www.lumberg-automationusa.com 1-717-217-2299 43

M12 Male Straight – Valve Connector

M12 Cordsets, Double Ended, Male Straight

Connector with Self-Locking Threaded Joint to Valve

Connector Similar to DIN EN 175301-803, Industry

Standard Form B.

VB 1A 1-1: Cable Gland 0˚

VB 1A 1-2: Cable Gland 180˚

Cable Types:

226 = PUR, halogen-free, black

RST-VB 1A 1-1 | RST-VB 1A 1-2

M12 Double-Ended Cordsets for Actuators, Sensors and Distribution Boxes

Connector Types: M12-Valve Connector

Part No.

RST 5-3-VB 1A-1-1-226/0,3 M

RST 5-3-VB 1A-1-1-226/0,6 M

RST 5-3-VB 1A-1-1-226/1 M

RST 5-3-VB 1A-1-1-226/1,5 M

RST 5-3-VB 1A-1-1-226/2 M

RST 5-3-VB 1A-1-1-226/5 M

RST 5-3-VB 1A-1-2-226/0,3 M

RST 5-3-VB 1A-1-2-226/0,6 M

RST 5-3-VB 1A-1-2-226/1 M

RST 5-3-VB 1A-1-2-226/1,5 M

RST 5-3-VB 1A-1-2-226/2 M

RST 5-3-VB 1A-1-2-226/5 M

M12 Male Straight – Valve Connector

M12 Cordsets, Double Ended, Male Straight

Connector with Self-Locking Threaded Joint to Valve

Connector According to DIN EN 175301-803, Form C

(8.0 mm).

Cable Types:

226 = PUR, halogen-free, black

241 = PUR, halogen-free,

welding spark proof

RST-VCD 1A 1-3

Part No.

RST 5-3-VCD 1A-1-3-226/0,3 M

RST 5-3-VCD 1A-1-3-226/0,6 M

RST 5-3-VCD 1A-1-3-226/1 M

RST 5-3-VCD 1A-1-3-226/1,5 M

RST 5-3-VCD 1A-1-3-226/2 M

RST 5-3-VCD 1A-1-3-226/5 M

RST 5-3-VCD 1A-1-3-241/0,3 M

RST 5-3-VCD 1A-1-3-241/0,6 M

RST 5-3-VCD 1A-1-3-241/1 M

RST 5-3-VCD 1A-1-3-241/1,5 M

RST 5-3-VCD 1A-1-3-241/2 M

RST 5-3-VCD 1A-1-3-241/5 M

M12 Male Straight – Valve Connector

M12 Cordsets, Double Ended, Male Straight

Connector with Self-Locking Threaded Joint to Valve

Connector Similar to DIN EN 175301-803, Industry

Standard Form C (9.4 mm).

Cable Types:

226 = PUR, halogen-free, black

RST-VC 1A 1-3

Part No.

RST 5-3-VC 1A-1-3-226/0,3 M

RST 5-3-VC 1A-1-3-226/0,6 M

RST 5-3-VC 1A-1-3-226/1 M

RST 5-3-VC 1A-1-3-226/1,5 M

RST 5-3-VC 1A-1-3-226/2 M

RST 5-3-VC 1A-1-3-226/5 M

Cordsets

Double-Ended

Cordsets, Double-Ended

1-717-217-2299 www.lumberg-automationusa.com44

M12-Duo-Male - 2xM8-Female 90˚ (LED)

Actuator-/Sensor-Double Ended, M12-Duo-Male and

two M8-Female 90˚, 3-Pole with LED Operation

and Function Indicator, Self-Locking Threaded Joint,

IP 67 Rated.

Cable Types:

226 = PUR, halogen-free, black

M12-Duo-Male - 2xM12-Female Straight

Actuator-/Sensor-Double Ended, M12-Duo-Male and

two M12-Female Straight, 3-Pole with Self-Locking

Threaded Joint, IP 67 Rated.

ASB 2-RKT: without AND Logic

ASBA 2-RKT: with AND Logic

Cable Types:

224 = PUR, halogen-free, black

251 = PUR, halogen-free, weld

spark proof, black

M12-Duo-Male - 2xM12-Female 90˚

Actuator-/Sensor-Double Ended, M12-Duo-Male

and two M12-Female 90˚, 3-Pole with Self-Locking

Threaded Joint, IP 67 Rated.

