a
ADP3300
High Accuracy anyCAP
®
50 mA Low Dropout Linear Regulator
One Technology Way, P.O. Box 9106, Norwood, MA 02062-9106, U.S.A.
Tel: 781/329-4700 World Wide Web Site: http://www.analog.com
Fax: 781/326-8703 © Analog Devices, Inc., 2000
FUNCTIONAL BLOCK DIAGRAM
Q2
THERMAL
PROTECTION
Gm
Q1
CC
BANDGAP
REF
DRIVER
R1
R2
ADP3300
OUT
IN
ERR
SD
GND
FEATURES
High Accuracy (Over Line and Load Regulations
at 25C): 0.8%
Ultralow Dropout Voltage: 80 mV Typical @ 50 mA
Requires Only C
O
= 0.47 F for Stability
anyCAP™ = Stable with All Types of Capacitors
(Including MLCC)
Current and Thermal Limiting
Low Noise
Dropout Detector
Low Shutdown Current: 1 A
3.0 V to 12 V Supply Range
–40C to +85C Ambient Temperature Range
Several Fixed Voltage Options
Ultrasmall SOT-23 6-Lead Package
Excellent Line and Load Regulations
APPLICATIONS
Cellular Telephones
Notebook, Palmtop Computers
Battery Powered Systems
PCMCIA Regulators
Bar Code Scanners
Camcorders, Cameras
ADP3300-5
3
1
6
2
NR
OUT
IN
4
R1
330k
E
OUT
C2
0.47
F
V
OUT
= +5V
ON
OFF
GND
C1
0.47
F
V
IN
5
Figure 1. Typical Application Circuit
GENERAL DESCRIPTION
The ADP3300 is a member of the ADP330x family of precision
low dropout anyCAP™ voltage regulators. The ADP3300
stands out from conventional LDOs with a novel architecture
and an enhanced process. Its patented design requires only a
0.47 µF output capacitor for stability. This device is stable with
any capacitor, regardless of its ESR (Equivalent Series Resistance)
value, including ceramic types (MLCC) for space restricted appli-
cations. The ADP3300 achieves exceptional accuracy of ±0.8%
at room temperature and ± 1.4% overall accuracy over tempera-
ture, line and load regulations. The dropout voltage of the
ADP3300 is only 80 mV (typical) at 50 mA.
The ADP3300 operates with a wide input voltage range from
3.0 V to 12 V and delivers a load current in excess of 50 mA. It
features an error flag that signals when the device is about to
lose regulation or when the short circuit or thermal overload
protection is activated. Other features include shutdown and
optional noise reduction capabilities. The ADP330x anyCAP™
anyCAP is a registered trademark of Analog Devices Inc.
LDO family offers a wide range of output voltages and output
current levels from 50 mA to 200 mA:
ADP3301 (100 mA)
ADP3302 (100 mA, Dual Output)
ADP3303 (200 mA)
–2–
REV. A
ADP3300–SPECIFICATIONS
Parameter Symbol Conditions Min Typ Max Units
OUTPUT VOLTAGE V
OUT
V
IN
= V
OUT(NOM)
+0.3 V to 12 V
ACCURACY I
L
= 0.1 mA to 50 mA
T
A
= +25°C –0.8 +0.8 %
V
IN
= V
OUT(NOM)
+0.3 V to 12 V
I
L
= 0.1 mA to 50 mA –1.4 +1.4 %
LINE REGULATION V
O
V
IN
= V
OUT(NOM)
+0.3 V to 12 V
V
IN
T
A
= +25°C 0.02 mV/V
LOAD REGULATION V
O
I
L
= 0.1 mA to 50 mA
I
L
T
A
= +25°C 0.06 mV/mA
GROUND CURRENT I
GND
I
L
= 50 mA 0.55 1.7 mA
I
L
= 0.1 mA 0.19 0.3 mA
GROUND CURRENT I
GND
V
IN
= 2.5 V
IN DROPOUT I
L
= 0.1 mA 0.6 1.2 mA
DROPOUT VOLTAGE V
DROP
V
OUT
= 98% of V
OUT(NOM)
I
L
= 50 mA 0.08 0.17 V
I
L
= 10 mA 0.025 0.07 V
I
L
= 1 mA 0.004 0.03 V
SHUTDOWN THRESHOLD V
