www.lumberg-automationusa.com 1-717-217-2299 19
M12-Round-Plug Connector According to IEC 61076-2-101
M12-Cordsets
M12-Male Straight
Actuator-/Sensor-Cordsets, Single Ended,
M12-Male Straight Connector, 3-, 4-, 5- and 8-Poles
with Threaded Joint and Molded Cable. IP 67 Rated.
Cable Types: 18 AWG
731 | 637 = TPE, yellow
645 | 602 = PUR, yellow
Cable Types: 22 AWG
632 | 633 | 612 = PVC, yellow
610 | 679 | 644 = PUR, yellow
643 = TPE, yellow
Cable Types: 24 AWG
627 = PVC, black
Part No.
RST 3-731/2 M RST 4-643/2 M
RST 3-731/5 M RST 4-643/5 M
RST 3-731/10 M RST 4-643/10 M
RST 3-632/2 M RST 4-602/2 M
RST 3-632/5 M RST 4-602/5 M
RST 3-632/10 M RST 4-602/10 M
RST 3-645/2 M RST 4-679/2 M
RST 3-645/5 M RST 4-679/5 M
RST 3-645/10 M RST 4-679/10 M
RST 3-610/2 M RST 5-612/2 M
RST 3-610/5 M RST 5-612/5 M
RST 3-610/10 M RST 5-612/10 M
RST 4-637/2 M RST 5-644/2 M
RST 4-637/5 M RST 5-644/5 M
RST 4-637/10 M RST 5-644/10 M
RST 4-633/2 M RST 8-627/2 M
RST 4-633/5 M RST 8-627/5 M
RST 4-633/10 M RST 8-627/10 M
RST
RST 8-627 (Only)
M12-Female Straight
Actuator-/Sensor-Cordsets, Single Ended,
M12-Female Straight Connector, 3-, 4-, 5-, 8- and
12-Poles with Threaded Joint and Molded Cable.
IP 67 Rated.
8-6-Poles Connects with SBS Sensor-/Actuator
M8 Distribution Boxes
12-Poles Connects with ASBSM Sensor-/Actuator
M8 Distribution Boxes
Cable Types:
06 | 07 | 56 = PVC, orange
224 | 225 |
228 | 282 | 337 | 348 = PUR, halogen-free, black
251 | 259 | 260 | 268 = PUR, halogen-free, weld
and spark proof, orange
Part No. Part No.
RKT 4-3-06/2 M RKT 5-228/2 M
RKT 4-3-06/5 M RKT 5-228/5 M
RKT 4-3-06/10 M RKT 5-228/10 M
RKT 4-3-224/2 M RKT 5-259/2 M
RKT 4-3-224/5 M RKT 5-259/5 M
RKT 4-3-224/10 M RKT 5-259/10 M
RKT 4-3-260/2 M RKT 8-6-268/2 M
RKT 4-3-260/5 M RKT 8-6-268/5 M
RKT 4-3-260/10 M RKT 8-6-268/10 M
RKT 4-07/2 M RKT 8-6-337/2 M
RKT 4-07/5 M RKT 8-6-337/5 M
RKT 4-07/10 M RKT 8-6-337/10 M
RKT 4-225/2 M RKT 8-282/2 M
RKT 4-225/5 M RKT 8-282/5 M
RKT 4-225/10 M RKT 8-282/10 M
RKT 4-251/2 M RKT 12-348/2 M
RKT 4-251/5 M RKT 12-348/5 M
RKT 4-251/10 M RKT 12-348/10 M
RKT 5-56/2 M
RKT 5-56/5 M
RKT 5-56/10 M
RKT
Cordsets
Single-Ended
Cordsets, Single-Ended
