www.lumberg-automationusa.com 1-717-217-2299 49

Cordsets

Double-Ended

Mini 7/8” Double-Ended Cordsets, A Body Style

7/8” A Body-Male Str (ET) to Female Str

Mini Cordsets, Single Ended, 7/8” Male Straight with

External Threads to Female Straight Connector, 2-, 3-,

4- and 5-Poles with Molded Cable. IP 67 Rated.

Color Code: IEC

Cable Types: 18 AWG

731 | 637 | 794 = TPE, yellow

603 = PVC, yellow

645 | 602 = PUR, yellow

Color Code: Euro AC

Cable Types: 18 AWG

601 = PVC, yellow

7/8” A Body-Male Str (ET) to Female 90˚

Mini Cordsets, Single Ended, 7/8” Male Straight with

External Threads to Female 90˚ Connector, 2-, 3-, 4-

and 5-Poles with Molded Cable. IP 67 Rated.

Color Code: IEC

Cable Types: 18 AWG

731 | 637 | 794 = TPE, yellow

603 = PVC, yellow

645 | 602 = PUR, yellow

Color Code: Euro AC

Cable Types: 18 AWG

601 = PVC, yellow

RSRK 20...50

RSRKW 20...50

Part No. Part No.

RSRK 20-603/0.3 M RSRK 40-637/6 F

RSRK 20-603/0.6 M RSRK 40-637/12 F

RSRK 20-603/1 M RSRK 40-637/15 F

RSRK 20-603/2 M RSRK 40-637/20F

RSRK 20-603/5 M RSRK 40-637/30F

RSRK 30-731/6 F RSRK 40-602/0.3 M

RSRK 30-731/12 F RSRK 40-602/0.6 M

RSRK 30-731/15 F RSRK 40-602/1 M

RSRK 30-731/20 F RSRK 40-602/2 M

RSRK 30-731/30 F RSRK 40-602/5 M

RSRK 30-645/0.3 M RSRK 40-602/10 M

RSRK 30-645/0.6 M RSRK 50-794/6 F

RSRK 30-645/1 M RSRK 50-794/12 F

RSRK 30-645/2 M RSRK 50-794/15 F

RSRK 30-645/5 M RSRK 50-794/20 F

RSRK 30-601/0.3 M RSRK 50-794/30 F

RSRK 30-601/0.6 M

RSRK 30-601/1 M

RSRK 30-601/2 M

RSRK 30-601/5 M

RSRK 30-601/10 M

Part No. Part No.

RSRKW 20-603/0.3 M RSRKW 40-637/6 F

RSRKW 20-603/0.6 M RSRKW 40-637/12 F

RSRKW 20-603/1 M RSRKW 40-637/15 F

RSRKW 20-603/2 M RSRKW 40-637/20F

RSRKW 20-603/5 M RSRKW 40-637/30F

RSRKW 20-603/10 M RSRKW 40-602/0.3 M

RSRKW 30-731/6 F RSRKW 40-602/0.6 M

RSRKW 30-731/12 F RSRKW 40-602/1 M

RSRKW 30-731/15 F RSRKW 40-602/2 M

RSRKW 30-731/20 F RSRKW 40-602/5 M

RSRKW 30-731/30 F RSRKW 40-602/10 M

RSRKW 30-645/0.3 M RSRKW 50-794/6 F

RSRKW 30-645/0.6 M RSRKW 50-794/12 F

RSRKW 30-645/1 M RSRKW 50-794/15 F

RSRKW 30-645/2 M RSRKW 50-794/20 F

RSRKW 30-645/5 M RSRKW 50-794/30 F

RSRKW 30-601/0.3 M

RSRKW 30-601/0.6 M

RSRKW 30-601/1 M

RSRKW 30-601/2 M

RSRKW 30-601/5 M

RSRKW 30-601/10 M

Cordsets, Double-Ended

1-717-217-2299 www.lumberg-automationusa.com50

Mini 1” Double-Ended Cordsets, B Body Style, 16 and 18 AWG

Mini 1 1/8” Double-Ended Cordsets, C Body Style, 16 and 18 AWG

1” B Body-Male Str to Female Str

Mini Cordsets, Double Ended, 1” Male Straight to

Female Straight Connector, 6-, 7-, and 8-Poles with

Internal Threads and Molded Cable. IP 67 Rated.

Color Code: U.S.

Cable Types: 16 AWG

696 | 622 | 698 = PVC, yellow

Cable Types: 18 AWG

649 | 650 = PVC, yellow

RSRK 601B...801M

Part No. Part No.

