LioN-Link
Wiring Accessories I/O Modules
0942 UEM 60.../63... 0942 UEM 65... LioN-Link Connection , 5-Poles Part No. Description
Actuator/sensor connection, 3 and 5 Poles Part No. Description
Power supply connection, 5-Poles Part No. Description
0935 253 10... CAN/ DeviceNet signal cable, Thin Cable, M12
RST 5... Actuator / sensor cordset,
M12 male connector with molded cable
RK(W)T 5... Actuator / sensor cordset, M12 female or female
right angle connector with molded cable
RST 5-RKT 5... Actuator / sensor double-ended cordset,
M12 male to M12 female connector
RSC(W) 5/9
RKC(W) 5/9
Field attachable connector, M12 male or male
right angle connector or M12 female or female
right angle connector, with threaded joint
0906 UTP 104 T-connector/ splitter, 2-way, with mounting hole,
M12 female connector with two M12 male
connectors,
5-poles
RSMV... Actuator / sensor cordset,
M8 male connector with molded cable
RSMC...
RSMCW...
Field attachable connector, M8 male/ male right
angle connector, with threaded joint
RST... Actuator / sensor cordset,
M12 male connector with molded cable
RSMV-RKM(WV)...
RST-RKM...
Actuator / sensor double-ended cordset,
M8/M12 male connector and M8/M12 female/
female right angle connector
RSC...
RKCW...
Field attachable connector, M12 male or male
right angle connector, with threaded joint
RKT 5...
RKWT 5...
RKT 5-226/...M
Actuator / sensor cordset,
M12 female or female right angle connector
with molded cable
0906 UTP 101 T-connector with M12 male/female connector,
5 poles
