www.lumberg-automationusa.com 1-717-217-2299 115

DeviceNet

DeviceNet Field Attachable Connectors

0936 DMC 301 | 0936 DMC 302 | 0936 DMC 303

0936 DFC 101

0936 DFC 301 | 0936 DFC 303

0936 DMC 102

0936 DFC 102

Part No.

0936 DMC 301

0936 DMC 302

0936 DMC 303

Part No.

0936 DFC 101

Part No.

0936 DFC 301

0936 DFC 303

Part No.

0936 DMC 102

Part No.

0936 DFC 102

7/8” Field Attachable, Male Straight

Field Attachable Connector, 7/8”-Male Straight,

5-Poles with Threaded Joint, Assembling with Screw

Terminals. IP 67 Rated.

Cable OD

0936 DMC 301: 6.0mm - 8.0 mm

0936 DMC 302: 8.8mm - 10,0mm

0936 DMC 303: 12.0mm - 14.0mm

M12 Field Attachable, Female Straight

Field Attachable Connector, M12-Female Straight,

5-Poles with Threaded Joint, Assembling with Screw

Terminals. IP 67 Rated.

Cable OD

0936 DFC 101: 4.0mm - 8.0 mm

7/8” Field Attachable, Female Straight

Field Attachable Connector, 7/8”-Female Straight,

5-Poles with Threaded Joint, Assembling with Screw

Terminals. IP 67 Rated.

Cable OD

0936 DMC 301: 6.0mm - 8.0 mm

0936 DMC 303: 12.0mm - 14.0mm

M12 Field Attachable, Male 90˚

Field Attachable Connector, M12-Male, 90˚, 5-Poles

with Threaded Joint, Assembling with Screw

Terminals. IP 67 Rated.

Cable OD

0936 DMC 102: 4.0mm - 8.0 mm

M12 Field Attachable, Female 90˚

Field Attachable Connector, M12-Female 90˚,

5-Poles with Threaded Joint, Assembling with Screw

Terminals. IP 67 Rated.

Cable OD

0936 DFC 102: 4.0mm - 8.0 mm

DeviceNet

1-717-217-2299 www.lumberg-automationusa.com116

DeviceNet

DeviceNet Receptacles

0936 DFC 151/...M

0936 DMC 152/...M

0936 DFC 152/...M

RSWF5-PCB

RKWF5-PCB

Part No.

0936 DFC 151/0.3 M

Part No.

0936 DMC 152/2 M

Part No.

0936 DFC 152/2 M

Part No.

RSWF5-PCB

Part No.

RKWF5-PCB

DeviceNet Receptacle, M12, Female, 5-Poles,

Assembled Descrete Wire, PG 9 Thread for

Panel Mount.

DeviceNet Receptacle, M12, Male, 5-Poles,

Assembled Thin Cable, PG 9 Thread for Panel Mount.

DeviceNet Receptacle, M12, Female, 5-Poles,

Assembled Thin Cable, PG 9 Thread for Panel Mount.

DeviceNet Receptacle (PCB), M12, Male 90˚, 5-Poles,

PG 9 Panel Cut Out.

DeviceNet Receptacle (PCB), M12, Female 90˚,

5-Poles, PG 9 Panel Cut Out.

0936 DMC 151/...M

Part No.

0936 DMC 151/0.3 M

M12 DeviceNet Receptacle - Male

DeviceNet Receptacle, M12, Male, 5-Poles,

Assembled Descret Wire, PG 9 Thread for

Panel Mount.

www.lumberg-automationusa.com 1-717-217-2299 117

DeviceNet

DeviceNet Receptacles

0936 DFC 355/...M

Part No.

0936 DFC 355/1 M

0936 DFC 355/2 M

0936 DFC 355/5 M

DeviceNet Receptacle, 7/8”, Female, 5-Poles,

Assembled Thin Cable, 1/2-NPT Thread for Panel

Mount.

0936 DMC 355/...M

0936 DMC 352/0,3 M

0936 DMC 353/...M

0936 DFC 353/...M

0936 DFC 352/0,3 M

Part No.

0936 DMC 355/1 M

0936 DMC 355/2 M

0936 DMC 355/3 M

0936 DMC 355/4 M

0936 DMC 355/5 M

Part No.

0936 DMC 352/0.3 M

Part No.

0936 DMC 353/0.5 M

0936 DMC 353/1 M

0936 DMC 353/2 M

0936 DMC 353/5 M

Part No.

0936 DFC 353/1 M

0936 DFC 353/2 M

0936 DFC 353/5 M

Part No.

0936 DFC 352/0.3 M

DeviceNet Receptacle, Male 7/8” 5-Poles, Assembled

Thin Cable, 1/2-NPT Thread for Panel Mount.

DeviceNet Receptacle, Male 7/8” 5-Poles, Assembled

Descrete Wire, 1/2-NPT Thread for Panel Mount.

DeviceNet Receptacle, Male 7/8” 5-Poles, Assembled

Thick Cable, 1/2-NPT Thread for Panel Mount.

DeviceNet Receptacle, Female 7/8” 5-Poles,

Assembled Thick Cable, 1/2-NPT Thread for Panel

Mount.

DeviceNet Receptacle, Female 7/8” 5-Poles,

Assembled Descrete Wire, 1/2-NPT Thread for Panel

Mount.