RSRK 601B-696/6 F RSRK 801M-650/6 F

RSRK 601B-696/12 F RSRK 801M-650/12 F

RSRK 601B-696/15 F RSRK 801M-650/15 F

RSRK 601B-696/20 F RSRK 801M-650/20 F

RSRK 601B-696/30 F RSRK 801M-650/30 F

RSRK 701M-622/6 F RSRK 801M-698/6 F

RSRK 701M-622/12 F RSRK 801M-698/12 F

RSRK 701M-622/15 F RSRK 801M-698/15 F

RSRK 701M-622/20 F RSRK 801M-698/20 F

RSRK 701M-622/30 F RSRK 801M-698/30 F

RSRK 701M-649/6 F

RSRK 701M-649/12 F

RSRK 701M-649/15 F

RSRK 701M-649/20 F

RSRK 701M-649/30 F

1 1/8” C Body-Male Str (ET) to Female Str

Mini Cordsets, Double Ended, 1 1/8”” Male Straight to

Female Straight Connector, 12-Poles (11 Conductors)

with External Threads and Molded Cable. IP 67 Rated.

Color Code: IEC

Cable Types: 18 AWG

728 = TPE, yellow

RSRK 1201M

Part No.

RSRK 1201M-728/6 F

RSRK 1201M-728/12 F

RSRK 1201M-728/15 F

RSRK 1201M-728/20 F

RSRK 1201M-728/30 F

www.lumberg-automationusa.com 1-717-217-2299 51

M23 Male Straight – M23 Female 90˚

M23 Cordsets, Double Ended, Male Striaght to

Female 90˚ Connector, 19-Poles with Threaded Joint,

IP 67 Rated.

– control cable for actuator/sensor boxes –

Cable Types:

355 = PUR, grey

RSUF-RKWU

M23 Double-Ended Cordsets for Actuators, Sensors and Distribution Boxes

Connector Types: M23-M23

Part No.

RSUF 19-RKWU 19-355/2 M

RSUF 19-RKWU 19-355/5 M

RSUF 19-RKWU 19-355/10 M

M23 Male 90˚ – M23 Female 90˚

M23 Cordsets, Double Ended, Male 90˚ to Female 90˚

Connector, 12-Poles with Threaded Joint,

IP 67 Rated.

– control cable for actuator/sensor boxes –

Cable Types:

256 = PUR, halogen-free, black

RSWU-RKWU

Part No.

RSWU 12-RKWU 12-256/5 M

RSWU 12-RKWU 12-256/10 M

RSWU 12-RKWU 12-256/15 M

RSWU 12-RKWU 12-256/20 M

Cordsets

Double-Ended

Mini 1 1/8” Double-Ended Cordsets, C Body Style, 16 and 18 AWG

1 1/8” C Body-Male Str to Female Str

Mini Cordsets, Single Ended, 1 1/8”” Female Straight

Connector, 9-, 10-, 12- and 19-Poles with Internal

Threads and Molded Cable. IP 67 Rated.

Color Code: U.S.

Cable Types: 16 AWG

623 | 699 = PVC, yellow

724 = TPE, yellow

Cable Types: 18 AWG

651 | 652 | 654 = PUR, yellow

Color Code: Numeric

Cable Types: 18 AWG

676 | 669 = PUR, yellow

RSRK 901M...1901M

Part No. Part No.

RSRK 901M-623/6 F RSRK 1201M-724/6 F

RSRK 901M-623/12 F RSRK 1201M-724/12 F

RSRK 901M-623/15 F RSRK 1201M-724/15 F

RSRK 901M-623/20 F RSRK 1201M-724/20 F

RSRK 901M-623/30 F RSRK 1201M-724/30 F

RSRK 901M-651/6 F RSRK 1201M-654/6 F

RSRK 901M-651/12 F RSRK 1201M-654/12 F

RSRK 901M-651/15 F RSRK 1201M-654/15 F

RSRK 901M-651/20 F RSRK 1201M-654/20 F

RSRK 901M-651/30 F RSRK 1201M-654/30 F

RSRK 1001M-699/6 F RSRK 1201M-676/1 M

RSRK 1001M-699/12 F RSRK 1201M-676/2 M

RSRK 1001M-699/15 F RSRK 1201M-676/3 M

RSRK 1001M-699/20 F RSRK 1201M-676/5 M

RSRK 1001M-699/30 F RSRK 1201M-676/15 M

RSRK 1001M-652/6 F RSRK 1901M-669/2 M

RSRK 1001M-652/12 F RSRK 1901M-669/5 M

RSRK 1001M-652/15 F

RSRK 1001M-652/20 F

RSRK 1001M-652/30 F

Cordsets, Double-Ended
