G
Max
.656 (16.7)
.656 (16.7)
.844 (21.4)
.844 (21.4)
.844 (21.4)
.844 (21.4)
.844 (21.4)
.844 (21.4)
.844 (21.4)
.844 (21.4)
.844 (21.4)
.844 (21.4)
.844 (21.4)
.844 (21.4)
.844 (21.4)
MIL-DTL-5015
H
Max
.688 (17.5)
.815 (20.7)
1.000 (25.4)
1.125 (28.6)
1.188 (30.2)
1.344 (34.1)
1.469 (37.3)
1.594 (40.5)
1.719 (43.7)
1.969 (50.0)
2.219 (56.4)
2.469 (62.7)
2.719 (69.1)
2.969 (75.4)
3.188 (81.0)
F Dia
Max
.562 (14.3)
.687 (17.4)
.812 (20.6)
.937 (23.8)
1.062 (27.0)
1.187 (30.1)
1.312 (33.3)
1.437 (36.5)
1.562 (39.7)
1.812 (46.0)
2.062 (52.4)
2.312 (58.7)
2.562 (65.1)
2.812 (71.4)
3.062 (77.8)
Shell
Size
8D
10D
12D
14D
16D
18D
20D
22D
24D
28D
32D
36D
40D
44D
48D
E
Thread
1/2 - 28 UNEF
5/8 - 24 UNEF
3/4 - 20 UNEF
7/8 - 20 UNEF
1 - 20 UNEF
1 1/8 - 18 UNEF
1 1/4 - 18 UNEF
1 3/8 - 18 UNEF
1 1/2 - 18 UNEF
1 3/4 - 18 UNS
2 - 18 UNS
2 1/4 - 16 UN
2 1/2 - 16 UN
2 3/4 - 16 UN
3 - 16 UN
J
Max
.469 (11.9)
.469 (11.9)
.469 (11.9)
.469 (11.9)
.469 (11.9)
.469 (11.9)
.469 (11.9)
.469 (11.9)
.469 (11.9)
.531 (13.5)
.531 (13.5)
.531 (13.5)
.531 (13.5)
.531 (13.5)
.531 (13.5)
E Thread
F
G
K
K
E Thread
Attachment
L Dia
Attachment
M Dia
J
Gasket
H
MS25042 Plug Cover MS25043 Receptacle Cover
TABLE I
1. For complete dimensions see applicable Military Specification.
2. Metric dimensions (mm) are indicated in parentheses.
K Attachment
Length
4.00 (101.6)
4.00 (101.6)
4.50 (114.3)
4.50 (114.3)
4.50 (114.3)
4.50 (114.3)
5.00 (127.0)
5.00 (127.0)
5.50 (139.7)
7.75 (196.9)
7.75 (196.9)
7.75 (196.9)
7.75 (196.9)
7.75 (196.9)
7.75 (196.9)
MS25042-20D A
Basic Part No.
MS25042 = Plug Cover
MS25043 = Receptacle Cover
Finish
A = Black Anodize
Shell Size
MS25042 and MS25043
Protective Covers
Prior Revision Available
MS25042-20D
Basic Part No.
MS25042 = Plug Cover
MS25043 = Receptacle Cover
Shell Size
Finish is Cadmium Olive Drab
