www.lumberg-automationusa.com 1-717-217-2299 79

PowerCINCH™ Trunk and Drop Cordsets

4-Pole, Single Key, Black PVC Cable

PowerCINCH™ T-Tap Trunk and Power Drop

4-Pole, Single Key, Black PVC Cable

RSRK 40D

TAP 40D-RK 40D

RSRK 40A

Part No.

RSRK 40D-10T/2 M RSRK 40D-10T/15 M

RSRK 40D-10T/3 M RSRK 40D-10T/20 M

RSRK 40D-10T/4 M RSRK 40D-10T/25 M

RSRK 40D-10T/5 M RSRK 40D-10T/35 M

RSRK 40D-10T/6 M RSRK 40D-10T/40 M

RSRK 40D-10T/8 M RSRK 40D-10T/45 M

RSRK 40D-10T/10 M RSRK 40D-10T/50 M

RSRK 40D-10T/14 M

Part No.

TAP 40D-RK 40D

Part No.

TAP 40D-RK 40A

Part No.

RSRK 40A-14D/1.5 M RSRK 40A-14D/15 M

RSRK 40A-14D/2.5 M RSRK 40A-14D/18 M

RSRK 40A-14D/3 M RSRK 40A-14D/20 M

RSRK 40A-14D/4 M RSRK 40A-14D/25 M

RSRK 40A-14D/5 M RSRK 40A-14D/30 M

RSRK 40A-14D/6 M RSRK 40A-14D/35 M

RSRK 40A-14D/8 M RSRK 40A-14D/40 M

RSRK 40A-14D/10 M RSRK 40A-14D/50 M

RSRK 40A-14D/12 M

Trunk Cordset, Male Str to Female Str

PowerCINCH 1 3/8” Double Ended Cordsets, 4-Pole,

10 AWG Stranded Copper Conductors, Single Key,

Black PVC Jacket, .79” Outside Diameter, Nut

Anodized Aluminum, Brass, Gold Over Nickel Plated

Contacts, Black PVC Insert, 25 A Current Rating,

600 V Voltage Rating, -20° to +105° C Temperature

Rating, IP 67 Rated, UL Recognition: TC-ER, STOOW.

T-Tap Trunk and Power Drop –1 3/8”

PowerCINCH™ T TAP (1 3/8”) with 10 AWG Power

Drop, 4-Pole, Single Key, Black PVC Molded Body,

Aluminum Anodized Coupling Nut, Brass-Gold Over

Nickel Plated, Black PVC Insert, 25 A Current Rating,

600 V Voltage Rating, -20° to +105° C Temperature

Rating, IP 67 Rated.

T-Tap Trunk and Power Drop – 7/8”

PowerCINCH™ T TAP (7/8”) with 14 AWG Power

Drop, 4-Pole, Single Key, Black PVC Molded Body,

Aluminum Anodized Coupling Nut, Brass-Gold Over

Nickel Plated, Black PVC Insert, 25 A Current Rating

Trunk, 15 A Drop, 600 V Voltage Rating, -20° to

+105° C Temperature Rating, IP 67 Rated.

Drop Cordset, Male Str to Female Str

PowerCINCH 7/8” Double Ended Cordsets, 4-Pole, 14

AWG Stranded Copper Conductors, Single Key, Black

PVC Jacket, .62” Outside Diameter, Nut Aluminum

E-Coating, Brass, Gold Over Nickel Plated Contacts,

Black PVC Insert, 15 A Current Rating, 600 V Voltage

Rating, -20° to +105° C Temperature Rating, IP 67

Rated, UL Recognition: TC-ER, STOOW.

PowerCINCH™

1-717-217-2299 www.lumberg-automationusa.com80

PowerCINCH™ In-Line Trunk Reducers

4-Pole, Single Key

PowerCINCH™ Trunk Feeder Receptacles

4-Pole, Single Key

PowerCINCH™ Drop-Branch Receptacles

4-Pole, Single Key

RS40D-RK40A

RSF 40D-3/4-10T

RSF 40A-14D

RKF 40D-3/4-10T

Part No.

RS40D-RK40A

Part No.

RSF 40D-3/4-10T/1 M

RSF 40D-3/4-10T/3 M

Part No.

RSF 40A-14D/1 M

RSF 40A-14D/3 M

Part No.

RKF 40D-3/4-10T/1 M

RKF 40D-3/4-10T/3 M

In-Line Reducers

PowerCINCH™ In-Line Reducer, 4-Pole Male to

Female with Single Key. PVC Black Molded Body,

Aluminum Anodized Coupling Nut, Copper Alloy

Contacts, PVC Black Insert, 15 A Current Rating,

600 V Voltage Rating, -20° to +105° C Temperature

Rating, IP 67 Rated.

Trunk Feeder Receptacle, Male

PowerCINCH™ Trunk Feeder Receptacles, Male,

4-Pole, 10 AWG Stranded Copper Wire, 3/4-14 NPT,

Single Key, Black PVC Molded Insert, Aluminum

Anodized Shell, Brass-Gold Over Nickel Plated, 25 A

Current Rating, 600 V Voltage Rating, -20° to +105°

C Temperature Rating, IP 67 Rated.

Drop-Branch Receptacle, Male

PowerCINCH™ Drop-Branch Receptacles, Male,

4-Pole, 14 AWG Stranded Copper Wire, 1/2-14 NPT,

Single Key, Black PVC Molded Insert, Aluminum

Anodized Shell, Brass-Gold Over Nickel Plated,

15 A Current Rating, 600 V Voltage Rating,

-20° to +105° C Temperature Rating, IP 67 Rated.

Trunk Feeder Receptacle, Female

PowerCINCH™ Trunk Feeder Receptacles, Female,

4-Pole, 10 AWG Stranded Copper Wire, 3/4-14 NPT,

Single Key, Black PVC Molded Insert, Aluminum

Anodized Shell, Brass-Gold Over Nickel Plated,

25 A Current Rating, 600 V Voltage Rating,

-20° to +105° C Temperature Rating, IP 67 Rated.

www.lumberg-automationusa.com 1-717-217-2299 81

PowerCINCH™ Drop-Branch Receptacles

4-Pole, Single Key

PowerCINCH™ Closure Caps

RKF 40A-14D

RSV-D

RKV-D

RSV-A

Part No.

RKF 40A-14D/1 M

RKF 40A-14D/3 M

Part No.

RSV-D

Part No.

RKV-D

Part No.

RSV-A

Part No.

RKV-A

Drop-Branch Receptacle, Female

PowerCINCH™ Drop-Branch Receptacles, Female,

4-Pole, 14 AWG Stranded Copper Wire, 1/2-14 NPT,

Single Key, Black PVC Molded Insert, Aluminum

Anodized Shell, Brass-Gold Over Nickel Plated,

15 A Current Rating, 600 V Voltage Rating,

-20° to +105° C Temperature Rating, IP 67 Rated.

Closure Cap-Trunk Male

PowerCINCH™ Closure Cap for Male Connector,

Internal Threads.

Closure Cap-Trunk Female

PowerCINCH™ Closure Cap for Female Connector,

Internal Threads.

Closure Cap-Trunk Male

PowerCINCH™ Closure Cap for Male Connector,

Internal Threads.

Closure Cap-Trunk Female

PowerCINCH™ Closure Cap for FeMale Connector,

Internal Threads.

PowerCINCH™

RKV-A

PowerCINCH™
