International Rectifier 10ETF04

Cross Number:

Item Description: DIODE GEN PURP 400V 10A TO220AC

Qty Price
1 + $0.89000



Other Cross Reference

Manufacturer Date Code Qty Available Qty
International Rectifier 0015
  • Freelance Stock: 2
    Ships Immediately





Technical Document


DISCLAIMER: The information provided herein is solely for informational purposes. Customers must be aware of the suitability of this product for their application, and consider that variable factors such as Manufacturer, Product Category, Date Codes, Pictures and Descriptions may differ from available inventory.

I
F(AV)
Sinusoidal waveform 10 A
V
RRM
200 to 600 V
I
FSM
150 A
V
F
@
10 A, T
J
= 25°C 1.2 V
t
rr
@ 1A, 100A/µs 50 ns
T
J
- 40 to 150 °C
Major Ratings and Characteristics
Characteristics 10ETF.. Units
Description/Features
The 10ETF.. fast soft recovery QUIETIR rectifier
series has been optimized for combined short
reverse recovery time and low forward voltage
drop.
The glass passivation ensures stable reliable
operation in the most severe temperature and
power cycling conditions.
Typical applications are both:
output rectification and freewheeling in
inverters, choppers and converters
and input rectifications where severe
restrictions on conducted EMI should be met.
TO-220AC
Package Outline
1
Bulletin I2137 rev. B 10/00
QUIETIR Series
10ETF..
V
F
< 1.2V @ 10A
t
rr
= 50ns
V
RRM
200 to 600V
FAST SOFT RECOVERY
RECTIFIER DIODE
2
10ETF.. QUIETIR Series
Bulletin I2137 rev. B 10/00
I
F(AV)
Max. Average Forward Current 10 A @ T
C
= 128° C, 180° conduction half sine wave
I
FSM
Max. Peak One Cycle Non-Repetitive 150 10ms Sine pulse, rated V
RRM
applied
Surge Current 160 10ms Sine pulse, no voltage reapplied
I
2
t Max. I
2
t for fusing 112.5 10ms Sine pulse, rated V
RRM
applied
160 10ms Sine pulse, no voltage reapplied
I
2
t Max. I
2
t for fusing 1600 A
2
s t = 0.1 to 10ms, no voltage reapplied
Part Number
V
RRM
, maximum V
RSM
, maximum non repetitive I
RRM
peak reverse voltage peak reverse voltage 150°C
VVmA
10ETF02 200 300 2
10ETF04 400 500
10ETF06 600 700
Voltage Ratings
Absolute Maximum Ratings
Electrical Specifications
Recovery Characteristics
Parameters 10ETF.. Units Conditions
A
A
2
s
V
FM
Max. Forward Voltage Drop 1.2 V @ 10A, T
J
= 25°C
r
t
Forward slope resistance 23.5 m T
J
= 150°C
V
F(TO)
Threshold voltage 0.85 V
I
RM
Max. Reverse Leakage Current 0.1 T
J
= 25 °C
3.0 T
J
= 150 °C
Parameters 10ETF.. Units Conditions
V
R
= rated V
RRM
mA
t
rr
Reverse Recovery Time 145 ns I
F
@ 10Apk
I
rr
Reverse Recovery Current 2.75 A @ 25A/ µs
Q
rr
Reverse Recovery Charge 0.32 µC @ 25°C
S Snap Factor 0.6
Parameters 10ETF.. Units Conditions
3
10ETF.. QUIETIR Series
Bulletin I2137 rev. B 10/00
T
J
Max. Junction Temperature Range - 40 to 150 °C
T
stg
Max. Storage Temperature Range - 40 to 150 °C
R
thJC
Max. Thermal Resistance Junction 1.5 °C/W DC operation
to Case
R
thJA
Max. Thermal Resistance Junction 62 °C/W
to Ambient
R
thCS
Typical Thermal Resistance, Case to 0.5 °C/W Mounting surface , smooth and greased
Heatsink
wt Approximate Weight 2 (0.07) g (oz.)
T Mounting Torque Min. 6 (5)
Max. 12 (10)
Case Style TO-220AC JEDEC
Thermal-Mechanical Specifications
Parameters 10ETF.. Units Conditions
Kg-cm
(Ibf-in)
Fig. 1 - Current Rating Characteristics
Fig. 2 - Current Rating Characteristics
Fig. 3 - Forward Power Loss Characteristics Fig. 4 - Forward Power Loss Characteristics
120
125
130
135
140
145
150
024681012
30
60
90
120
180
Maximum Allowable Case Temperature ( C)
Conduction Angle
Average Forward Current (A)
10ETF.. Series
R (DC) = 1.5 C/W
thJC
120
125
130
135
140
145
150
0246810121416
DC
30
60
90
120
180
Maximum Allowable Case Temperature ( C)
Conduction Period
Average Forward Current (A)
10ETF.. Series
R (DC) = 1.5 C/W
thJC
0
2
4
6
8
10
12
14
16
0246810
Average Forward Current (A)
RMS Limit
Maximum Average Forward Power Loss (W)
Conduction Angle
180
120
90
60
30
10ETF.. Series
T = 150 C
J
0
4
8
12
16
20
0481216
DC
180
120
90
60
30
Average Forward Current (A)
RMS Limit
Maximum Average Forward Power Loss (W)
Conduction Period
10ETF.. Series
T = 150 C
J
