1-717-217-2299 www.lumberg-automationusa.com22

M12-Female Straight – LED

Actuator-/Sensor-Cordsets with LED, Single Ended,

M12-Female Straight Connector, 3-Poles with

Threaded Joint and Molded Cable. IP 67 Rated.

Cable Types:

632 = PVC, yellow

Part No.

RKT/LED A 4-3-632/1 M

RKT/LED A 4-3-632/2 M

RKT/LED A 4-3-632/5 M

RKT/LED A 4-3-632/10 M

RKT/LED

M12-Round-Plug Connector According to IEC 61076-2-101

M12-Cordsets

M12-Female 90° – LED

Actuator-/Sensor-Cordsets with LED, Single Ended,

M12-Female 90° Connector, 3- and 4-Poles with

Threaded Joint and Molded Cable. IP 67 Rated.

Cable Types:

06 | 07 = PVC, orange

224 | 225 | 265 = PUR, halogen-free, black

251 | 260 = PUR, halogen-free, weld

and spark proof, orange

Part No.

RKWT/LED A 4-3-06/2 M

RKWT/LED A 4-3-06/5 M

RKWT/LED A 4-3-06/10 M

RKWT/LED A 4-3-224/2 M

RKWT/LED A 4-3-224/5 M

RKWT/LED A 4-3-224/10 M

RKWT/LED A 4-3-260/2 M

RKWT/LED A 4-3-260/5 M

RKWT/LED A 4-3-260/10 M

RKWT/LED P 4-07/2 M

RKWT/LED P 4-07/5 M

RKWT/LED P 4-07/10 M

RKWT/LED P 4-225/2 M

RKWT/LED P 4-225/5 M

RKWT/LED P 4-225/10 M

RKWT/LED P 4-251/2 M

RKWT/LED P 4-251/5 M

RKWT/LED P 4-251/10 M

RKWT/LED W 4-265/2 M

RKWT/LED W 4-265/5 M

RKWT/LED W 4-265/10 M

RKWT/LED

M12-Female Straight – LED

Actuator-/Sensor-Cordsets with LED, Single Ended,

M12-Female 90˚ Connector, 3-Poles with Threaded

Joint and Molded Cable. IP 67 Rated.

Cable Types:

632 | 633 = PVC, yellow

Part No.

RKWT/LED A 4-3-632/1 M

RKWT/LED A 4-3-632/2 M

RKWT/LED A 4-3-632/5 M

RKWT/LED A 4-3-632/10 M

RKWT/LED P 4-3-633/1 M

RKWT/LED P 4-3-633/2 M

RKWT/LED P 4-3-633/5 M

RKWT/LED P 4-3-633/10 M

RKWT/LED

www.lumberg-automationusa.com 1-717-217-2299 23

M12-Round-Plug Connector According to IEC 61076-2-101

M12-Cordsets

M12-Male Straight

Actuator-/Sensor-Cordsets, Single Ended,

M12-Male Straight Connector, 4-, 5- and 8-Poles,

with Threaded Joint and Molded Cable.

IP 67 Rated.

Cable Types:

182 | 183 | 184 = PVC, orange

288 | 298 | 299 = PUR, halogen-free, black

M12-Female Straight

Actuator-/Sensor-Cordsets, Single Ended,

M12-Male Straight Connector, 4-, 5- and 8-Poles,

with Threaded Joint and Molded Cable with Shielding

Connected to nut. IP 67 Rated.

Cable Types:

182 | 183 | 184 = PVC, orange

288 | 298 | 299 = PUR, halogen-free, black

Part No. Part No.

RSTS 4-182/2 M RSTS 5-298/2 M

RSTS 4-182/5 M RSTS 5-298/5 M

RSTS 4-182/10 M RSTS 5-298/10 M

RSTS 4-288/2 M RSTS 8-184/2 M

RSTS 4-288/5 M RSTS 8-184/5 M

RSTS 4-288/10 M RSTS 8-184/10 M

RSTS 5-183/2 M RSTS 8-299/2 M

RSTS 5-183/5 M RSTS 8-299/5 M

RSTS 5-183/10 M RSTS 8-299/10 M

Part No. Part No.

