M12 Double-Ended Cordsets for Actuators, Sensors and Distribution Boxes
Connector Types: M12-M12
M12 Male Straight – M12 Female Straight
M12 Cordsets, Double Ended, Male Straight to
Female Straight with Threaded Connector 3-, 4- and
5-Poles with Molded Cable. IP 67 Rated.
Cable Types: 18 AWG
731 | 637 = TPE, yellow
645 | 602 = PUR, yellow
Cable Types: 22 AWG
632 | 633 | 612 = PVC, yellow
610 | 679 | 644 = PUR, yellow
643 = TPE, yellow
M12 Male Straight – M12 Female 90˚
M12 Cordsets, Double Ended, Male Straight to
Female 90˚ with Threaded Connector 3-, 4-, 6- and
8-Poles with Molded Cable. IP 67 Rated.
8-6 poles: Used with Sensor/Actuator Distribution
Box, Type: SBS
Cable Types:
224 | 225 | 337 = PUR, halogen-free, black
268 = PUR, halogen-free, weld
spark proof, orange
627 = PVC, black
RST-RKT
RST-RKWT
Part No.
RST 3-RKWT 4-3-224/0,3 M RST 8-RKWT 8-6-268/2 M
RST 3-RKWT 4-3-224/0,6 M RST 8-RKWT 8-6-268/5 M
RST 3-RKWT 4-3-224/1 M RST 8-RKWT 8-6-268/10 M
RST 3-RKWT 4-3-224/1,5 M RST 8-RKWT 8-6-337/2 M
RST 3-RKWT 4-3-224/2 M RST 8-RKWT 8-6-337/5 M
RST 3-RKWT 4-3-224/5 M RST 8-RKWT 8-6-337/10 M
RST 4-RKWT 4-225/0,3 M RST 8-RKWT 8-627/0.6 M
RST 4-RKWT 4-225/0,6 M RST 8-RKWT 8-627/1 M
RST 4-RKWT 4-225/1 M RST 8-RKWT 8-627/2 M
RST 4-RKWT 4-225/1,5 M RST 8-RKWT 8-627/5 M
RST 4-RKWT 4-225/2 M
RST 4-RKWT 4-225/5 M
Part No. Part No.
RST 3-RKT 4-3-731/0,3 M RST 4-RKT 4-643/0,3 M
RST 3-RKT 4-3-731/0,6 M RST 4-RKT 4-643/0,6 M
RST 3-RKT 4-3-731/1 M RST 4-RKT 4-643/1 M
RST 3-RKT 4-3-731/2 M RST 4-RKT 4-643/2 M
RST 3-RKT 4-3-731/5 M RST 4-RKT 4-643/3 M
RST 3-RKT 4-3-632/0,3 M RST 4-RKT 4-643/5 M
RST 3-RKT 4-3-632/0,6 M RST 4-RKT 4-602/0,3 M
RST 3-RKT 4-3-632/1 M RST 4-RKT 4-602/0,6 M
RST 3-RKT 4-3-632/2 M RST 4-RKT 4-602/1 M
RST 3-RKT 4-3-632/5 M RST 4-RKT 4-602/2 M
RST 3-RKT 4-3-645/0,3 M RST 4-RKT 4-602/3 M
RST 3-RKT 4-3-645/0,6 M RST 4-RKT 4-602/5 M
RST 3-RKT 4-3-645/1 M RST 4-RKT 4-679/0,3 M
RST 3-RKT 4-3-645/2 M RST 4-RKT 4-679/0,6 M
RST 3-RKT 4-3-645/5 M RST 4-RKT 4-679/1 M
RST 3-RKT 4-3-610/0,3 M RST 4-RKT 4-679/2 M
RST 3-RKT 4-3-610/0,6 M RST 4-RKT 4-679/3 M
RST 3-RKT 4-3-610/1 M RST 4-RKT 4-679/5 M
RST 3-RKT 4-3-610/2 M RST 5-RKT 5-612/0,3 M
RST 3-RKT 4-3-610/5 M RST 5-RKT 5-612/0,6 M
RST 4-RKT 4-637/0,3 M RST 5-RKT 5-612/1 M
RST 4-RKT 4-637/0,6 M RST 5-RKT 5-612/2 M
RST 4-RKT 4-637/1 M RST 5-RKT 5-612/5 M
RST 4-RKT 4-637/2 M RST 5-RKT 5-644/0,3 M
RST 4-RKT 4-637/3 M RST 5-RKT 5-644/0,6 M
RST 4-RKT 4-637/5 M RST 5-RKT 5-644/1 M
RST 4-RKT 4-633/0,3 M RST 5-RKT 5-644/2 M
RST 4-RKT 4-633/0,6 M RST 5-RKT 5-644/5 M
RST 4-RKT 4-633/1 M
RST 4-RKT 4-633/2 M
RST 4-RKT 4-633/3 M
RST 4-RKT 4-633/5 M
