Name: 53398-0471
SKU: 53398-0471
Price: 0.19006 USD
Availability: InStock

1801 Morgan Street

Rockford, Illinois 61102

800-435-2931

www.molexkits.com

Datasheet for 76650-0126

• Car Radios

• Process controls

• Cash dispensers

• Patient monitors

• Alarm systems

• Set top boxes

• Dvd

ers

• Reliable terminal for solid electrical

connection

• Friction lock for good mating retention

• Polarizing features ensures proper

mating orientation

• Two solder tabs for better connection

to the PCB

Features and Benefits

Applications

Current Rating: 1 Amp

Specifications

Circuit Sizes:

1.25mm (.049") pitch PicoBlade™ system is designed for high-density harness

applications. PicoBlade provides the same 1.0 amperes of current as similar

2.00mm (.079") pitch systems, but in a more compact design. PicoBlade™ is

offered in wire-to-board and wire-to-wire options. The system saves about 45% of

PCB space compared to typical 2.00mm wire-to-board systems. It is a single row

system, available in 2 to 15 circuits, with both surface mount and through-hole

headers.

Voltage:

2, 3, 4, 6 and 8

Pitch:

Mounting

Orientation:

Connector Type: Headers and Receptacles

Vertical

General Information

Molex / Waldom

Wire-to-Board

1.25mm (.049")

Kit assembled in U.S.A.

Description:

Product Family:

Part Number:

Design

Configuration:

76650-0126

Manufacturer:

Country of Origin:

PicoBlade™

Certificates:

SMT Friction Lock Vertical Header and Receptacle

(Molex Parts within this kit) - UL and CSA

Title: PicoBlade Connector Kit

Product Highlights

Wire size:

125 Volts

32-28 AWG

For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com

Page 1 of 2

1801 Morgan Street

Rockford, Illinois 61102

800-435-2931

www.molexkits.com

Datasheet for 76650-0126

Molex Part No.

Quantity in

Kit

50058-8000 100

51021-0200 10

51021-0300 10

51021-0400 10

51021-0600 10

51021-0800 10

53398-0271 10

53398-0371 10

53398-0471 10

53398-0671 10

53398-0871 10

Molex Part No.

63819-0400 *

11-03-0043 *

1.25mm (.049") Pitch PicoBlade™ Header, Surface Mount,

Vertical, 4 Circuits

Japan

1.25mm (.049") Pitch PicoBlade™ Header, Surface Mount,

Vertical, 3 Circuits

Bill of Materials for Part No. 76650-0126

PicoBlade™ Crimp Terminal, Female, 32-28 AWG

1.25mm (.049") Pitch PicoBlade™ Receptacle, 2 Circuits

*Tool(s) not included in kit. Tool(s) ordered separately.

Recommended Molex Tool(s) for Part No. 76650-0126*

Country

of Origin Description

USA

Hand Crimp Tool

Extraction Tool

Sweden

1.25mm (.049") Pitch PicoBlade™ Header, Surface Mount,

Vertical, 8 Circuits

1.25mm (.049") Pitch PicoBlade™ Header, Surface Mount,

Vertical, 6 Circuits

Japan

Country

of Origin

1.25mm (.049") Pitch PicoBlade™ Header, Surface Mount,

Vertical, 2 Circuits

Japan

Description

1.25mm (.049") Pitch PicoBlade™ Receptacle, 8 Circuits

1.25mm (.049") Pitch PicoBlade™ Receptacle, 3 Circuits

1.25mm (.049") Pitch PicoBlade™ Receptacle, 4 Circuits

1.25mm (.049") Pitch PicoBlade™ Receptacle, 6 Circuits

Japan

For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com

Page 2 of 2

Part #	53398-0471
Description	CONNECTOR, HEADER, 4POS, 1ROW, 1.25MM, Product Range:PicoB
Category	HEADER
Availability	In Stock
Qty	34

53398-0471