RKTS 4-182/2 M RKTS 5-298/2 M

RKTS 4-182/5 M RKTS 5-298/5 M

RKTS 4-182/10 M RKTS 5-298/10 M

RKTS 4-288/2 M RKTS 8-184/2 M

RKTS 4-288/5 M RKTS 8-184/5 M

RKTS 4-288/10 M RKTS 8-184/10 M

RKTS 5-183/2 M RKTS 8-299/2 M

RKTS 5-183/5 M RKTS 8-299/5 M

RKTS 5-183/10 M RKTS 8-299/10 M

RSTS

RKTS

M12-Male 90°

Actuator-/Sensor-Cordsets, Single Ended,

M12-Male 90° Connector, 4-, 5- and 8-Poles, with

Threaded Joint and Molded Cable with Shielding

Connected to nut. IP 67 Rated.

Cable Types:

182 | 183 | 184 = PVC, orange

288 | 298 | 299 = PUR, halogen-free, black

635 = PVC, yellow

Part No. Part No.

RKWTH 4-182/2 M RKWTH 5-298/2 M

RKWTH 4-182/5 M RKWTH 5-298/5 M

RKWTH 4-182/10 M RKWTH 5-298/10 M

RKWTH 4-288/2 M RKWTH 8-299/2 M

RKWTH 4-288/5 M RKWTH 8-299/5 M

RKWTH 4-288/10 M RKWTH 8-299/10 M

RKWTH 4-635/2 M

RKWTH 4-635/5 M

RKWTH 4-635/10 M

RKWTH

Cordsets

Single-Ended

Cordsets, Single-Ended

1-717-217-2299 www.lumberg-automationusa.com24

M12-Round-Plug Connector According to IEC 61076-2-101

M12-Cordsets

M12-Male Straight

Actuator-/Sensor-Cordsets, Single Ended,

M12-Male Straight Connector, 4-Poles, with Threaded

Joint and Molded Cable, Hexagon Stainless Steel

External Threads and Nut. IP 67 / IP 69K Rated.

– especially designed for use in

Food Processing equipment –

Cable Types:

07 = PVC, orange

M12-Female Straight

Actuator-/Sensor-Cordsets, Single Ended,

M12-Female Straight Connector, 4- and 5-Poles, with

Threaded Joint and Molded Cable, Hexagon Stainless

Steel Internal Threads and Nut. IP 67 / IP 69K Rated.

– especially designed for use in

Food Processing equipment –

Cable Types:

07 | 56 = PVC, orange

M12-Female 90°

Actuator-/Sensor-Cordsets, Single Ended,

M12-Female 90° Connector, 4- and 5-Poles, with

Threaded Joint and Molded Cable, Hexagon Stainless

Steel Internal Threads and Nut. IP 67 / IP 69K Rated.

– especially designed for use in

Food Processing equipment –

Cable Types:

07 | 56 = PVC, orange

Part No.

PRST 4-07/5 M

PRST 4-07/10 M

PRST 4-07/25 M

Part No.

PRKT 4-07/5 M

PRKT 4-07/10 M

PRKT 4-07/25 M

PRKT 5-56/5 M

PRKT 5-56/10 M

PRKT 5-56/25 M

Part No.

PRKWT 4-07/5 M

PRKWT 4-07/10 M

PRKWT 4-07/25 M

PRKWT 5-56/5 M

PRKWT 5-56/10 M

PRKWT 5-56/25 M

PRST

PRKT

PRKWT

M12-Female 90° – LED

Actuator-/Sensor-Cordsets with LED, Single Ended,

M12-Female 90° Connector, 4-Poles, with Threaded

Joint and Molded Cable, Hexagon Stainless Steel

Internal Threads. IP 67 / IP 69K Rated.

– especially designed for use in Food

Processing equipment –

Cable Types:

07 | 56 = PVC, orange

Part No.

PRKWT/LED P 4-07/5 M

PRKWT/LED P 4-07/10 M

PRKWT/LED P 4-07/25 M

PRKWT/LED
