1-717-217-2299 www.lumberg-automationusa.com34

M8 Male Straight – M8 Female Straight

M8 Cordsets, Double Ended, Male Straight to Female

Straight with Threaded Connector 3-Poles and

Molded Cable. IP 67 Rated.

Cable Types:

224 = PUR, halogen-free, black

M8 Male Straight – M8 Female 90˚

M8 Cordsets, Double Ended, Male Straight to Female

90˚ with Threaded Connector 3-Poles and Molded

Cable. IP 67 Rated.

Cable Types:

224 = PUR, halogen-free, black

M8 Male Straight – M8 Female 90˚ (LED)

M8 Cordsets, Double Ended, Male Straight to Female

90˚ with LED and Threaded Connector 3-Poles and

Molded Cable. IP 67 Rated.

Cable Types:

224 = PUR, halogen-free, black

M8 Male Straight – M12 Female Straight

M8 Cordsets, Double Ended, M8 Male Straight to M12

Female Straight with Threaded Connector 3-Poles

and Molded Cable. IP 67 Rated.

Cable Types:

224 = PUR, halogen-free, black

RSMV-RKMV

RSMV-RKMWV

RSMV-RKMWV/LED

RSMV-RKT

Part No.

RSMV 3-RKMV 3-224/0,6

RSMV 3-RKMV 3-224/1 M

RSMV 3-RKMV 3-224/2 M

Part No.

RSMV 3-RKMWV 3-224/0,6 M

RSMV 3-RKMWV 3-224/1 M

RSMV 3-RKMWV 3-224/2 M

Part No.

RSMV 3-RKMWV/LED A 3-224/0,6 M

RSMV 3-RKMWV/LED A 3-224/1 M

RSMV 3-RKMWV/LED A 3-224/2 M

Part No.

RSMV 3-RKT 4-3-224/0,6 M

RSMV 3-RKT 4-3-224/1 M

RSMV 3-RKT 4-3-224/2 M

M8-Double-Ended Cordsets for Actuators, Sensors and Distribution Boxes

Connector Types: M8-M8 and M8-M12

M8 Male Straight – M8 Female Snap-In

M8 Cordsets, Double Ended, Male Straight with

Threaded Joint to Female Straight (Snap-In)

Connector 3-Poles and Molded Cable.

IP 67 / IP 65 Rated.

Cable Types:

224 = PUR, halogen-free, black

RSMV-RKM

Part No.

RSMV 3-RKM 3-224/0,6

RSMV 3-RKM 3-224/1 M

RSMV 3-RKM 3-224/2 M

www.lumberg-automationusa.com 1-717-217-2299 35

M12 Male Straight – M8 Female Snap-In

M12 Cordsets, Double Ended, M12 Male Straight with

Threaded Connector to M8 Female Straight (Snap-In)

3-Poles and Molded Cable. IP 67 / IP 65 Rated.

Cable Types:

224 = PUR, halogen-free, black

M12 Male Straight – M8 Female

M12 Cordsets, Double Ended, M12 Male Straight to

M8 Female Straight with Threaded Connector 3-Poles

and Molded Cable. IP 67 Rated.

Cable Types:

224 = PUR, halogen-free, black

M12 Male Straight – M8 Female (LED)

M12 Cordsets, Double Ended, M12 Male Straight to

M8 Female Straight with LED, Threaded Connector

3-Poles and Molded Cable. IP 67 Rated.

Cable Types:

224 = PUR, halogen-free, black

RST-RKM

RST-RKMV

RST-RKMV/LED

Part No.

RST 3-RKM 3-224/0,3 M

RST 3-RKM 3-224/0,6 M

RST 3-RKM 3-224/1 M

RST 3-RKM 3-224/1,5 M

RST 3-RKM 3-224/2 M

RST 3-RKM 3-224/5 M

Part No.

RST 3-RKMV 3-224/0,3 M

RST 3-RKMV 3-224/0,6 M

RST 3-RKMV 3-224/1 M

RST 3-RKMV 3-224/2 M

RST 3-RKMV 3-224/5 M

RST 3-RKMV 3-224/1,5 M

Part No.

RST 3-RKMW/LED A 3-224/0,3 M

RST 3-RKMW/LED A 3-224/0,6 M

RST 3-RKMW/LED A 3-224/1 M

RST 3-RKMW/LED A 3-224/1,5 M

RST 3-RKMW/LED A 3-224/2 M

RST 3-RKMW/LED A 3-224/5 M

M8-Double-Ended Cordsets for Actuators, Sensors and Distribution Boxes

Connector Types: M8-M12 and M12-M8

M8 Male Straight – M12 Female 90˚

M8 Cordsets, Double Ended, M8 Male Straight to M12

Female 90˚ with Threaded Connector 3-Poles and

Molded Cable. IP 67 Rated.

