Actuator/Sensor Distribution Boxes
M12 Distribution Boxes
M12-Distribution Box
Actuator-/Sensor-Distribution Box with LED (PnP)
to Connect 4 Standard-Sensors and 4-Standard
Actuators with Separate Power Supply for Inputs and
Outputs, Top Entry, 8-Ports, M12 Sockets, 4-Poles, 1
Signal per Port. IP 67 Rated.
M12-Distribution Box
Actuator-/Sensor-Distribution Box, Top Entry, 6- and
8-Ports, M12 Sockets, 4-Poles, 1 Signal per Port, with
On-Board M23 Quick Disconnect. IP 67 Rated.
M12-Distribution Box
Actuator-/Sensor-Distribution with LED (PnP), Top
Entry, 4-, 6- and 8-Ports, M12 Sockets, 4-Poles,
1 Signal per Port, with On-Board M23 Quick
Disconnect. IP 67 Rated.
Part No.
ASBS 8/LED 5-4/4E-4A
Part No.
ASBS 6 5-4
ASBS 8 5-4
Part No.
ASBS 4 / LED 5-4
ASBS 6 / LED 5-4
ASBS 8 / LED 5-4
ASBS 8/LED 5-4/4E4A
ASBS
ASBS.../LED
M12-Distribution Box
Actuator-Distribution Box, Top Entry, 4- and 8-Ports,
M12 Sockets, 3-Poles, 2 Signal per Port for Dual
Solenoids with Integrated Mini Quick Disconnect
Home Run Connector. IP 67 Rated.
Cable Type: 138 | 139
PUR, black
Part No.
ASBV 4 4-3-138/RS120M
ASBV 8 4-3-139/RS190M
ASBV
