Technical Document


DISCLAIMER: The information provided herein is solely for informational purposes. Customers must be aware of the suitability of this product for their application, and consider that variable factors such as Manufacturer, Product Category, Date Codes, Pictures and Descriptions may differ from available inventory.

www.ittcannon.com 356
Dimensions are shown in inches (millimeters).
Dimensions subject to change.
Combo D® - High Voltage
Coaxial Housings With Solder Cup Signal Contacts
High voltage contacts
supplied separately.
High Power Contacts
Solder Type
Plug
Recommended Wire Strip Length
Crimp Tooling - Page 357.
See Commerical D Subminiature catalong for PCB High Power connectors.
Receptacle
A
A
A
B
B
B
.142 +_ .002 (3.61 +_ 0.05)
.345
.315
(8.75)
(8.01)
.824
.804
(20.93)
(20.42)
Crimp Type
Contact Arrangements: Page 346 of Coax section
Peformance Specifications: Page 345 of Coax
section.
Clinch Nut and Float Mount Options Available:
See page 334 for Mouting Method Detail.
Cable Combinations supplied with preloaded solder
signal contacts. High Power Contacts supplied sep-
arately, see below.
Extraction Tool for High Power Contacts are the
same as for 50 Ohm Coaxial Contacts. See page 348.
Add: E = 4-40 Clinch Nut
Y = Float Mounting
DAMME3W3P
DAMMY3W3P
Example:
Layout
DE-5W1
DA-7W2
DA-11W1
DA-3W3
DB-5W5
DB-9W4
DB-13W3
DB-17W2
DB-21W1
DC-8W8
DC-13W6
DC-17W5
DC-21WA4
DC-25W3
DC-27W2
DD-24W7
DD-36W4
DD-43W2
DD-47W1
Gold over
Nickel
50µ in. Gold
over Copper
50µ in. Gold
over Copper
A
Max.
B
Ref.
Current Rating
(Amps)
Wire
Size
Plug
Plug
Plug
Receptacle
Receptacle
Receptacle
DM53745-1
DM53745-7
DM53745-8
DM53744-1
DM53744-6
DM53744-7
DM53745-28
DM53745-27
DM53745-25
DM53744-21
DM53744-25
DM53744-24
DM53745-70
DM53745-77
DM53745-70
DM53744-62
DM53744-64
DM53744-63
.666 (16.92)
.666 (16.92)
.666 (16.92)
.666 (16.92)
.666 (16.92)
.666 (16.92)
.866 (22.00)
.866 (22.00)
.866 (22.00)
.856 (21.74)
.856 (21.74)
.856 (21.74)
40
20
10
40
20
10
#8
#12
#16
#8
#12
#16
Military
Socket
Military
Pin
NM NM
- Non-Magnetic
Socket
- Non-Magnetic
Pin
NM
- Non-Magnetic
Gold over
Nickel
50µ in. Gold
over Copper
A
Dia.
Max.
B
Dia.
Max.
Current
Rating
(Amps)
Wire
Size
Plug
Plug
Plug
Receptacle
Receptacle
Receptacle
DM130338
DN130339
DM130340
DM130341
DM130342
DM130343
DM130338-4
DM130339-4
DM130340-4
DM130341-4
DM130342-4
DM130343-4
.181 (4.60)
.100 (2.54)
.067 (1.07)
.181 (4.60)
.100 (2.54)
.067 (1.07)
.230 (5.84)
.218 (5.54)
.102 (2.59)
.230 (5.84)
.218 (5.54)
.102 (2.59)
40
20
10
40
20
10
#8
#12
#16
#8
#12
#16
DEMM5W1S
DAMM7W2S
DAMM11W1S
DAMM3W3S
DBMM5W5S
DBMM9W4S
DBMM13W3S
DBMM17W2S
DBMM21W1S
DCMM8W8S
DCMM13W6S
DCMM17W5S
DCMM21WA4S
DCMM25W3S
DCMM27W2S
DDMM24W7S
DDMM36W4S
DDMM43W2S
DDMM47W1S
DEMM5W1P
DAMM7W2P
DAMM11W1P
DAMM3W3P
DBMM5W5P
DBMM9W4P
DBMM13W3P
DBMM17W2P
DBMM21W1P
DCMM8W8P
DCMM13W6P
DCMM17W5P
DCMM21WA4P
DCMM25W3P
DCMM27W2P
DDMM24W7P
DDMM36W4P
DDMM43W2P
DDMM47W1P
DEM5W1S-NMB-K52
DAM7W2S-NMB-K52
DAM11W1S-NMB-K52
DAM3W3S-NMB-K47
DBM5W5S-NMB-K47
DBM9W4S-NMB-K52
DBM13W3S-NMB-K52
DBM17W2S-NMB-K52
DBM21W1S-NMB-K52
DCM8W8S-NMB-K47
DCM13W6S-NMB-K52
DCM17W5S-NMB-K52
DCM21WA4S-NMB-K52
DCM25W3S-NMB-K52
DCM27W2S-NMB-K52
DDM24W7S-NMB-K52
DDM36W4S-NMB-K52
DDM43W2S-NMB-K52
DDM47W1S-NMB-K52
DEM5W1P-NMB-K52
DAM7W2P-NMB-K52
DAM11W1P-NMB-K52
DAM3W3P-NMB-K47
DBM5W5P-NMB-K47
DBM9W4P-NMB-K52
DBM13W3P-NMB-K52
DBM17W2P-NMB-K52
DBM21W1P-NMB-K52
DCM8W8P-NMB-K47
DCM13W6P-NMB-K52
DCM17W5P-NMB-K52
DCM21WA4P-NMB-K52
DCM25W3P-NMB-K52
DCM27W2P-NMB-K52
DDM24W7P-NMB-K52
DDM36W4P-NMB-K52
DDM43W2P-NMB-K52
DDM47W1P-NMB-K52
www.ittcannon.com 357
Dimensions are shown in inches (millimeters).