THSD
ON 2.0 0.75 V
OFF 0.75 0.3 V
SHUTDOWN PIN I
SDIN
0 < V
SD
5 V 1 µA
INPUT CURRENT 5 < V
SD
12 V @ V
IN
= 12 V 22 µA
GROUND CURRENT IN I
Q
V
SD
= 0, V
IN
= 12 V
SHUTDOWN MODE T
A
= +25°C 0.005 1 µA
V
SD
= 0, V
IN
= 12 V
T
A
= +85°C0.013µA
OUTPUT CURRENT IN I
OSD
T
A
= +25°C @ V
IN
= 12 V 2 µA
SHUTDOWN MODE T
A
= +85°C @ V
IN
= 12 V 4 µA
ERROR PIN OUTPUT
LEAKAGE I
EL
V
EO
= 5 V 13 µA
ERROR PIN OUTPUT
“LOW” VOLTAGE V
EOL
I
SINK
= 400 µA 0.12 0.3 V
PEAK LOAD CURRENT I
LDPK
V
IN
= V
OUT(NOM)
+ 1 V 100 mA
OUTPUT NOISE V
NOISE
f = 10 Hz–100 kHz
@ 5 V OUTPUT C
NR
= 0 100 µV
rms
C
NR
= 10 nF, C
L
= 10 µF30µV
rms
NOTE
Ambient temperature of +85°C corresponds to a typical junction temperature of +125°C under typical full load test conditions.
Specifications subject to change without notice.
(@ T
A
= –40C to +85C, V
IN
= 7 V, C
IN
= 0.47 F, C
OUT
= 0.47 F, unless otherwise
noted)
ADP3300
–3–
REV. A
ABSOLUTE MAXIMUM RATINGS*
Input Supply Voltage . . . . . . . . . . . . . . . . . . . . –0.3 V to +16 V
Shutdown Input Voltage . . . . . . . . . . . . . . . . . –0.3 V to +16 V
Error Flag Output Voltage . . . . . . . . . . . . . . . . –0.3 V to +16 V
Noise Bypass Pin Voltage . . . . . . . . . . . . . . . . . –0.3 V to +5 V
Power Dissipation . . . . . . . . . . . . . . . . . . . . Internally Limited
Operating Ambient Temperature Range . . . . –55°C to +125°C
Operating Junction Temperature Range . . . . –55°C to +125°C
θ
JA
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165°C
θ
JC
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92°C
Storage Temperature Range . . . . . . . . . . . . . –65°C to +150°C
Lead Temperature Range (Soldering 10 sec) . . . . . . . . +300°C
Vapor Phase (60 sec ) . . . . . . . . . . . . . . . . . . . . . . . . +215°C
Infrared (15 sec) . . . . . . . . . . . . . . . . . . . . . . . . . . . +220°C
*This is a stress rating only; operation beyond these limits can cause the device to
be permanently damaged.
PIN FUNCTION DESCRIPTIONS
Pin Mnemonic Function
1 GND Ground Pin.
2 NR Noise Reduction Pin. Used for further
reduction of the output noise (see text for
details). No connection if not used.
3 SD Active Low Shutdown Pin. Connect to
ground to disable the regulator output.
When shutdown is not used, this pin should
be connected to the input pin.
4 OUT Output of the Regulator, fixed 2.7, 3.0, 3.2,
3.3 or 5 volts output voltage. Bypass to
ground with a 0.47 µF or larger capacitor.
5 IN Regulator Input.
6 ERR Open Collector Output which goes low to
indicate that the output is about to go out
of regulation.
PIN CONFIGURATION
1
2
3
6
5
4
TOP VIEW
(Not to Scale)
OUT
NR
GND
IN
ERR
SD
ADP3300
Model Voltage Output Package Description Package Options Branding Information
ADP3300ART-2.7 2.7 V Surface Mount SOT-23-6 LAB
ADP3300ART-3 3.0 V Surface Mount SOT-23-6 LBB
ADP3300ART-3.2 3.2 V Surface Mount SOT-23-6 LCB
ADP3300ART-3.3 3.3 V Surface Mount SOT-23-6 LDB
ADP3300ART-5 5.0 V Surface Mount SOT-23-6 LEB
Contact the factory for the availability of other output voltage options.