Cable Types:

224 = PUR, halogen-free, black

251 = PUR, halogen-free, weld

spark proof, black

M12-Duo-Male - 2xM12-Female 90˚ (LED)

Actuator-/Sensor-Double Ended, M12-Duo-Male and

two M12-Female 90˚, 3-Pole with LED Operation

and Function Indicator, Self-Locking Threaded Joint,

IP 67 Rated.

Cable Types:

224 = PUR, halogen-free, black

ASB 2-RKMWV/LED

ASB 2-RKT | ASBA 2-RKT

ASB 2-RKWT

ASB 2-RKWT/LED

M12 Double-Ended Cordsets for Actuators, Sensors and Distribution Boxes

Duo-Connector Types: M12 Duo-2xM8, M12 Duo-2xM12

Part No.

ASB 2-RKMWV/LED A 3-224/1 M

ASB 2-RKMWV/LED A 3-224/2 M

ASB 2-RKMWV/LED A 3-224/1,5 M

Part No.

ASB 2-RKT 4-3-224/1 M

ASB 2-RKT 4-3-224/1,5 M

ASB 2-RKT 4-3-224/2 M

ASB 2-RKT 4-3-251/1 M

ASB 2-RKT 4-3-251/1,5 M

ASB 2-RKT 4-3-251/2 M

ASBA 2-RKT 4-3-224/1 M

ASBA 2-RKT 4-3-224/1,5 M

ASBA 2-RKT 4-3-224/2 M

Part No.

ASB 2-RKWT 4-3-224/1 M

ASB 2-RKWT 4-3-224/2 M

ASB 2-RKWT 4-3-224/1,5 M

ASB 2-RKWT 4-3-251/1 M

ASB 2-RKWT 4-3-251/2 M

ASB 2-RKWT 4-3-251/1,5 M

Part No.

ASB 2-RKWT/LED A 4-3-224/1 M

ASB 2-RKWT/LED A 4-3-224/2 M

ASB 2-RKWT/LED A 4-3-224/1,5 M

www.lumberg-automationusa.com 1-717-217-2299 45

M12 Double-Ended Cordsets for Actuators, Sensors and Distribution Boxes

Duo-Connector Types: M12 Duo-2xM8, M12 Duo-2xM12

M12-Duo-Male - 2xM12-Male/Female

Actuator-/Sensor-Double Ended, M12-Duo-Male and

two M12-Male and Female Straight, 3-Pole, Self-

Locking Threaded Joint, IP 67 Rated.

Cable Types:

228 = PUR, halogen-free, black

M12-Duo-Male - 2xValve Connector

Actuator-/Sensor-Double Ended, M12-Duo-Male

5-Pole with Self-Locking Threaded Joint, and two

Valve Connectors According to DIN EN 175301-803,

DIN Form A, IP 67 Rated.

Cable Types:

226 = PUR, halogen-free, black

ASB 2-RST-RKT

ASB 2-VAD 1A

Part No.

ASB 2-RST 5-228/0,2-RKT 5-228/1 M

ASB 2-RST 5-228/0,2-RKT 5-228/1,5 M

ASB 2-RST 5-228/0,2-RKT 5-228/2 M

Part No.

ASB 2-VAD 1A-1-3-226/1 M

ASB 2-VAD 1A-1-3-226/1,5 M

ASB 2-VAD 1A-1-3-226/2 M

M12 Double-Ended Cordsets for Actuators, Sensors and Distribution Boxes

Duo-Connector Types: M12 Duo-2xM12, M12 Duo-2xValve Connector

M12-Duo-Male - 2xValve Connector

Actuator-/Sensor-Double Ended, M12-Duo-Male

5-Pole with Self-Locking Threaded Joint, and two

Valve Connectors According to DIN EN 175301-803,

DIN Form B, IP 67 Rated.

Cable Types:

226 = PUR, halogen-free, black

ASB 2-VBD 1A

Part No.

ASB 2-VBD 1A-1-1-226/1 M

ASB 2-VBD 1A-1-1-226/1,5 M

ASB 2-VBD 1A-1-1-226/2 M

Cordsets

Double-Ended

Cordsets, Double-Ended
