Part Number:
1050291001
Status:
Active
Overview: battery_connectors
Description: 2.00mm (.079") Pitch Battery Connector, Right Angle, 4 Circuits, SMT, Contact Width
0.65mm (.026"), Lead-free
Documents:
3D Model Product Specification PS-105029-101 (PDF)
Drawing (PDF) RoHS Certificate of Compliance (PDF)
General
Product Family PCB Headers
Series 105029
Application Board-to-Board
Comments Recommended Nominal Horizontal Deflection 1.05mm
(.041")
Overview battery_connectors
Product Name Battery Connector
Physical
Breakaway No
Circuits (Loaded) 4
Circuits (maximum) 4
Color - Resin Black
Durability (mating cycles max) 10,000
First Mate / Last Break No
Glow-Wire Compliant No
Guide to Mating Part No
Keying to Mating Part None
Lock to Mating Part None
Material - Metal Beryllium Copper
Material - Plating Mating Gold
Material - Plating Termination Tin
Material - Resin High Temperature Thermoplastic
Number of Rows 1
Orientation Right Angle
PCB Locator No
PCB Retention None
Packaging Type Embossed Tape on Reel
Pitch - Mating Interface (in) 0.079 In
Pitch - Mating Interface (mm) 2.00 mm
Pitch - Term. Interface (in) 0.079 In
Pitch - Term. Interface (mm) 2.00 mm
Plating min: Mating (µin) 30
Plating min: Mating (µm) 0.75
Plating min: Termination (µin) 145
Plating min: Termination (µm) 3.75
Polarized to Mating Part No
Polarized to PCB No
Robotic Placement Vacuum Pick-Up Tape
Shrouded No
Stackable No
Temperature Range - Operating -40°C to +85°C
Termination Interface: Style Surface Mount
Electrical
Series
image - Reference only
EU RoHS China RoHS
ELV and RoHS
Compliant
REACH SVHC
Not Reviewed
Halogen-Free
Status
Halogen-Free
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
Search Parts in this Series
105029Series
Current - Maximum per Contact 1A
Voltage - Maximum 200V (RMS)
Solder Process Data
Duration at Max. Process Temperature (seconds) 30
Lead-free Process Capability Reflow Capable (SMT only)
Max. Cycles at Max. Process Temperature 2
Process Temperature max. C 250
Material Info
Reference - Drawing Numbers
Packaging Specification PK-47506-001
Product Specification PS-105029-101
Sales Drawing SD-105029-101