Dimensions subject to change.
Combo D - High Power
®
Crimp High Power Contact Tooling
Combo D Guide Pin and Socket
(For use with Crimp High Power Contacts on Page
356)
AWG Wire
Size
8-10
12-14
16-18
NOTE: Purchase tooling directly from Daniels.
Description
Press Fit Guide Socket
P/N DM53744-72
PCB Guide Pin
P/N DM53745-82
.223 (5.55)
.213 (5.53)
RING, RETAINGING
SHELL, RECEPTACLE
.197
(5.01)
MIN.
.223 (5.66)
.213 (5.41)
.128 (3.25)
.122 (3.10)
.145 (3.68)
.135 (3.43)
1.150
(29.21)
REF.
.115
(2.92)
REF.
RING, RETAINING
2X WASHER, STABILIZING
.153 (3.89)
.149 (3.78)
.197
(5.00)
MIN.
Guide Pin
Guide Socket
Brass
Copper Alloy
Gold over nickel
Gold over nickel
Material Finish
M300-BT
M300-BT
FT-8
TP968
TP968
TH554
AWG 8 = 6
AWG 10 = 5
AWG 12/14 = 1
AWG 16 = 6
AWG 18 = 5
Daniels Crimp
Tool
Tool Setting
Number Locartor
Crimp Tool/Locator
Installs into any Combo D, size 8 Cavity. This
patented guide pin and socket system is ideal for
blind mate applications where space is limited.
www.ittcannon.com 358
Dimensions are shown in inches (millimeters).
Dimensions subject to change.
Combo D® - High Voltage
Coaxial Housings With Solder Cup Signal Contacts
High Voltage Combination Contacts
High voltage contacts
supplied separately.
Wire Accommodation (AWG)
Current Rating
Temperature Rating
Insulator
Ring, Retaining
Contacts Copper Alloy Std: Gold over nickel
MIL-50µ in. Gold over copper
Thermoplastic
Copper Alloy
None
Nickel
Plug
Receptacle
DM51157
DM51155
DM51157-8
DM51155-7
.539 (13.69)
.539 (13.69)
.734 (18.64)
.764 (19.41)
#20
#20
Description Material Finish
Straight
Right Angle
Straight PCB
Plug Receptacle
Plug Receptacle
A
B
B
Plug Receptacle
A
CONTACT.SKT.
A
REF
.192 (4.88)
DIA. MAX.
.225 (5.72)
.210 (5.33)
DIA.
.065 (1.65)
.059 (1.50)
DIA.
B
.234 (5.94)
.214 (5.44)
.145 (3.68)
.139 (3.53)
DIA.
INSULATOR
RING. RETAINING.
COTNACT, PIN
RING, RETAINING
INSULATOR
.255 (6.48)
.245 (6.22)
.192 (4.88)
DIA MAX.
.225 (5.72)
.210 (5.33)
DIA.
.065 (1.65)
.059 (1.50)
DIA.
A
REF
B
B
B
A
Max.
B
Ref.
Wire
Size50µ in. GoldGold over Nickel
Plug
Receptacle
DM51157-5000
DM51155-5000
DM51157-5005
DM51155-5004
.491 (12.47)
.491 (12.47)
.697 (17.70)
.697 (17.70)
#20
#20
A
Max.
B
Ref.
Wire
Size50µ in. GoldGold over Nickel
Plug
Receptacle
DM51157-13
DM51155-12
DM51157-14
DM51155-13
.628 (15.95)
.660 (16.76)
.060/.050 (1.52/1.27)
.010/.000 (0.25/0.00)
Standard Finish Military Finish A B
#20 Max.
5 Amp
-55˚C to +125˚C
Contact Arrangements: Page 346 of Coax section
Peformance Specifications: Page 345 of Coax
section.
Clinch Nut and Float Mount Options Available:
Mouting Method Detail - Page 334.
Cable Combinations supplied with preloaded solder
signal contacts. High Voltage Contacts supplied
separately, see below.
Extraction Tool for High Voltage Contacts are the
same as for 50 Ohm Coaxial Contacts. See page 348.
Add: E = 4-40 Clinch Nut
Y = Float Mounting
DAMME3W3P
DAMMY3W3P
Example:
Layout
Military
Socket
Military
Pin
DE-5W1
DA-7W2
DA-11W1
DA-3W3
DB-5W5
DB-9W4
DB-13W3
DB-17W2
DB-21W1
DC-8W8
DC-13W6
DC-17W5
DC-21WA4
DC-25W3
DC-27W2
DD-24W7
DD-36W4
DD-43W2
DD-47W1
DEMM5W1S
DAMM7W2S
DAMM11W1S
DAMM3W3S
DBMM5W5S
DBMM9W4S
DBMM13W3S
DBMM17W2S
DBMM21W1S
DCMM8W8S
DCMM13W6S
DCMM17W5S
DCMM21WA4S
DCMM25W3S
DCMM27W2S
DCMM24W7S
DCMM36W4S
DCMM43W2S
DCMM47W1S
DEMM5W1P
DAMM7W2P
DAMM11W1P
DAMM3W3P
DBMM5W5P
DBMM9W4P
DBMM13W3P
DBMM17W2P
DBMM21W1P
DCMM8W8P
DCMM13W6P
DCMM17W5P
DCMM21WA4P
DCMM25W3P
DCMM27W2P
DCMM24W7P
DCMM36W4P
DCMM43W2P
DCMM47W1P