Cable Types:

224 = PUR, halogen-free, black

M8 Male Straight – M12 Female 90˚ (LED)

M8 Cordsets, Double Ended, M8 Male Straight to

M12 Female 90˚ with LED and Threaded Connector

3-Poles and Molded Cable. IP 67 Rated.

Cable Types:

224 = PUR, halogen-free, black

RSMV-RKWT

RSMV-RKWT/LED

Part No.

RSMV 3-RKWT 4-3-224/0,6 M

RSMV 3-RKWT 4-3-224/1 M

RSMV 3-RKWT 4-3-224/2 M

Part No.

RSMV 3-RKWT/LED A 4-3-224/0,6 M

RSMV 3-RKWT/LED A 4-3-224/1 M

RSMV 3-RKWT/LED A 4-3-224/2 M

Cordsets

Double-Ended

Cordsets, Double-Ended

1-717-217-2299 www.lumberg-automationusa.com36

M8-Double-Ended Cordsets for Actuators, Sensors and Distribution Boxes

Connector Types: M12-M8 and M12-M12

M12 Male Straight – M8 Female 90˚ (LED)

M12 Cordsets, Double Ended, M12 Male Straight

to M8 Female 90˚ with LED, Threaded Connector

3-Poles and Molded Cable. IP 67 Rated.

Cable Types:

224 = PUR, halogen-free, black

RST-RKMWV/LED

Part No.

RST 3-RKMWV/ LED A 3-224/0,3 M

RST 3-RKMWV/LED A 3-224/0,6 M

RST 3-RKMWV/LED A 3-224/1 M

RST 3-RKMWV/LED A 3-224/1,5 M

RST 3-RKMWV/LED A 3-224/2 M

RST 3-RKMWV/LED A 3-224/5 M

M12 Male Straight – M12 Female Straight

M12 Cordsets, Double Ended, Male Straight to

Female Straight with Threaded Connector 3-, 4-, 5-

and 8-Poles with Molded Cable. IP 67 Rated.

8-6 poles: Used with Sensor/Actuator Distribution

Box, Type: SBS

Cable Types:

224 | 225 | 228 |

282 | 337 = PUR, halogen-free, black

251 | 259 | 268 = PUR, halogen-free, weld

spark proof, orange

627 = PVC, black

RST-RKT

Part No.

RST 3-RKT 4-3-224/0,3 M RST 8-RKT 8-627/0,3 M

RST 3-RKT 4-3-224/0,6 M RST 8-RKT 8-627/0,6 M

RST 3-RKT 4-3-224/1 M RST 8-RKT 8-627/1 M

RST 3-RKT 4-3-224/1,5 M RST 8-RKT 8-627/2 M

RST 3-RKT 4-3-224/2 M RST 8-RKT 8-627/5 M

RST 3-RKT 4-3-224/5 M

RST 4-RKT 4-225/0,3 M

RST 4-RKT 4-225/0,6 M

RST 4-RKT 4-225/1 M

RST 4-RKT 4-225/1,5 M

RST 4-RKT 4-225/2 M

RST 4-RKT 4-225/5 M

RST 4-RKT 4-251/0,3 M

RST 4-RKT 4-251/0,6 M

RST 4-RKT 4-251/1 M

RST 4-RKT 4-251/1,5 M

RST 4-RKT 4-251/2 M

RST 4-RKT 4-251/5 M

RST 5-RKT 5-228/0,3 M

RST 5-RKT 5-228/0,6 M

RST 5-RKT 5-228/1 M

RST 5-RKT 5-228/1,5 M

RST 5-RKT 5-228/2 M

RST 5-RKT 5-228/5 M

RST 5-RKT 5-259/0,3 M

RST 5-RKT 5-259/0,6 M

RST 5-RKT 5-259/1 M

RST 5-RKT 5-259/1,5 M

RST 5-RKT 5-259/2 M

RST 5-RKT 5-259/5 M

RST 8-RKT 8-6-268/2 M

RST 8-RKT 8-6-268/5 M

RST 8-RKT 8-6-268/10 M

RST 8-RKT 8-6-337/2 M

RST 8-RKT 8-6-337/5 M

RST 8-RKT 8-6-337/10 M

RST 8-RKT 8-282/0,3 M

RST 8-RKT 8-282/0,6 M

RST 8-RKT 8-282/1 M

RST 8-RKT 8-282/1,5 M

RST 8-RKT 8-282/2 M

RST 8-RKT 8-282/5 M
