Technical Document


DISCLAIMER: The information provided herein is solely for informational purposes. Customers must be aware of the suitability of this product for their application, and consider that variable factors such as Manufacturer, Product Category, Date Codes, Pictures and Descriptions may differ from available inventory.

Mobile
AUDIO
JACK
291
Specifications:
Insulator Material : Black High Temp. Plastic
: 1.5A
: 115V AC
: 500V AC For 60 Seconds
Operating Type Range
Terminal Material
Platings
Max. Current Rating
Max. Voltage Rating
Dielectric Strength
Order Information
2.50mm EARPHONE JACK 3 POLES
010162FB Series
: Phos. Bronze
: Contact-Selective Gold
Plated or Full Gold Plated
Recommended P.C.B Layout
12 3 45
1. 'B' : Right Angle SMT Type
2. No. of pins.
3. Plating
4. Color 'Z' : Black
5. Package
'U' : Tube Package Without Cap
Reference Page 11
