1-717-217-2299 www.lumberg-automationusa.com124
FWD 5
FWD 5
FWD 5
RSU 6-RKU A 6-203/0,6 M | RKU A 6-203/...M
RSU 6-RKU 6-204/0,6 M | RKU 6-204/...M
0905 204 302/0,6 M | 0905 204 301/...M | 0905 204 303/...M
Part No.
RSU 6-RKU A 6-203/0,6 M
RKU A 6-203/5 M
RKU A 6-203/10 M
RKU A 6-203/15 M
Part No.
RSU 6-RKU 6-204/0,6 M
RKU 6-204/5 M
RKU 6-204/10 M
RKU 6-204/15 M
Part No.
0905 204 302/0,6 M
0905 204 301/5 M
0905 204 301/10 M
0905 204 301/15 M
0905 204 303/5 M
0905 204 303/10 M
0905 204 303/15 M
Profibus Power Supply Cable.
RSU 6-RKU A 6-203/0,6 M: Double-Ended (molded on
both sides) with M23-Male Connector and
M23-Female Connector, 6-Poles (Pin 1, 2, 3
assigned), 0.6 Meters.
RKU A 6-203/...M: Single-Ended (molded on one
side) with M23-Female Connector, 6-Poles (Pin 1, 2,
3 assigned).
– for output/mixing modules (0970 PSL 2xx) –
Profibus Power Supply Cable.
RSU 6-RKU 6-204/0,6 M: Double-Ended (molded on
both sides) with M23-Male Connector and
M23-Female Connector, 6-Poles, 0.6 Meters.
RKU 6-204/...M: Single-Ended (molded on one side)
with M23-Female Connector, 6-Poles.
Profibus Power Supply Cable.
0905 204 302/0,6 M: Double-Ended (molded on both
sides) with 7/8”-Male Connector and 7/8”-Female
Connector, 5-Poles, 0.6 Meters.
0905 204 301/...M: Single-Ended (molded on one
side) with 7/8”-Female Connector, 5-Poles.
0905 204 303/...M: Single-Ended (molded on one
side) with 7/8”-Male Connector, 5-Poles.
Profibus
Profibus-DP-Power Cables
FWD 5RKU E 6-203/...M
Part No.
RKU E 6-203/5 M
RKU E 6-203/10 M
RKU E 6-203/15 M
Profibus Power Supply System/Sensor Cable.
Single-Ended (molded on one side) with M23-Female
Connector, 6 Poles (Pin 1, 4, 5 assigned)
– for modules with inputs-only (0970 PSL 1xx) –
