1-717-217-2299 www.lumberg-automationusa.com148
References
Glossary of Terms
W
W (Watt or Wattage)
A unit of measure for electrical power.
Watt (W)
The unit of measure for electrical power.
Wicking
Capillary absorption of a liquid along the fibers of the
base material.
Withdrawal Force
The force required to separate two mated contacts or
group of contacts.
X
X
The alpha symbol for Reactance – opposition to
alternating electric current flow caused by inductance
and capacitance in a circuit.
XLR
A multi pin audio connector (typically 3 pins) used in
a microphone, line level and snake cable connections.
Y
Z
www.lumberg-automationusa.com 1-717-217-2299 149
References
Cable Index and Connector Key/Pin Configurations
IEC Color Code-M8 Cable Specifications
Conductors Cable
No.
Pin/Wire Color
Code
Face View
Male
Face View
Female
Gauge Material Jacket
Color
Outside Diameter UL
CSA
3 06
224
357
1 = brown
2 = blue
3 = black
3 x 0.34mm
2
3 x 0.34mm
2
PVC
PUR,
Halogen-Free
Orange
Black
.197” / Ø 5.0mm
.185” / Ø 4.7mm
AWM 2464
AWM 21198
AWM 20233
AWM I/II A/B
AWM I/II A/B
AWM I/II A/B
4 07
225
358
1 = brown
2 = white
3 = blue
4 = black
4 x 0.25mm
2
4 x 0.34mm
2
4 x 0.25mm
2
PVC
PUR,
Halogen-Free
PUR, Halogen-Free
Orange
Black
Grey
.197” / Ø 5.0mm
.181” / Ø 4.6mm
.205” / Ø 5.2mm
AWM 2464
AWM 21198
AWM 20233
AWM I/II A/B
AWM I/II A/B
AWM I/II A/B
8 354
1 = white
2 = brown
3 = green
4 = yellow
5 = grey
6 = pink
7 = blue
8 = red
8 x 0.14mm
2
PUR, Halogen-Free Black .197” / Ø 5.0mm AWM 21198 AWM I/II A/B
5
4
3
8
6
7
1
2
5
4
3
8
6
7
1
2
5
6
7
8
5
6
7
8
5
6
7
8
IEC Color Code-M12 Micro Cable Specifications
Conductors Cable
No.
Pin/Wire Color
Code
Face View
Male
Face View
Female
Gauge Material Jacket
Color
Outside Diameter UL
CSA
3 06
224
226
260
645
610
1 = brown
2 = n.c
3 = blue
4 = black
3 x 0.34mm
2
3 x 0.34mm
2
3 x 0.50mm
2
3 x 0.34mm
2
3 x 0.75mm
2
3 x 0.34mm
2
PVC
PUR,
Halogen-Free
PUR, Halogen-Free
PUR, Halogen-Free,
Weld Spark Proof
PUR
PUR
Orange
Black
Black
Orange
Yellow
Yellow
.197” / Ø 5.0mm
.169” / Ø 4.3mm
.181” / Ø 4.6mm
.177” / Ø 4.5mm
.220” / Ø 5.6mm
.190” / Ø 4.8mm
AWM 21198
AWM 21198
AWM 21198
AWM 20233
AWM 20233
Class I/II, A/B
Class I/II, A/B
Class I/II, A/B
Class I/II, A/B
Class I/II, A/B
4 07
182
225
251
265
288
602
637
643
679
1 = brown
2 = white
3 = blue
4 = black
4 x 0.25mm
2
4 x 0.34mm
2
4 x 0.34mm
2
4 x 0.34mm
2
4 x 0.34mm
2
4 x 0.34mm
2
4 x 0.75mm
2
18 AWG
22 AWG
4 x 0.34mm
2
PVC
PVC,
Shielded
PUR, Halogen-Free
PUR, Halogen-Free,
Weld Spark Proof
PUR, Halogen-Free
PVC, Shielded
PUR
TPE
TPE
PUR
Orange
Orange
Black
Orange
Grey
Black
Yellow
Yellow
Yellow
Yellow
.197” / Ø 5.0mm
.217” / Ø 5.5mm
.185” / Ø 4.7mm
.185” / Ø 4.7mm
.185” / Ø 4.7mm
.217” / Ø 5.5mm
.230” / Ø 5.8mm
.280” / Ø 7.1mm
.246” / Ø 6.2mm
.190” / Ø 4.8mm
AWM 2464
AWM 21198
AWM 21198
AWM 21198
AWM 20233
AWM 20327
PLTC
AWM 20233
AWM I/II A/B
Class I/II, A/B
Class I/II, A/B
Class I/II, A/B
Class I/II, A/B
Class I/II, A/B
Class I/II, A/B
Class I/II, A/B
5 183
228
298
644
1 = brown
2 = white
3 = blue
4 = black
5 = grey
5 x 0.34mm
2
5 x 0.50mm
2
5 x 0.34mm
2
5 x 0.34mm
2
PVC
PUR,
Halogen-Free
PUR, Halogen-Free,
Shielded
PUR
Orange
Black
Black
Yellow
.260” / Ø 6.6mm
.213” / Ø 5.4mm
.236” / Ø 6.0mm
.210” / Ø 5.3mm
AWM 21198
AWM 21198
AWM 20233
Class I/II, A/B
Class I/II, A/B
Class I/II, A/B
6 337
268
1 = white
2 = green
3 = yellow
4 = grey
5 = brown
6 = n.c.
