1-717-217-2299 www.lumberg-automationusa.com58

Receptacle Connector, M12 Male, 5-Poles, B-Coding,

For Front Mounting, Print Contacts, Chassis Side

Thread PG 9.

– especially suitable for Proﬁbus –

Receptacle Connector, M8 Male, 3- and 4-Pole for

Sensors with Snap-In Joint, Translucent Ring, Short

Solder Contacts, Hollow Contacts (RSMEJ) or Solid

Contacts (RSMEH) on Solder Side.

Receptacle Connector, M8 Male, 3- and 4-Pole for

Sensors with Combined Snap-In/Threaded Joint,

Light Indicator Windows, Mounting Hole for LED,

Short Solder Contacts, Hollow Contacts (RSMED) or

Solid Contacts (RSMEB) on Solder Side.

Receptacle Connector, M8 Male, 8-Pole for Sensors

with Combined Snap-In/Threaded Joint, 4 Light

Indicator Windows, Mounting Hole for LED, Short

Solder Contacts, Hollow Contacts on Solder Side.

Receptacle Connector, M8 Male, 3- and 4-Pole for

Sensors with Stainless Steel Housing, Threaded Joint,

4 Light Indicator Windows, Mounting Hole for LED,

Short Solder Contacts, Hollow Contacts on Solder

Side.

RSHL.../S 5,5

0976 PMC 152

RSEMJ | RSMEH

RSMED | RSMEB

RSMEDG

RSMEDGN

Part No.

RSHL 4/ S 5,5

RSHL 5/ S 5,5

RSHL 5B/S 5,5

RSHL 8/ S 5,5

Part No.

0976 PMC 152

Part No.

RSMEJ 3

RSMEH 3

RSMEH 4

Part No.

RSMED 3

RSMED 4

RSMEB 3

RSMEB 4

Part No.

RSMEDG 8

Part No.

RSMEDGN

Receptacle Connector, M12 Male, 4-, 5- and 8-Pole

for Rear Mounting, Print Contacts, Chassis Side

Thread PG 9 (Panel Nut RSKF 9).

Receptacle Connectors In Accordance With IEC 61076-2-104

M8-Receptacles

Receptacle Connectors In Accordance With IEC 61076-2-101

M12-Receptacles

www.lumberg-automationusa.com 1-717-217-2299 59

Receptacle Connector, M12 Male, 3-, 4- and 5-Poles,

For Front Mounting, Solder Connections, Chassis Side

Thread M16 x 1.5 (Panel Nut RSKFM 16).

Receptacle Connector, M12 Male, 4- and 5-Pole for

For Front Mounting, Stainless Steel Housing, Solder

Connections, Solder Contacts Not Potted, Chassis

Side Thread M16 x 1.5 (Panel Nut RSKFM 16).

– especially designed for use in Food

Processing Equipment –

Receptacle Connector, M12 Female, 4-, 5- and 8-Pole

for For Rear Mounting, Solder Pin Contacts, Chassis

Side Thread PG 9 (Panel Nut RSKF 9).

Receptacle Connector, M12 Female, 4-Pole,

D-Coding, For Rear Mounting, Printed Contacts,

Chassis Side Thread PG 9 (Panel Nut RSKF 9).

0986 EFC 152: 4 Poles, D Coding

Receptacle Connector, M12 Female, 5-Pole, B-Coding,

For Front Mounting, Printed Contacts, Chassis Side

Thread PG 9 (Panel Nut RSKF 9).

– especially suitable for Proﬁbus –

RSFM

PRSFM

RKHL.../S 5,5

0986 EFC 152

0976 PFC 152

Part No.

RSFM 3

RSFM 4

RSFM 5

Part No.

PRSFM 4

PRSFM 5

Part No.

RKHL 4/ S 5,5

RKHL 5/ S 5,5

RKHL 5B/S 5,5

RKHL 8/ S 5,5

Part No.

0986 EFC 152

Part No.

0976 PFC 152

Receptacle Connectors In Accordance With IEC 61076-2-101

M12-Receptacles

Receptacles

FWD

Part No.

FWD 5

FWD 5B

Receptacle Connector, Combined FIXCON/M12 5-Pole

Male to Combined FIXCON/M12 Female Connector,

Available in Standard or B Coding, IP 67 Rated.

– especially designed for use as panel

feed through –

Receptacles

1-717-217-2299 www.lumberg-automationusa.com60

Receptacle Connector, M12 Male, 3-, 4-, 5- and

8-Pole, For Front Mounting, Assembled Stranded

Wire, Potted with Epoxy, Chassis Side Thread M16 x

1.5 Screw Connection, IP 67 Rated.

Receptacle Connector, M12 Male, 3-, 4-, 5- and

8-Pole, For Front Mounting, Assembled Stranded

(22 AWG and 24 AWG) Wire, Potted with Epoxy,

Chassis Side Thread PG 9 Screw Connection, IP 67

Rated.

Receptacle Connector, M12 Male, 4-, 5- and 8-Pole,

For Back Mounting, Assembled Stranded

(22 AWG and 24 AWG) Wire, Potted with Epoxy,

Chassis Side Thread PG 9 Screw Connection, IP 67

Rated.

Receptacle Connector, M12 Male, 3-, 4-, 5- and

8-Pole, For Front Mounting, Assembled Stranded

(22 AWG and 24 AWG) Wire, Potted with Epoxy,

Chassis Side Thread 1/2”-14 NPT Screw Connection,

IP 67 Rated.

Receptacle Connector, Combined FIXCON/M12 Male,

5-Pole, For Front Mounting, Assembled Stranded

Wire, Potted with Epoxy, Chassis Side Thread M20 x

1.5 Screw Connection, IP 67 Rated.

Receptacle Connector, M12 Male, 3-, 4-, 5- and

8-Pole, For Front Mounting, Adjustable, Assembled

Stranded Wire, Solder Contacts Potted with Epoxy,

Chassis Side Thread M16 x 1.5 Screw Connection,

IP 67 Rated.

RSFM.../0,5 M

RSF 3...8/0,5 M

RSF 4...8-S3103/0,5 M

RSF 3...8-1/2-14/0,5 M

RSFM.../20/0,5 M

RSFPM.../0,5 M

Part No.

RSFM 3/0,5 M

RSFM 4/0,5 M

RSFM 5/0,5 M

RSFM 8/0,5 M

Part No.

RSF 3/0,5 M

RSF 4/0,5 M

RSF 5/0,5 M

RSF 8/0,5 M

Part No.

RSF 4-S3103/0.5 M

RSF 5-S3103/0.5 M

RSF 8-S3103/0.5 M

Part No.

RSF 3-1/2-14/0,5 M

RSF 4-1/2-14/0,5 M

RSF 5-1/2-14/0,5 M

RSF 8-1/2-14/0,5 M

Part No.

RSFM 3/20/0,5 M

RSFM 4/20/0,5 M

Part No.

RSFPM 3/0,5 M

RSFPM 4/0,5 M

RSFPM 5/0,5 M

RSFPM 8/0,5 M

Receptacle Connectors In Accordance With IEC 61076-2-101

M12-Receptacles
