www.lumberg-automationusa.com 1-717-217-2299 61

Receptacle Connector, M12 Male, 5-Poles, For Front

Mounting, Adjustable, Assembled Stranded Wire,

Solder Contacts Potted with Epoxy, Chassis Side

Thread M16 x 1.5 Screw Connection,

IP 67 Rated.

– especially suitable for Proﬁbus –

Receptacle Connector, M12 Male, 5-Poles, For Front

Mounting, Adjustable, Assembled Stranded Wire,

Solder Contacts Potted with Epoxy, Chassis Side

Thread M16 x 1.5 Screw Connection,

IP 67 Rated.

– especially suitable for DeviceNet and CANopen

–

Receptacle Connector, M12 Male, 4-, 5- and 8-Poles,

For Front Mounting, Stainless Steel Housing,

Assembled Stranded Wire, Solder Contacts Potted

with Epoxy, Chassis Side Thread M16 x 1.5 Screw

Connection (Panel Nut RSKFM 16), IP 69 K Rated.

– especially designed for use in Food

Processing equipment –

0976 PMC 151

0936 DMC 351

PRSFM.../0,5 M

Part No.

0976 PMC 151

Part No.

0936 DMC 351

Part No.

PRSFM 4/0,5 M

PRSFM 5/0,5 M

PRSFM 8/0,5 M

Receptacle Connectors In Accordance With IEC 61076-2-101

M12-Receptacles

Receptacle Connector, M12 Male 5-Poles to Terminal

Block Recepatcle with Screw Terminal, IP 67 Rated

(M12 end).

– especially designed for use as panel

feed through –

RSF 5 TB

Part No.

RSF 5 TB

Receptacles

Receptacle Connector, M12 Female, 3-, 4-, 5- and

8-Poles, For Front Mounting, Assembled Stranded

Wire, Solder Contacts Potted with Epoxy, Chassis

Side Thread M16 x 1.5 Screw Connection (Panel Nut

RSKFM 16), IP 67 Rated.

RKFM.../0,5 M

Part No.

RKFM 4-3/0,5 M

RKFM 4/0,5 M

RKFM 5/0,5 M

RKFM 8/0,5 M

Receptacles

1-717-217-2299 www.lumberg-automationusa.com62

Receptacle Connectors In Accordance With IEC 61076-2-101

M12-Receptacles

Receptacle Connector, M12 Female, 5-Poles, For

Front Mounting, Assembled Stranded Wire, Potted

with Epoxy, Chassis Side Thread M20 x 1.5 Screw

Connection (Panel Nut RSKFM 20), IP 67 Rated.

Receptacle Connector, M12 Female 5-Poles to

Terminal Block Recepatcle with Screw Terminal, IP 67

Rated (M12 end).

– especially designed for use as panel

feed through –

Receptacle Connector, M12 Female, 3-, 4-, 5- and

8-Poles, For Front Mounting, Adjustable, Assembled

Stranded Wire, Potted with Epoxy, Chassis Side

Thread M16 x 1.5 Screw Connection

IP 67 Rated.

RKFM.../20/0,5 M

RKF 5 TB

RKFPM.../0,5 M

Part No.

RKFM 5/20/0,5 M

Part No.

RKF 5 TB

Part No.

RKFPM 4-3/0,5 M

RKFPM 4/0,5 M

RKFPM 5/0,5 M

RKFPM 8/0,5 M

Receptacle Connector, M12 Female, 4-, 5- and

8-Pole, For Rear Mounting, Assembled Stranded

(22 AWG and 24 AWG) Wire, Potted with Epoxy,

Chassis Side Thread PG 9 Screw Connection, IP 67

Rated.

Receptacle Connector, M12 Female, 3-, 4-, 5- and

8-Pole, For Front Mounting, Assembled Stranded

(22 AWG and 24 AWG) Wire, Potted with Epoxy,

Chassis Side Thread 1/2”-14 NPT Screw Connection,

IP 67 Rated.

RKF 4...8-S3103/0,5 M

RKF 4-3...8-1/2-14/0,5 M

Part No.

RKF 4-S3103,5 M

RKF 5-S3103,5 M

RKF 8-S3103,5 M

Part No.

RKF 4-3-1/2-14/0,5 M

RKF 4-1/2-14/0,5 M

RKF 5-1/2-14/0,5 M

RKF 8-1/2-14/0,5 M

Receptacle Connector, M12 Female, 3-, 4-, 5- and

8-Pole, For Front Mounting, Assembled Stranded

(22 AWG and 24 AWG) Wire, Solder Contacts Potted

with Epoxy, Chassis Side Thread PG 9 Screw

Connection, IP 67 Rated.

RKF 3...8/0,5 M

Part No.

RKF 3/0,5 M

RKF 4/0,5 M

RKF 5/0,5 M

RKF 8/0,5 M

www.lumberg-automationusa.com 1-717-217-2299 63

Receptacle Connectors In Accordance With IEC 61076-2-101

M12-Receptacles

Receptacle Connector, M12 Female, 5-Poles, For

Front Mounting, Adjustable, Assembled Stranded

Wire, Potted with Epoxy, Chassis Side Thread M16 x

1.5 Screw Connection

IP 67 Rated.

– especially suitable for DeviceNet and CANopen

–

Receptacle Connector, M12 Female, 4-Poles,

D Coding, For Front Mounting, Adjustable, Assembled

Stranded Wire, Potted with Epoxy, Chassis Side

Thread M16 x 1.5 Screw Connection

IP 67 Rated.

– especially suitable for Industrial Ethernet –

Receptacle Connector, M12 Female, 4-, 5- and

8-Poles, For Front Mounting, Stainless Steel Housing,

Assembled Stranded Wire, Solder Contacts Potted

with Epoxy, Chassis Side Thread M16 x 1.5 Screw

Connection (Panel Nut RSKFM 16), IP 69 K Rated.

– especially designed for use in Food

Processing equipment –

0936 DFC 351

0986 EFC 151 A

PRKFM.../0,5 M

Part No.

0936 DFC 351

Part No.

0986 EFC 151 A

Part No.

PRKFM 4/0,5 M

PRKFM 5/0,5 M

PRKFM 8/0,5 M

Receptacle Connector, M12 Female, 5-Poles, B

Coding, For Front Mounting, Adjustable, Assembled

Stranded Wire, Potted with Epoxy, Chassis Side

Thread M16 x 1.5 Screw Connection

IP 67 Rated.

– especially suitable for Proﬁbus –

0976 PFC 151

Part No.

0976 PFC 151

Receptacles

Receptacle Connector, M12 Male Insert, 4-, 5- and

8-Poles, For Sensors with Short Solder Contacts for

Printed Circuit Board Mounting.

RSEL

Part No.

RSEL 4

RSEL 5

RSEL 8

Receptacle Connector, M12 Male Insert, 4- and

5-Poles, For Sensors with Short Solder Contacts.

RSE...L: with Ventalation Hole 2,0 mm

RSEO: pin 5 Not leading

RSE | RSEO

Part No.

RSE 4

RSE 4 L

RSE 5

RSEO 5

Receptacles
