1-717-217-2299 www.lumberg-automationusa.com106

DeviceNet

DeviceNet-Devices, 16 IN | 8 0UT

0930 DSL 108

0930 DSL 109

0930 DSL 312

0930 DSL 313

0930 DSL 107

Part No.

0930 DSL 108

Part No.

0930 DSL 109

Part No.

0930 DSL 312

Part No.

0930 DSL 313

Part No.

0930 DSL 107

16 IN (p)

DeviceNet Device with 16 Digital Inputs (p-switching)

to Connect Standard Sensors, M12 Socket, Rotary

Switches for Addressing, M12 Bus Connection.

16 IN (n)

DeviceNet Device with 16 Digital Inputs (n-switching)

to Connect Standard Sensors, M12 Socket, Rotary

Switches for Addressing, M12 Bus Connection.

16 IN (p)

DeviceNet Device with 16 Digital Inputs (p-switching)

to Connect Standard Sensors, M12 Socket, Rotary

Switches for Addressing, 7/8” Bus Connection.

16 IN (n)

DeviceNet Device with 16 Digital Inputs (n-switching)

to Connect Standard Sensors, M12 Socket, Rotary

Switches for Addressing, 7/8” Bus Connection.

8 OUT

DeviceNet Device with 8 Digital Outputs (2 A) to

Connect Standard Actuators, M12 Socket, Rotary

Switches for Addressing, M12 Bus Connection, 7/8”

Actuator Supply.

www.lumberg-automationusa.com 1-717-217-2299 107

DeviceNet

DeviceNet-Devices, 8 OUT | 16 OUT | 8 IN/8 OUT

0930 DSL 311

0930 DSL 114

0930 DSL 315

0930 DSL 113

0930 DSL 314

Part No.

0930 DSL 311

Part No.

0930 DSL 114

Part No.

0930 DSL 315

Part No.

0930 DSL 113

Part No.

0930 DSL 314

8 OUT

DeviceNet Device with 8 Digital Outputs (2 A) to

Connect Standard Actuators, M12 Socket, Rotary

Switches for Addressing, 7/8” Bus Connection, 7/8”

Actuator Supply.

16 OUT

DeviceNet Device with 16 Digital Outputs (0.5 A) to

Connect Standard Actuators, M12 Socket, Rotary

Switches for Addressing, M12 Bus Connection, 7/8”

Actuator Supply.

16 OUT

DeviceNet Device with 16 Digital Outputs (0.5 A) to

Connect Standard Actuators, M12 Socket, Rotary

Switches for Addressing, 7/8” Bus Connection, 7/8”

Actuator Supply.

8 IN/8 OUT

DeviceNet Device with 8 Digital Inputs to Connect

Standard Sensors and 8 Digital Outputs (0.5 A) to

Connect Standard Actuators, M12 Socket, Rotary

Switches for Addressing, M12 Bus Connection, 7/8”

Actuator Supply.

8 IN/8 OUT

DeviceNet Device with 8 Digital Inputs to Connect

Standard Sensors and 8 Digital Outputs (0.5 A) to

Connect Standard Actuators, M12 Socket, Rotary

Switches for Addressing, 7/8” Bus Connection, 7/8”

Actuator Supply.

DeviceNet

1-717-217-2299 www.lumberg-automationusa.com108

DeviceNet

Passive-Device, DeviceNet-Thin Cable

0931 DNC 301

0935 253 103/...M | 0935 253 104/...M | 0935 253 105/...M

0935 253 101/...M

0935 253 102/...M

Part No.

0931 DNC 301

Part No.

0935 253 103/0,3 M

0935 253 103/0,6 M

0935 253 103/1 M

0935 253 103/2 M

0935 253 103/3 M

0935 253 103/5 M

0935 253 103/10 M

0935 253 103/15 M

0935 253 103/20 M

0935 253 103/25 M

0935 253 104/1 M

0935 253 104/3 M

0935 253 104/5 M

0935 253 104/10 M

0935 253 104/15 M

0935 253 105/1 M

0935 253 105/3 M

0935 253 105/5 M

0935 253 105/10 M

0935 253 105/15 M

Part No.

0935 253 101/1 M

0935 253 101/2 M

0935 253 101/3 M

0935 253 101/5 M

Part No.

0935 253 102/1 M

0935 253 102/2 M

0935 253 102/3 M

0935 253 102/5 M

Passive DeviceNet Distribution Box, 7/8” Bus-In/Bus-

Out Connection for Trunk Line, 8 x M12 Branches for

Drop Line.

DeviceNet-Thin Cable

0935 253 103/...M: Double-Ended with M12 Male

Connector and M12 Female Connector, 5-Poles.

0935 253 104/...M: Single-Ended with M12 Male

Connector, 5-Poles.

0935 253 105/...M: Single-Ended with M12 Female

Connector, 5-Poles.

DeviceNet-Thin Cable

Double-Ended with 7/8” Male Connector and M12

Female Connector, 5-Poles.

DeviceNet-Thin Cable

Double-Ended with M12 Male Connector and 7/8”

Female Connector, 5-Poles.
