References
Cable Index and Connector Key/Pin Configurations
U.S. Color Code-Mini-A-Body (7/8”) Cable Specifications
Conductors Cable
No.
Pin/Wire Color
Code
Face View
Male
Face View
Female
Gauge Material Voltage
Rating
Jacket
Color
Outside
Diameter
Temperature
Rating
UL
CSA
2 678
1 = black
2 = white
16
PVC
600 V Yellow .375" -40°C to +105°C STOW STO
3 738
619
1 = green
2 = black
3 = white
16
18
TPE
CPE
600 V
600 V
Yellow
Yellow
.390”
.370”
-50°C to +90°C
-25°C to +90°C
SEOOW
SOOW
STOOW
SOW
4 739
1 = black
2 = white
3 = red
4 = green
16
TPE
600 V Yellow .415” -50°C to +90°C SEOOW STOOW
5 777
1 = white
2 = red
3 = green
4 = orange
5 = black
16
TPE
600 V Yellow .495” -50°C to +90°C SEOOW STOOW
6 697
1 = white
2 = red
3 = green
4 = orange
5 = black
6 = blue
18
PVC
300 V Yellow .502” -40°C to +105°C STOW STO
U.S. Color Code-Mini-B-Body (1”) Cable Specifications
Conductors Cable
No.
Pin/Wire Color
Code
Face View
Male
Face View
Female
Gauge Material Voltage
Rating
Jacket
Color
Outside
Diameter
Temperature
Rating
UL
CSA
6 696
1 = orange
2 = blue
3 = black
4 = white
5 = red
6 = green
16
PVC
600 V Yellow .560” -40°C to +105°C STOW STO
7 622
649
1 = white/black
2 = black
3 = white
4 = red
5 = orange
6 = blue
7 = green
16
18
PVC
PUR
600 V
300 V
Yellow
Yellow
.560”
.270”
-40°C to +105°C
-45°C to +80°C
STOW
AWM 20233
STO
AWM I/II A/B
8 698
650
1 = orange
2 = blue
3 = white/black
4 = black
5 = white
6 = red
7 = green
8 = red/black
16
18
PVC
PUR
600 V
300 V
Yellow
Yellow
.585”
.292”
-40°C to +105°C
-45°C to +80°C
STOW
AWM 20233
STO
AWM I/II A/B