7 = blue
8 = n.c.
6 x 0.34mm
2
6 x 0.34mm
2
PUR, Halogen-Free
PUR, Halogen-Free,
Weld Spark Proof
Black
Orange
.236” / Ø 6.0mm
.236” / Ø 6.0mm
AWM 21198
AWM 21198
Class I/II, A/B
Class I/II, A/B
Cable Index
Pin Configurations
References
1-717-217-2299 www.lumberg-automationusa.com150
References
Cable Index and Connector Key/Pin Configurations
IEC Color Code-M12 Micro Cable Specifications
Conductors Cable
No.
Pin/Wire Color
Code
Face View
Male
Face View
Female
Gauge Material Jacket
Color
Outside Diameter UL
CSA
7 282
1 = white
2 = brown
3 = green
4 = yellow
5 = grey
6 = pink
7 = blue
8 = shield
7 x 0.25mm
2
PUR, Halogen-Free Black .236” / Ø 6.0mm AWM 21198 AWM I/II, A/B
8 299
184
627
1 = white
2 = brown
3 = green
4 = yellow
5 = grey
6 = pink
7 = blue
8 = red
8 x 0.25mm
2
8 x 0.25mm
2
8 x 0.25mm
2
PUR, Halogen-Free
Shielded
PVC, Shielded
PVC
Black
Orange
Black
.260” / Ø 6.6mm
.260” / Ø 6.6mm
.232” / Ø 5.9mm
AWM 21198
AWM 2661
AWM I/II, A/B
AWM I/II, A/B
12 348
1 = brown
2 = blue
3 = white
4 = green
5 = pink
6 = yellow
7 = black
8 = grey
9 = red
10 = violett
11 = grey/pink
12 = red/blue
2 x 0.25mm
2
10 x 0.14mm
2
PUR, Halogen-Free Black .236” / Ø 6.0mm
U.S. Color Code-M12 1/2”-20 Cable Specifications
Conductors Cable
No.
Pin/Wire Color
Code
Face View
Male
Face View
Female
Gauge Material Jacket
Color
Outside Diameter UL
CSA
3 619
1 = green
2 = black
3 = white
3 x 0.75mm
2
CPE
Yellow .370” / Ø 9.4mm SOOW SOW
Automotive Color Code-M12 1/2”-20
Conductors Cable
No.
Pin/Wire Color
Code
Face View
Male
Face View
Female
Gauge Material Jacket
Color
Outside Diameter UL
CSA
3 618
688
664
1 = green
2 = red/black
3 = red/white
3 x 0.34mm
2
3 x 0.75mm
2
3 x 0.34mm2
PVC
PVC
PUR
Yellow
Yellow
Yellow
.180” / Ø 4.6mm
.290” / Ø 7.4mm
.190” / Ø 4.8mm
AWM 2661
AWM 2661
AWM 20233
AWM I/II, A/B
AWM I/II, A/B
AWM I/II, A/B
4 674
689
1 = red/black
2 = red/white
3 = red
4 = green
4 x 0.34mm
2
4 x 0.75mm
2
PVC
PVC
Yellow
Yellow
.190” / Ø 4.8mm
.290” / Ø 7.4mm
AWM 2661
AWM 2661
AWM I/II, A/B
AWM I/II, A/B
5 673
755
1 = red/white tr.
2 = red
3 = green
4 = red/yellow tr.
5 = red/black tr.
5 x 0.34mm
2
5 x 0.75mm
2
PVC
TPE
Yellow
Yellow
.210” / Ø 5.3mm
.333” / Ø 8.5mm
AWM 20233
PLTC
AWM I/II, A/B
AWM I/II, A/B
