688/12 F RKWT 5 U-673/12 F

RKWT 3 U-688/15 F RKWT 5 U-673/15 F

RKWT 3 U-688/20 F RKWT 5 U-673/20 F

RKWT 3 U-664/6 F RKWT 5 U-755/6 F

RKWT 3 U-664/12 F RKWT 5 U-755/12 F

RKWT 3 U-664/15 F RKWT 5 U-755/15 F

RKWT 3 U-664/20 F RKWT 5 U-755/20 F

RKT 3 U | RKT 4 U | RKT 5 U

RKWT 3 U | RKWT 4 U | RKWT 5 U

M12-Duo-Male

Actuator-/Sensor-Double Ended, M12-Duo-Male

Straight and two Open Leads, 3-Pole with Self-

Locking Threaded Joint, IP 67 Rated.

Cable Types:

632 = PVC, yellow

ASB 2

Part No.

ASB 2 4-3-632/0.3 M

ASB 2 4-3-632/0.6 M

ASB 2 4-3-632/1 M

ASB 2 4-3-632/1.5 M

ASB 2 4-3-632/2 M

ASB 2 4-3-632/5 M

1/2”-20-Round-Plug Connector

1/2”-20-Cordsets

www.lumberg-automationusa.com 1-717-217-2299 27

Mini 7/8” -Round-Plug Connector

7/8”-Single-Ended Cordsets, A Body Style

7/8” A Body-Male Straight

Mini Cordsets, Single Ended, 7/8” Male Straight

Connector, 2-, 3-, 4-, 5-, and 6-Poles with Internal

Threads and Molded Cable. IP 67 Rated.

Color Code: U.S.

Cable Types: 16 AWG

738 | 739 | 777 = TPE, yellow

678 = PVC, yellow

Cable Types: 18 AWG

619 = CPE, yellow

697 = PVC, yellow

Color Code: Automotive

Cable Types: 16 AWG

741 | 742 = TPE, yellow

Cable Types: 18 AWG

755 = TPE, yellow

7/8” A Body-Female Straight

Mini Cordsets, Single Ended, 7/8” Female Straight

Connector, 2-, 3-, 4-, 5-, and 6-Poles with Internal

Threads and Molded Cable. IP 67 Rated.

Color Code: U.S.

Cable Types: 16 AWG

738 | 739 | 777 = TPE, yellow

678 = PVC, yellow

Cable Types: 18 AWG

619 = CPE, yellow

697 = PVC, yellow

Color Code: Automotive

Cable Types: 16 AWG

741 | 742 = TPE, yellow

Cable Types: 18 AWG

755 = TPE, yellow

RS 201...601A

RK 20...60A

Part No. Part No.

RS 201-678/6 F RS 501-742/6 F

RS 201-678/12 F RS 501-742/12 F

RS 201-678/15 F RS 501-742/15 F

RS 201-678/20 F RS 501-742/20 F

RS 201-678/30 F RS 501-742/30 F

RS 301-619/6 F RS 501-755/6 F

RS 301-619/12 F RS 501-755/12 F

RS 301-619/15 F RS 501-755/15 F

RS 301-619/20 F RS 501-755/20 F

RS 301-619/30 F RS 501-755/30 F

RS 301-738/6 F RS 501-777/6 F

RS 301-738/12 F RS 501-777/12 F

RS 301-738/15 F RS 501-777/15 F

RS 301-738/20 F RS 501-777/20 F

RS 301-738/30 F RS 501-777/30 F

RS 301-741/6 F RS 601A-697/6 F

RS 301-741/12 F RS 601A-697/12 F

RS 301-741/15 F RS 601A-697/15 F

RS 301-741/20 F RS 601A-697/20 F

RS 301-741/30 F RS 601A-697/30 F

RS 401-739/6 F

RS 401-739/12 F

RS 401-739/15 F

RS 401-739/20F

RS 401-739/30F

Part No. Part No.

RK 20-678/6 F RK 50-742/6 F

RK 20-678/12 F RK 50-742/12 F

RK 20-678/15 F RK 50-742/15 F

RK 20-678/20 F RK 50-742/20 F

RK 20-678/30 F RK 50-742/30 F

RK 30-619/6 F RK 50-755/6 F

RK 30-619/12 F RK 50-755/12 F

RK 30-619/15 F RK 50-755/15 F

RK 30-619/20 F RK 50-755/20 F

RK 30-619/30 F RK 50-755/30 F

RK 30-738/6 F RK 50-777/6 F

RK 30-738/12 F RK 50-777/12 F

RK 30-738/15 F RK 50-777/15 F

RK 30-738/20 F RK 50-777/20 F

RK 30-738/30 F RK 50-777/30 F

RK 30-741/6 F RK 60A-697/6 F

RK 30-741/12 F RK 60A-697/12 F

RK 30-741/15 F RK 60A-697/15 F

RK 30-741/20 F RK 60A-697/20 F

RK 30-741/30 F RK 60A-697/30 F

RK 40-739/6 F

RK 40-739/12 F

RK 40-739/15 F

RK 40-739/20 F

RK 40-739/30 F

Cordsets

Single-Ended

Cordsets, Single-Ended
