1-717-217-2299 www.lumberg-automationusa.com52

M12-Duo-Male - 2xM12-Male/Female

T-Splitter, 3-Pole, with Two Female Connectors,

Self-Locking Threaded Joint, with Home Run Cable,

IP 67 Rated.

Cable Types:

225 = PUR, halogen-free, black

M12-Male - 2xM8 Female

T-Splitter, 3-Poles, with One M12 Male and Two M8

Female Connectors, Self-Locking Threaded Joint,

IP 67 Rated.

M12-Male - 2xM12 Female

T-Splitter, 2-Way, 4-Poles with One M12-Male

Connector and Two M12-Female Connectors. IP 67

Rated.

M12-Male - 2xM12 Female

T-Splitter, 3- and 5-Poles with One M12 Male and

Two M12 Female Connectors, Self-Locking Threaded

Joint, IP 67 Rated.

ASBS 2 M12-5 1-1: 1 to 1 wired through

ASBSA 2 M12-3: with AND-circuit

ZV 2

ASBS 2 M8

ASBS 2 M12-S-2326 | ASBS 2 M12-S-2325

ASBS 2 M12 | ASBSA 2 M12

T-Splitters and Adapters

2-Port-Distributor, M8-T-Distributor, M12-T-Distributor

Part No.

ZV 2 4-3-225/2 M

ZV 2 4-3-225/5 M

ZV 2 4-3-225/10 M

Part No.

ASBS 2 M8

Part No.

ASBS 2 M12-S-2326

ASBS 2 M12-S-2325

Part No.

ASBSA 2 M12-3

ASBS 2 M12-5S

ASBS 2 M12-5

ASBS 2 M12-5 A B

ASBS 2 M12-5S A B

Wired to work with ASBV distribution Boxes

ASBSA 2 M12-3 A B

M12 A B

ASBS 2 M12-S-2326

ASBS 2 M12-S-2325

M12 M8 A M8 B

M12 A B

www.lumberg-automationusa.com 1-717-217-2299 53

M12-Male - 2xM12-Female

T-Splitter, 4- and 5-Pole, 90˚-version with One M12

Male Connector and Two M12 Female Connectors,

Self-Locking Threaded Joint, IP 67 Rated.

M12-Male - 2xM8 Female

T-Splitter, 3-Poles, 90˚ -version (on M12) with One

M12 Male and Two M8 Female Connectors, Self-

Locking Threaded Joint, IP 67 Rated.

M12-Male - 2xM12 Female

T-Splitter, 5-Poles with One M12 Male and Two M12

Female Connectors and Mounting Hole, IP 67 Rated.

M12-Male - 2xM12 Male/Female

T-Splitter, 5-Poles with One M12 Female, One M12

Male and One M12 Female Connector, IP 67 Rated.

– especially suitable for DeviceNet and CANopen

modules with M12 bus connection –

7/8”-Female - 2x7/8” Male/Female

T-Splitter, 5-Poles with One 7/8” Female, One 7/8”

Male and One 7/8” Female Connector, IP 67 Rated.

– especially suitable for DeviceNet modules with

7/8” bus connection –

ASBS 2 M12...-90

ASBS 2 M8-90

FASBS 2 M12

0906 UTP 101

0906 UTP 301

T-Splitters and Adapters

2-Port-Distributor, M12-T-Distributor, 7/8”-T-Distributor

Part No.

ASBS 2 M12-4S-90

ASBS 2 M12-5-90

Part No.

ASBS 2 M8-90

Part No.

FASBS 2 M12-5S

Part No.

0906 UTP 101

Part No.

0906 UTP 301

ASBS 2 M12-5-90 A B

M12 A B

7/8” 7/8” A 7/8” B

ASBS 2 M12-4S-90 A B

M12 M8 A M8 B

Splitters and

Adapters

Splitters and Adapters

1-717-217-2299 www.lumberg-automationusa.com54

7/8”-Female - 2x7/8” Female/Male

T-Splitter, 3-Poles with One 7/8” Female, One 7/8”

Female and One 7/8” Male Connector, IP 67 Rated.

– especially suitable for DeviceNet and CANopen

modules with 7/8” bus connection –

7/8”-Female - 2x7/8” Female/Male

T-Splitter, 4-Poles with One 7/8” Female, One 7/8”

Male and One 7/8” Female Connector, IP 67 Rated.

– especially suitable for Auxillary Power with

7/8” power connection –

M23-Female - 2xM23 Male/Male

T-Splitter, 6-Poles with One M23 Female, and Two

M23 Male Connectors, IP 67 Rated.

– especially suitable for Proﬁbus and

Interbus modules –

M23-Female - 2xM23 Male/Female

T-Splitter, 12-Poles with One M23 Female, One M23

Male and One M23 Female Connector, IP 67 Rated.

– especially suitable for Proﬁbus Modules with

M23 Bus Connection for separate feeding of Power

Supply (System/Sensor System) and Proﬁbus

signals –

0906 UTP 303

0906 UTP 312

0906 UTP 201

0906 UTP 202

T-Splitters and Adapters

7/8”-T-Distributor, M23-T-Distributor

Part No.

0906 UTP 303

Part No.

0906 UTP 312

Part No.

0906 UTP 201

Part No.

0906 UTP 202

7/8” 7/8” A 7/8” B

M12-Female - 2x7/8” Male/Female

T-Splitter, 5-Poles with One M12 Female, One 7/8”

Male and One 7/8” Female Connector, IP 67 Rated.

– especially suitable for DeviceNet modules with

M12 bus connection –

0906 UTP 302

M12 7/8” A 7/8” B

Part No.

0906 UTP 302
