1-717-217-2299 www.lumberg-automationusa.com136

Industrial Ethernet

Ethernet-Switches and Adapters

FWD 5

0982 EEC 100

0982 EEC 101

0981 ENC 100

0981 ENC 102

Part No.

0982 EEC 100

Part No.

0982 EEC 101

Part No.

0981 ENC 100

Part No.

0981 ENC 102

Part No.

0985 342 100/1 M

0985 342 100/2 M

0985 342 100/3 M

0985 342 100/5 M

Ethernet-Switch, IP 67, 5-Port Unmannaged Switch

for 10/100 Mbaud Transmission Rates, M12-Sockets,

4-Poles, D-Coding, M12 Power Supply, 5-Poles

Standard Coding.

– suitable for Ethernet/IP or ProﬁNet applications –

Ethernet-Switch, IP 67, 5-Port Unmannaged Switch

for 10/100 Mbaud Transmission Rates, M12-Sockets,

8-Poles, M12 Power Supply, 5-Poles Standard

Coding.

– suitable for Modbus/TCP applications –

Ethernet-Panel-Mount-Adapter, M12-Female,

D-Coding Connector, Chasis Side Thread PG 9,

RJ45-Female Connctor 90˚.

– suitable for Ethernet/IP or ProﬁNet applications –

Ethernet-Panel-Mount-Adapter, M12-Female, 8-Pole

Connector, Chasis Side Thread PG 9, RJ45-Female

Connctor 90˚.

– suitable for Modbus/TCP applications –

Industrial Ethernet Double-Ended Data Cable (molded

on both sides) According to PROFInet Type C with

M12-Male Connectors, D-Coding.

0985 342 100/...M: 4-Pin, M12 Straight Male to M12

Straight Male, IP 65/ IP 67 Rated.

– suitable for PROFInet applications –

0985 342 100/...M

www.lumberg-automationusa.com 1-717-217-2299 137

Industrial Ethernet

Ethernet-Data Cables-for PROFInet Applications

FWD 5

Part No.

0985 342 104/0.5 M

0985 342 104/1 M

0985 342 104/2 M

0985 342 104/5 M

0985 342 104/10 M

Part No.

0985 342 500/0.5 M

0985 342 500/1 M

0985 342 500/2 M

0985 342 500/5 M

0985 342 500/10 M

Industrial Ethernet Double-Ended Data Cable

According to PROFInet Type C with M12-Male

Connector, D-Coding and RJ45-Male Connector.

0985 342 104/...M: 4-Pin, M12 to RJ45-Male, IP 65/

IP 67 Rated.

– suitable for PROFInet applications –

Industrial Ethernet Double-Ended Data Cable

According to PROFInet Type C with RJ45- to RJ45-

Male Connectors.

0985 342 500/...M: 4-Pin, RJ45 to RJ45, IP 65/

IP 67 Rated.

– suitable for PROFInet applications –

0985 342 104/...M

0985 342 500

Industrial Ethernet

Ethernet-Data Cables-Moderate Flex, 4-Twistsed Pair, 24 AWG Solid, Shielded, PVC Jacket

FWD 5

Part No.

0985 609 100/0.5 M 0985 609 101/0.5 M

0985 609 100/1 M 0985 609 101/1 M

0985 609 100/2 M 0985 609 101/2 M

0985 609 100/5 M 0985 609 101/5 M

0985 609 100/10 M

0985 609 100/15 M

0985 609 100/20 M

0985 609 100/25 M

0985 609 100/30 M

0985 609 100/35 M

0985 609 100/40 M

0985 609 100/45 M

0985 609 100/50 M

Part No.

0985 609 500/0.5 M

0985 609 500/1 M

0985 609 500/2 M

0985 609 500/5 M

0985 609 500/10 M

Industrial Ethernet Double-Ended Data Cables

(molded on both sides) 4-Twisted Pair, 24 AWG

Solid, PVC Teal Jacket, Moderate-Flex and Shielded,

Standard Coding.

0985 609 100/...M: 8-Pin, M12-Male Straight to

M12-Male Straight, IP 67 Rated.

0985 609 101/...M: 8-Pin, M12-Male Straight to

M12-Male Straight with Cross-Over Wire.

Industrial Ethernet Double-Ended Data Cables,

4-Twisted Pair, 24 AWG Solid, PVC Teal Jacket,

Moderate-Flex and Shielded, Standard Coding.

0985 609 500/...M: 8-Pin, RJ45 to RJ45,

IP 20 Rated.

0985 609 100/...M | 0985 609 101/...M |

0985 609 500/...M

1-717-217-2299 www.lumberg-automationusa.com138

Industrial Ethernet

Ethernet-Data Cables-High Flex, 4-Twisted Pair, 24 AWG Stranded, Shielded, PVC Cable

FWD 5

Part No.

0985 656 100/0.5 M 0985 656 101/0.5 M

0985 656 100/1 M 0985 656 101/1 M

0985 656 100/2 M 0985 656 101/2 M

0985 656 100/5 M 0985 656 101/5 M

0985 656 100/10 M

0985 656 100/15 M

0985 656 100/20 M

0985 656 100/25 M

0985 656 100/30 M

0985 656 100/35 M

0985 656 100/40 M

0985 656 100/45 M

0985 656 100/50 M

Part No.

0985 656 103/0.5 M

0985 656 103/1 M

0985 656 103/2 M

0985 656 103/5 M

0985 656 103/10 M

Part No.

0985 656 104/0.5 M

0985 656 104/1 M

0985 656 104/2 M

0985 656 104/5 M

0985 656 104/10 M

Part No.

0985 656 500/0.5 M

0985 656 500/1 M

0985 656 500/2 M

0985 656 500/5 M

0985 656 500/10 M

Industrial Ethernet Double-Ended Data Cables

(molded on both sides) 4-Twisted Pair, 24 AWG

Stranded, PVC Teal Jacket, High-Flex and Shielded,

Standard Coding.

0985 656 100/...M: 8-Pin, M12-Male Straight to

M12-Male Straight, IP 67 Rated.

0985 656 101/...M: 8-Pin, M12-Male Straight to

M12-Male Straight with Cross-Over Wire, IP 67 Rated.

Industrial Ethernet Double-Ended Data Cables,

4-Twisted Pair, 24 AWG Stranded, PVC Teal Jacket,

High-Flex and Shielded, Standard Coding.

0985 656 103/...M: 8-Pin, M12 Straight to RJ45,

IP 65/ IP 67 Rated.

Industrial Ethernet Double-Ended Data Cables,

4-Twisted Pair, 24 AWG Stranded, PVC Teal Jacket,

High-Flex and Shielded, Standard Coding.

0985 656 104/...M: 8-Pin, RJ45 to M12-Female

Receptacle, IP 65/IP 67 Rated.

Industrial Ethernet Double-Ended Data Cables,

4-Twisted Pair, 24 AWG Stranded, PVC Teal Jacket,

High-Flex and Shielded, Standard Coding.

0985 656 500/...M: 8-Pin, RJ45 to RJ45,

IP 65 Rated.

0985 656 100/...M | 0985 656 101/...M |

0985 656 103/...M

0985 656 104

0985 656 500
